- Page 1 DDL-8000CS Long pitch kit INSTRUCTION MANUAL...
- Page 2 CONTENTS 1. General ............................ 1 2. List of long pitch kit parts ..................... 1 3. How to operate the panel ...................... 2 4. Adjusting the forward and reverse feed stitch ..............5 4-1. Aligning the stitches for the reverse feed stitching at the sewing start (Memory switch No.
- Page 3 1. General The long pitch kit is an optional part kit that changes the maximum stitch length to 7 mm (standard: 5 mm). 2. List of long pitch kit parts Part number of the long pitch kit : 40218198 (with four teeth) ・List of parts supplied with the machine Description Parts No.
- Page 4 3. How to operate the panel 3.1 The service level parameter setting screen will be displayed. Tap the red circle twice. 3.2 Enter the password “2011”. 3.3 The screen will change. Tap the red circle. 3.4 Select “Other settings”. Tap the red circle. –...
- Page 5 3.5 For model DDL8000CSM, select 3 as the Type selection. For Models DDL8000CSC and DDL8000CSH, select 4 as the Type selection. 3.6 Click the “Save” button to complete the type selection. Performing the machine head model settings will initialize the parameters. Tap the red circle.
- Page 6 3.7 Next, adjust the pitch data. Go to the service level parameter setting screen and press the “Stitch length setting of stepping back- tacking” button. Tap the red circle. 3.8 Tap to select the pitch data you want to set. Measure the actual needle entry position and adjust the input data.
- Page 7 4. Adjusting the forward and reverse feed stitch If you want to perform automatic reverse feed stitching with a feed pitch length longer than “5 mm” and adjust the forward and reverse feed stitch due to differences in fabric types, etc., make the following adjustments separately.
- Page 8 4-2. Aligning the stitches for the reverse feed stitching at the sewing end (Memory switch No. U239, U240) Recommendation: Select the stitching alignment for section C before selecting section D. Case 1: Longer C Adjustment: [U239] Decrease the set value. C becomes shorter.
- Page 9 4-3. Aligning the stitches for the multi-layer stitching (Memory switch No. U241, U242) Start point Case 1: Longer A and shorter B Adjustment: [U241] Decrease the set value. A becomes shorter and B becomes longer. Start point Case 1: Shorter A and longer B Adjustment: [U241] Increase the set value.
