Haier HWM60-Z918 User Manual

Fully automatic washing machine
Hide thumbs

Advertisement

User's Manual
Fully Automatic Washing Machine
This manual is for
HWM60-Z918
Please read this manual carefully before using.
Retain it for future reference.
Index
Safety precautions ............... 2
Packing list ........................... 4
Names of the parts............... 4
adjustment............................ 5
washing ................................. 9
to question............................ 14
Specification......................... 15

Advertisement

loading

  Related Manuals for Haier HWM60-Z918

  Summary of Contents for Haier HWM60-Z918

  • Page 1: Table Of Contents

    Preparation before washing ......... 9 Use the operation buttons ..11 Disposal after washing ..13 Trouble-shooting Answer to question......14 Specification......15 This manual is for HWM60-Z918 Please read this manual carefully before using. Retain it for future reference.
  • Page 2: Safety Precautions

    Safety precautions Meaning and description of the symbols Contents marked with that symbol are related to the safety of the product and the personal safety of the users. Please operate in strict conformity to the contents, otherwise it may cause damage of the machine or injure the personal safety WARNING of the user.
  • Page 3 In case the washing machine is installed on ground with carpet, do not block the ventilation hole with carpet. Ensure carpet does not obstruct the opening in the bases. Do not put the machine at damp place like the bathroom. Never wash it with water. Do not put wet laundries on the control panel.
  • Page 4: Packing List

    Packing list Fully automatic Water inlet hose Bottom plate Tapping screw User’s manual washing machine Warranty card Names of the parts Water inlet valve Water absorption Top lid cushion Control panel seat Liquid detergent inlet Liquid whitener inlet Power line Control panel film Hanging Back cover...
  • Page 5: Installation And Adjustment

    Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. After you open the package, please lean the washing machine gently down on soft Front items (like the towel cloth, blanket, ect.
  • Page 6 Confirm the water faucet It is required that the front end shall be longer than 10mm. The exit end face of the faucet shall be flat and smooth.If not please file it to avoid leakage. water faucet, not suitable water faucet, suitable The exit end face of the faucet Connection between the water inlet hose jointer and the water faucet...
  • Page 7: Connection Between The Water Inlet Hose And The Washer

    Connection between the water inlet hose and the washer 1.Do not take off the water absorption cushion. Please check if the cushion is dropped or damaged before nut of the water each usage. If it happens please contact our inlet hose after-sale department immediately.
  • Page 8: How To Change The Direction Of The Drain Hose

    How to change the direction of the drain hose 1.Dismantle the back cover of the washing machine. 2.Press the spring lamination lightly and pull the top Back cover segment of the drain hose decumbent then put down the drain hose from the drain hose frame. Drain hose frame 3.Put down the drain hose, squeeze the drain hose lightly and take off the hook, put the drain hose into...
  • Page 9: Preparation Before Washing

    Preparation before washing Connect the water inlet hose. Open the water faucet. Confi rm that the washing machine is earthed reliably. Then insert the power plug into the receptacle. The earth terminal shall not link to gas pipeline and faucet water pipeline. Put down the drain hose.
  • Page 10 The capacity of washing and spinning of he machine refer to the largest weight of the standard laundries under dry condition that can be washed or spinned in one time. One time washing quantity shall be lower than the rated capacity. The thickness, size, type of the cloth will influence the actual washing capacity.
  • Page 11: Use The Operation Buttons

    Use the operation buttons HOLD FLASH LIGHT SOAK MEMORY FAVOURITE REMAIN(MINUTES) WASH STANDARD HEAVY RINSE WOOL DELICATE POWER SPIN DELAY TIME TUB DRY SPEEDY START/HOLD WATER LEVEL PROGRAM PROCESS PROGRAM Program Applicable situation MEMORY The commom wash,the washing machine will set to MEMORY program including “...
  • Page 12: Finish Washing

    Push “ ” button to switch on the power Push “ ” button to select suitable automatic program SPEEDY Push “ ” button, select suitable water level After switching on the power, the washing machine will execute fuzzy program automatically to detect the cloth during the standard program. After defection, it can set the water level automatically.
  • Page 13: Disposal After Washing

    Disposal after washing Please first pull off the power plug from the receptacle before cleaning. After using, please clean the lint and foreign materials of the lint filter and overflow filter in time. Otherwise it may influence your using the machine. Clean the detergent box with water.
  • Page 14: Trouble-Shooting Answer To Question

    Trouble-shooting Answer to question (If there’s breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company.
  • Page 15: Specification

    The spinning is intermittent when it starts. Balance the laundries to avoid slanting. Push the “spin” button to select “Spin”, but it doesn’t The program is setting the drain time. Some time is work. needed before it starts spinning. The fi nal spinning is fi nished, it becomes rinsing and Because the washing clothes lean to one side,the begins to inlet water.
