Bars And Beats - Euphonix R-1 Digital Multitrack Operation Manual

Euphonix Version 3 Supplement to the R-1 Operation Manual
The trackball cursor can now select Clips (punch segments) with a single click. It is now
also possible to wireframe select using the trackball and to precisely adjust Clip, selec-
tion, or track parameters in a context-sensitive Information dialog. Many edit opera-
tions are now accessed from drop-down menus, such as restoring the original recording
parameters to previously edited Clips.
Audio clips from other Titles or imported from another file format can now be placed
in tracks of the current Title.
See Chapter 5: Editing and Selection Features for complete information.
Context-Sensitive Popup Menus
Right-clicking with the trackball pointer produces context-sensitive popup menus in
several new places. Right-clicking never does anything harmful or data altering, so you
can experiment to find out how version 3.0 works. See Figure 5-5 and Figure 5-6 for
examples of the popup menus.
1.1.4

Bars and Beats

The R-1's extensive Title Time display now includes Bars, Beats, and Ticks. When
selected, the time locator accepts and displays time information in these more musically
meaningful units. A tempo map editing page permits up to 16 tempo regions per Title.
A click track can be created using one imported WAV file for the beat marks of the cur-
rent tempo map and a second WAV file for the downbeat. (See Create a Click Track on
page 23.)
9
Overview of Version 3
