EUROCOM Notebook User Manual page 77

Advanced Controls
Configuring Multimonitor Displays
You can reconfigure the displays in Multimonitor mode from the Display
Properties > Settings control panel (see "Multimonitor Setting" on page 3 -
3
13). Make sure you have checked the "Extend my Windows desktop onto
this monitor." check box as illustrated in Figure 3 - 8.
Figure 3 - 8
Extended Desktop
Monitor Arrangement
Use the Display Properties control panel to drag the monitors to match the
physical arrangement you wish to use. In the example shown in Figure 3 - 8
the primary monitor is on the left, the secondary display is on the right.
1
With the Extended Desktop Mode enabled drag any icons or windows across
to the other display desktop. It is therefore possible to have one program vis-
ible in one of the displays, and a different program visible in the other display.
3 - 14 Display Options
