Windows XP Information
SATA RAID or AHCI Setup Procedure (BIOS)
1. Go to the operable computer running Windows XP and insert a prepared formatted blank 3.5" 1.44MB floppy
diskette.
2. Insert the Device Drivers & Utilities + User's Manual CD-ROM (WinXP) into the CD/DVD drive of the operable
computer.
3. Click Start (menu) > Run... and navigate (Browse..) to D:\Others\00RAID\F6flpy32.exe and click OK.
4. Make sure the formatted blank 3.5" 1.44MB floppy diskette i s inserted, and click OK.
5. A SATA RAID/AHCI driver diskette will now be created for you.
6. Remove the SATA RAID/AHCI driver diskette.
7. Start-up your computer and press <F2> to enter the BIOS.
8. Go to the Advanced menu.
• For RAID Mode: - Set "SATA RAID Enable"
"Enabled".
• For AHCI Mode: - Set "SATA AHCI Enable"
to "Enabled".
9. Press Esc and go to the Boot menu.
10. Set the external CD/DVD-ROM Drive (make sure the Microsoft Windows OS CD is inserted) as the first
device in the boot order from the Boot menu.
11. Attach the external USB floppy disk drive to one of the computer's USB ports.
12. Select Exit Saving Changes from the Exit menu (or press F10 and Enter) and press Enter to exit the BIOS and
reboot the computer.
E
E - 46 Setting Up SATA RAID or AHCI Modes
OR
("SATA RAID Enable: (Advanced Menu)" on page 5 -
("SATA AHCI Enable: (Advanced Menu)" on page 5 -
9) to
9)
