Page 1: Installation Manual
ENGLISH INSTALLATION MANUAL * "CompactFlash(TM)" is the registered trademark of SanDisk Corporation, U.S.A. -
Page 2: Table Of Contents
CONTENTS 1. CHECK AT THE BEGINNING ..............1 (1) Control box to be used ..................... 1 (2) List of parts to be used .................... 1 2. SETUP OF THE HARDWEAR ..............1 (1) Attaching the circuit board ..................1 3. SETUP OF THE SOFTWARE ..............3 (1) Checking procedure of the software version ............ -
Page 3: Check At The Beginning
1. CHECK AT THE BEGINNING (1) Control box to be used There are cases where the control box to be used Fig. A may not be utilized. Check that REV. No. 1 as showninFig.Aisafter"02".Ifthenumberisbefore it,thecontrolboxcannotbeused. (2) List of parts to be used OntheoccasionofusingDLU-5494N-7/IP-0C,checkthattheproducts(parts)belowareonhand. - Page 4 3. InsertKT-0(EPF)p.c.b.A(asm.) 1 toconnector CN47 3 ofthemainunitasillustrated. Do not forcibly press the circuit board. 4. Securely fix KT-0(EPF) p.c.b.A (asm.) 1 to the control box main unit using three screws 4 suppliedwiththeunitasaccessories. For installing from M-91 motor to SC-910 control box or installing SC-910 control box on the table, refer to "Instruction Manual for DLU-5494N-7/SC-910/M-91/IP-110C/KT-01".
-
Page 5: Setup Of The Software
3. SETUP OF THE SOFTWARE There are cases where the software in the state of delivery may be unadaptable. Perform checking and updatingofthesoftwarefollowingtheprocedurebelow. (1) Checking procedure of the software version TurnONthepower,andpressswitch 1 forthreeseconds. ■ Normal screen <Information switch> Thescreenischangedovertothescreenbelow.Thenpressswitch 2 toopentheRVLcheckscreen. ■... -
Page 6: Rewriting Procedure Of The Software By Means Of Ip-110
(2) Rewriting procedure of the software by means of IP-110 Fromhere,therewritingprocedureofthevariouskindsofsoftwarebyutilizingIP-0isexplained. StartwithCompactFlash(TM)insertedintoIP-0. When CompactFlash(TM) is not inserted, the machine does not work properly. 1) Common procedure TurnONthepowerandpressswitch 1 forthreeseconds. ■ Normal screen <Information switch> Thescreenchangestothescreenbelow.Thenpressswitch 2 forthreesecondstoopenthecommunication settingscreen. ■ Information maintenance level screen ■... -
Page 7: Rewriting Procedure Of The Software Of Ip-110
■ Data classification selection pop-up Thecommonprocedureisuptohere.Thenreadthedescriptionbelowfollowingtheobjecttoberewritten. RewritingthesoftwareofIP-0:referto"3. (2) 2) Rewriting procedure of the software of IP-110". Rewriting of the software of main shaft : refer to "3. (2) 3) Rewriting procedure of the software of main shaft". 2) Rewriting procedure of the software of IP-110 ■... - Page 8 ■ Program selection screen IP-110 Whenthescreenhaschangedtotheaforementionedprogramselectionscreen,pressswitch 1 andselect the program. The machine type code and RVL of the selected program are displayed on the screen. Confirm thatthemachinetypecodeandRVLoftheprogramyoudesiretowritearedisplayedandpressswitch 2 to startwriting. The screen above is the example that the program of the machine type code "IP-00-SC" and RVL "0-0-02-00"hasbeenselected.
-
Page 9: Rewriting Procedure Of The Software Of Main Shaft
3) Rewriting procedure of the software of main shaft ■ Data classification selection pop-up Pressswitch 1 in the data classification selection pop-up to select the rewriting of software of main shaft. Thenpressswitch 2 toexecutereading. ■ During reading data screen ItisthestatethattheprogramisreadfromCompactFlash(TM).Donotperformthepaneloperation. ■... - Page 10 ■ During writing screen Main shaft Theaforementionedscreenistheduringwritingscreen.Duringdisplayingtheduringwritingscreen,donot turnOFFthepower.WhenthepoweristurnedOFFduringwriting,theoperationcannotbeguaranteed. ■ Writing finish screen Main shaft When the screen has changed to the aforementioned screen, writing is finished. Turn OFF the power. Now, the software setup operation is finished. –8– –8– –8–...
