Model Types

In addition to the two external designs mentioned on page 1-4, this notebook
series includes three model types according to their specifications (a total of
six different combinations).
your model type:

Mobile or Desktop CPU

The computer designs incorporate both mobile and desktop CPUs. To tell if
you have a mobile or desktop CPU model, look at the DC output rating on the
bottom of the AC adapter:
• Mobile: DC-Output 20V, 3.25A, 65w
• Desktop: DC-Output 20V, 4.5A, 90w
(You can also check the heat sink type as pictured in
Removal" on page 6 - 5
CPU models.)

USB Port Type

Only Model A supports USB 2.0 and requires the driver to be installed (see
"Install Procedure" on page 4 -
pliant.
Table 1 - 1 on page 1 - 6
to differentiate between the desktop and mobile
3), while Models B & C are USB 1.1 com-
will help you identify
Figure 6 - 2b of "HDD
Introduction
AC Adapter
Warning
The AC adapter rated
at 90w (for desktop
CPU) will power a mo-
bile CPU. However,
the AC adapter rated
at 65w (for mobile
CPU) will NOT power a
desktop CPU.
Model Types 1 - 5
1
