Console Screens; Login Screen - IMC Networks iMcV-E1-Mux/4 Operation Manual

Console Screens

Configuration Using the Console Port
The following section describes configuration using the console screens. The Remote
module is only configured through the Host.

Login Screen

After running through an initial self test, the log-in screen is displayed (the diagnostic
information displayed below is for illustration purposes only and may differ from the
actual screen display):
The username is case sensitive with a maximum length of 16 characters. After a
username is entered, the system prompts the end-user for a password.
Password is case sensitive with a maximum length of 16 characters. After the system
validates the username and password, the Main Menu is displayed.
14
