GUIDE TO COMPONENTS

Operation Panel

Keys
1. Economy/Tint key
See pages 42 ~ 44.
2. Skip Feed key
See page 71.
3. Image Density key
See page 23.
4. Paste Shadow Erase key
See page 36.
5. Auto Cycle key
See page 45.
6. Master Making/Print key
Press to select Master Making or
Print mode.
7. Security key
See page 79.
8. Quality Start key
See page 80.
9. SP mode key
See page 94.
5
1
2
7
9
8 10
13 14
12
10. Edge Erase key
11. Edge Erase/Center Erase key
12. 13. 14. CS mode keys
15. 16. Scroll keys
17. Type of Original key
18. Reduce key
19. Enlarge key
3
4
11
17
15
16
See page 34.
See page 31.
See pages 97 ~ 101.
Press to select size and direction
of paper or original in Edge
Erase/Center Erase and Edge
Erase function.
Press to select the mode in Serv -
ice Program mode.
See page 40.
See page 27.
See page 29.
6
5
19
18
21
20
