ENGLISH
IP-200 SET-UP MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP-200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JUKI IP-200

Summary of Contents for JUKI IP-200

  • Page 1 ENGLISH IP-200 SET-UP MANUAL...

  • Page 2: Table Of Contents

    !. OUTLINE ........................1 @. CONTENTS OF THE ARTICLES PACKED TOGETHER ..........1 1. For those who have purchased the machine provided with IP-200 operation panel .......1 2. For those who have purchased the single unit of IP-200 operation panel ........1 #. INSTALLING IP-200 ON TABLE/STAN AND CONTROL BOX ........2 1.

  • Page 3: Outline

    !. OUTLINE Operation panel of IP-200 can realize various functions in combination with the control box. @. CONTENTS OF THE ARTICLES PACKED TOGETHER 1. For those who have purchased the machine provided with IP-200 operation panel 1 IP-200 operation panel main unit ............1 set 2 Operation panel installing base ..............

  • Page 4: Installing Ip-200 On Table/Stan And Control Box

    #. INSTALLING IP-200 ON TABLE/STAN AND CONTROL BOX 1. Installing procedure of the operation panel and the installing base 1) When installing the installing base, install it on the table with the screws supplied as accessories. At this time, consider the position of the hole for wiring opened in the table to install the base.

  • Page 5: Explanation Of The Operation Panel

    $. EXPLANATION OF THE OPERATION PANEL Explanation of the respective parts of the operation panel is given below. For the details of the respective parts, refer to "1. NAME OF EACH SECTION OF THE OPERATION PANEL" of the Instruction Manual. 1 LCD display section •...

  • Page 6: Connecting Procedure Of Operation Panel With External Vehicle

    %. CONNECTING PROCEDURE OF OPERATION PANEL WITH EXTERNAL VEHICLE It is possible for this operation panel to perform communication or input of signal with the vehicles below other than the control box. 1. Smart media card 2. RS-232C 3. Input of signal by means of the connector for external input Connecting procedure is given below.
  • Page 7 3) When the setting of the card is completed, close the smart media card cover. It is not possible to receive or send the data with the smart media card with the cover opened. For the operating procedure, refer to "USING COMMUNICATION FUNCTION of the Instruction Manual. If the smart media card comes in contact with the cover and the cover is not closed, check the following matters.

  • Page 8: Rs-232C

    2. RS-232C Operation panel can give and take the data with the personal computer by using communication by means of RS-232C. For the cable to be connected, connect the reverse type 9-pin (female) to the operation panel side. Signal names of the operation panel are as follows. Pin No.

  • Page 9: Input Of Signal By Means Of The Connector For External Input

    3. Input of signal by means of the connector for external input It is possible to input the signal from the outside. When the switch is connected, it is possible to use as the input of the production control information. For the details, refer to "Observing the production control information"...

  • Page 10: Re-Setup Of The Program Of The Operation Panel

    ^. RE-SETUP OF THE PROGRAM OF THE OPERATION PANEL When the case is as below, it is necessary to perform re-setup of the program of the operation panel. ™ When the operation panel is used as that for other model. ™...
  • Page 11 Communication screen 2 6) Press key 6 File selection screen 7) P r e s s k e y 7 a n d s e l e c t t h e download program at display 8 . 8) Press key 9 Communication screen 3 9) Press key !0 <-<- Start of communication ->->...
  • Page 12 Screen during data deletion Screen 1 during data writing Screen 2 during data writing End screen If the screen below is displayed, quickly turn OFF the power and perform the set-up again after checking [Checking items] below. Data writing abnormal screen The procedure above completes the replacing work of application software.

  • Page 13: Re-Setup Of Main Program

    Data edit screen 1) Press key 1 for three seconds. Communication screen 1 2) Press key 2 . 3) Press key 3 Data selection screen 4) Press key 4 5) Press key 5 – 11 –...
  • Page 14 Communication screen 2 6) Press key 6 File selection screen 7) Press key 7 and select download program at display 8 . 8) Press key 9 Communication screen 3 9) Press key !0 <-<- Start of communication ->-> – 12 –...
  • Page 15 Screen during data writing Screen of end of data writing The procedure above completes the replacing work of application software. If the screen below is displayed, quickly turn OFF the power and perform the set-up again after checking [Checking items] below. Data writing abnormal screen Checking items 1 Smart media cover is opened during the data communication from the smart media.

  • Page 16: When Panel Program Does Not Match With Main Program And An Error Occurs

    Error screen 1) Press key 1 Communication screen 1 2) Press key 2 Data selection screen 3) Press key 3 4) Press key 4 – 14 –...
  • Page 17 Communication screen 2 6) Press key 5 File selection screen 7) P r e e s k e y 6 a n d s e l e c t t h e download program at display 7 . 8) Press key 8 Communication screen 3 9) Press key 9 <-<- Start of communication ->->...
  • Page 18 Screen during data writing Screen of end of data writing T h e p r o c e d u r e a b o v e completes the replacing work of application software. If the screen below is displayed, quickly turn OFF the power and perform the set-up again after checking [Checking items] below.

  • Page 19: Re-Setup Of Servo Program

    Data edit screen 1) Press key 1 for three seconds. Communication screen 1 2) Press key 2 . 3) Press key 3 Data selection screen 4) Press key 4 5) Press key 5 – 17 –...
  • Page 20 Communication screen 2 6) Press key 6 File selection screen 7) P r e s s k e y 7 a n d s e l e c t t h e download program at display 8 . 8) Press key 9 Communication screen 3 9) Press key !0 <-<- Start of communication ->->...
  • Page 21 Screen during data writing Screen of end of data writing The procedure above completes the replacing work of application software. If the screen below is displayed, quickly turn OFF the power and perform the set-up again after checking [Checking items] below. Data writing abnormal screen Checking items...

  • Page 22: When Panel Program Does Not Match With Main Program And An Error Occurs

    Error screen 1) Press key 1 Communication screen 1 2) Press key 2 Data selection screen 3) Press key 3 4) Press key 4 – 20 –...
  • Page 23 Communication screen 2 6) Press key 5 File selection screen 7) P r e s s k e y 6 a n d s e l e c t t h e download program at display 7 . 8) Press key 8 Communication screen 3 9) Press key 9 <-<- Start of communication ->->...
  • Page 24 Screen of end of data writing Screen during data writing T h e p r o c e d u r e a b o v e completes the replacing work of application software. If the screen below is displayed, quickly turn OFF the power and perform the set-up again after checking [Checking items] below.

  • Page 25: Packed Together

    When copying the contents of the smart media card which is packed together to the other smart media, create the directory structure mentioned below with the personal computer after formatting the smart media to be the copy destination with IP-200. For the formatting procedure of the smart media, read "USING COMMUNICATION FUNCTION" of Instruction Manual.
