Euphonix Version 3 Supplement to the R-1 Operation Manual
Patches
Once the MADI connections have been defined:
1. Click the Patches tab to save the configuration.
2. Click the New button under Patches.
3. Name your configuration.
4. Press the OK button.
You change your Patches later by selecting the Patch to change, editing, and then click-
ing Store. To recall a Patch simply select the Patch you want and click on Recall. You
can also create new, delete, or make current different configurations under the Config-
uration section of the Patches tab.
Once the configuration of your system is entered, numerous and very different routes
can be created quickly and easily. See Chapter 6: Routing for more information.
NOTE: Unlike beta-test versions of the routing application that were previously available but
not released, this application runs while the R-1 Application is still open.
Figure 1-3 Router App: Patches Dialog
13
Overview of Version 3
