Summary of Contents for Schwinn A.C. Power
- Page 1 Core Health & Fitness Schwinn® A.C.™ Power OWNER’S MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ............................. 2 PRODUCT SPOTLIGHT ............................. 3 ..................4 Features SAFETY INSTRUCTIONS ............................. 5 ..................6 Compliance and Certifications ..................7 Important Label Locations OPERATIONS ............................. 8 Locking Pop Pins / Seatpost & Handlebar Adjustment ............9 Emergency Stop ..................10 Slider Tension Knob... - Page 3 INTRODUCTION Congratulations on the purchase of a Schwinn A.C.™ Power! This manual will acquaint you with the operation, safety, and maintenance of your Schwinn® group cycling bike, and covers the following units: - A.C.™ Power & A.C.™ Power Custom 9-7300 •...
- Page 4 PRODUCT SPOTLIGHT 9-7300 A.C.™ Power 9-7300 A.C.™ Power Custom Overall Weight Width Length Height User Weight 110 lbs (50 kg) 54” (137 cm) 54” (137 cm) 51” (130 cm) 0-350 lbs (0-159 kgs) Product Conformity • EN957-1 (S,H) • EN957-10 (S,H) •...
-
Page 5: Features
Features Locking Pop Pin Seat Post Seat Slider Brake Adjustment Knob and Seat Handlebar Slider Emergency Brake Handlebar Echelon2G Console Flywheel Stabilizer Leveling Foot Transport Wheels Generator Housing Pedal with Morse Taper 4iiii Crank Page 4... - Page 6 Danger: There is risk of explosion if the battery is replaced with an incorrect type. Dispose of used batteries according to the manufacturer’s instructions. Danger: Pedals that have not been tested and qualified by Schwinn should never be used on Schwinn bikes. Unqualified pedals can lead to pedal failure and serious injury to the rider.
-
Page 7: Compliance And Certifications
Compliance and Certifications FCC Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide a reasonable protection against harmful interference in a residential installation. -
Page 8: Important Label Locations
Important Label Locations Warning Label Warning Label Serial Label Serial Label Page 7... - Page 9 Locking Pop Pins Locking Pop Pins Seatpost Seatpost To operate the features shown, see the directions on the following pages. For bike fit and coaching resources, refer to https://www.corehandf.com/schwinn-resources/ For Schwinn Group Cycle Education and Certification, refer to https://corehandf.com/certification Page 8...
-
Page 10: Locking Pop Pins / Seatpost & Handlebar Adjustment
Locking Pop Pins / Seatpost & Handlebar Adjustment 1. Turn pin counterclockwise and pull to loosen. 2. Adjust tube. Warning: Do not lift the Seatpost or Handlebar posts above the stop mark on the tube. 3. Release pin and turn clockwise to lock. Tighten knob until snug and post is secure without wobble. -
Page 11: Emergency Stop
Emergency Stop 1. Push down on red knob to stop flywheel. Page 10... -
Page 12: Slider Tension Knob
Slider Tension Knob 1. Turn pin counterclockwise to loosen. 2. Adjust slider. 3. Turn pin clockwise to lock. Tighten knob until snug and post is secure without wobble. Page 11... - Page 13 SUPPORT & SERVICE CORE Get world class support for all brands with our new support portal, Core Connect. Get help with your general inquiries, warranty registration, preventative maintenance, service requests and parts orders. You can CONNECT also make seamless service requests, get real time updates, manage your assets and intuitively order parts for all brands direct from the site.
- Page 14 PREVENTATIVE MAINTENANCE Preventive maintenance (PM) is a schedule of planned maintenance actions aimed at the prevention of failures. PM is the best way to preserve and enhance equipment reliability by keeping key com- ponents clean and free of debris. PM activities may include cleaning, vacuuming, visual inspections of key components, lubrication, etc.
- Page 15 409®. Do not spray water, or cleaner directly onto console surfaces. • Danger: Pedals that have not been tested and qualified by Schwinn should never be used on Schwinn bikes. Unqualified pedals can lead to pedal failure and serious injury to the rider. Page 14...
- Page 16 © 2019 CORE HEALTH & FITNESS, LLC PART NUMBER 620-8602, REV E...
