INSTALLING THE ACCESS CONVERTER/3

Install the Access Converter/3 as a table-top device, or mount to a wall surface with
the appropriate bracket (included). To wall mount, use the supplied screws to attach
the wall-mount bracket to the Access Converter/3, then simply mount the unit to the
wall by tightening the screws (not supplied).
The Access Converter/3 packaging also includes four small rubber "feet" for use in
table-top or wall-mount installations.
Plug the Access Converter/3 into a power source and attach the connected devices.
Verify installation by observing the LEDs on the unit (refer to the LED Operation
section for more information).
Wall Mount Bracket
Screw holes for mounting
wall-mount bracket with
supplied screws
Note
Screw holes for mounting unit to the wall.
Wall-mount bracket must be attached
to the bottom of the unit.
