For RAID Only (for AHCI Mode go to
1. Press Ctrl + i to enter RAID configuration menu.
2. Select 1.Create RAID Volume and press Enter.
3. Specify the RAID volume name and then press Tab or Enter to advance to the next field.
4. Specify the RAID level (RAID 0 or RAID 1 - see
page E - 45) and then press Tab or Enter to advance to the next field.
5. Press Enter and the system will select the physical disks to use.
"Windows Setup for RAID & AHCI Modes" on page E -
Intel(R) Matrix Storage Manager option ROM v6.0.0.1022 ICH8R wRAID5
Copyright (C) 2003-06 Intel Corporation. All Rights Reserved.
[ MAIN MENU
1. Create RAID Volume
2. Delete RAID Volume
3. Reset Disks to Non-RAID
4. Exit
[ DISK/VOLUME INFORMATION ]
RAID Volumes:
None Defined
Physical Disks:
Port Drive Model Serial #
1 HDT722516DLA380 VDK71GTE17AH6K
4 ST380811AS 5PS196TS
[ ]-Select [ESC]-Exit
Figure E - 27
- Intel(R) Matrix Storage Manager
Table E - 3, on page E - 44
]
Size Type/Status(Vol ID)
153.4GB Non-RAID Disk
74.5GB Non-RAID Disk
[ENTER]-Select Menu
