10 SERIES
UPRIGHT BIKE
ASSEMBLY
GUIDE
PN 001-7053
REVA
(06/14/2007)
ASSEMBLY GUIDE

Advertisement

loading
Need help?

Need help?

Do you have a question about the active 10 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Schwinn active 10 Series

Summary of Contents for Schwinn active 10 Series

  • Page 1 10 SERIES UPRIGHT BIKE ASSEMBLY GUIDE ASSEMBLY GUIDE PN 001-7053 REVA (06/14/2007)
  • Page 2 © Table of Contents Exploded View ..................2 Parts List ....................:3 Hardware ....................4 Assembly Instructions ................5 AC Adapter Specifications ..............1 2...

  • Page 3: Exploded View

    EXPLODEDViEW Note. Some component images are for general reference only and may not represent the actual shape or detail of the part. Assembly is unaffected,...

  • Page 4: Parts List

    PARTSLiST Description Main Body Assembly Front Stabilizer Rear Stabilizer Console Mast Handlebar Console (Computer) Seat Post Seat Pad Left Pedal Right Pedal Seat Adjustment Knob Mast Base Seat Post Cover MSx 10ramRoundHead Phillips Screw M10 x 70ramCarriage Bolt Arc Washer ID 10.5;OD25ram:T 1.5ram M10 Acorn Nut MSx 15 Allen Head Screw Arc Washer ID 8.Smm;OD22ram;T 1.2ram...
  • Page 5 13. Seat PostCover- 1pc £} s{{_' < 15. Carriage Bolt M10 x 70mm - 4pcs < 16. Arc Washer- 4 pcs < (ID 10.Bmm;0D 2Bmm;1.Bmm) 17. Acorn Nut M10 - 4pcs 18. Allen Head Hex Screw M8 x 1Bmm-4pcs lg. Arc Washer- 4pcs (ID 8.Bmm;0D 22mm;...
  • Page 6 You will also need the following tools, which are readily available from any hardware store: Phillips screwdriver Basic Assembly Principles Here are a few basic tips that will aid in the assembly process. By using these principles, you can simplify each process and save yourself extra time and effort.
  • Page 7 Step 1 Install Front and Rear Stabilizers Parts: Tools: • Front Stabilizer (2) ,,Wrench L13 - L17 Rear Stabilizer (3) Main Body (1) Carriage Bolts - 4 (15) • ArcWashers - 4 (16) ,,Acorn Nut - 4 (17) Step 1: Secure Front Stabilizer (2) and Rear Stabilizer (3) to Main Body (1) using two Carriage Bolts (15), two ArcWashers (16), and two Acorn Nuts (17) for both Stabilizers.
  • Page 8 Step 2 Attach Front Post Parts: Tools: • Console MastWire (20) • Allen Key L6 • Main FrameWire (21) • Console Mast (4) • ArcWashers - 4 (19) • Hex Screws - 4 (18) Step 2-1: Connect Console MastWire (20) to Main FrameWire (21).
  • Page 9 Step 3 Connect Console Assembly Parts: Tools: • Console MastWire (20) • Allen Key L6 • ConsoleWire (23) • Phillips screwdriver • Console Assembly • Phillips Screws - 4 (14) Step 3-1: Connect ConsoleMastWire (20) top connector to Console Wire (23). Push connected console wires down into the hole in the top of the Console Mast (4).
  • Page 10 Step 4 Connect Contact HR and Handle Bar Parts: Tools: • Heart RateWire (24) oAllen Key L6 Handlebar • C-Ring (30) • Flat Hex Screw M8 (27) <_ =Adjustment Knob (26) Step 4-1: Using C-ring (30), Flat HeadScrew (27) and Knob (26), secure Handle Bar (5) to Console Mast (4).
  • Page 11 Step 5 Attach Seat Post and Seat © Parts: Tools: • Seat Post Cover (13) oWrench L13-L17 Seat Post (7) Seat Pad (8) Step 5-1: Side Seat Post Cover (13) over Seat Post (7). Pull out Quick Release Knob (11) and insert Seat Post (7) into Main Body (1).
  • Page 12 Step 6Attach Pedals to Cranks Parts: Tools: = Left Pedal (9) = SpannerWrench • Right Pedal (10) • Batteries Step 6-1: Install the Left Pedal (9) to Left Crank (25). Install Right Pedal (10) to the Right Crank. Note: TheLeft Peda/has a/eft handedtreadand screws into theLeft Crank counter-clockwise.
  • Page 13 NOTE: If you prefer, you may power the bike with a Class 2 © Transformer AC Adapter. The adapter plugs into the DC Connector Jack on the back of the console. © The adapter must be purchased separately and can be obtained from many electronic stores.
  • Page 14 Step 7 Final inspection Step 7-1: Please inspect your machine to ensure that all fasteners are tight and components are properly assembled. Review all warnings affixed to machine. Congratulations!Assemblyis complete! Please reference the Owner's Manual for information regarding Computer Operation, Product Maintenance, Warranty...
