  • Page 1 MVX VGA A Computer Video (VGA) and Audio Matrix Switchers 68-521-31 Rev. C 11 07...
  • Page 2 Precautions Safety Instructions • English This symbol is intended to alert the user of important operating and maintenance (servicing) instructions in the literature provided with the equipment. This symbol is intended to alert the user of the presence of uninsulated dangerous voltage within the product’s enclosure that may present a risk of electric shock.

  • Page 3: Fcc Class A Notice

    N This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense. N This unit was tested with shielded cables on the peripheral devices. Shielded cables must be used with the unit to ensure compliance. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 4: Front Panel Controls

    Quick Start — MVX VGA A Matrix Switchers Installation Step 1 Turn off power to the input and output devices, and disconnect their power cords. Step 2 — Inputs a. Connect up to 16 high resolution video inputs to the 15-pin HD input connectors. b. Connect up to 16 stereo or mono audio inputs to the 5-pin captive screw connectors. Sleeve Ring Sleeve (s) Sleeve Ring Balanced Input Unbalanced Input (high impedance) (high impedance) Step 3 — Outputs a. Connect up to 16 high resolution...

  • Page 5: Quick Start

    5. Press and release the Enter button. All input and output LEDs and the Enter LED go out. Saving or recalling a preset 1. Save a preset — Press and hold the Preset button for 2 seconds. Recall a preset — Press and release the Preset button. QS-2 MVX VGA A Matrix Switchers • Quick Start Quick Start — Save a Press and hold. preset 2 seconds PRESET Recall a Press and release.

  • Page 6: Table Of Contents

    ... 2-8 ... 3-1 ..3-2 ..3-3 ..3-7 ..3-7 ... 3-8 ... 3-15 ..3-18 ... 3-25 ..3-30 MVX VGA A Matrix Switchers • Table of Contents...
  • Page 7 Preferences.menu..5-12 Master-Reset.selection..5-12 Using.Emulation.mode Using.the.help.system Button-Label Generator Program Using.the.Button-Label.Generator.software. MVX VGA A Matrix Switchers • Table of Contents ..3-36 ... 3-37 ..3-40 ..3-41 ... 3-41 ... 3-42 ...
  • Page 8 Part Numbers and Accessories MVX.matrix.switcher.part.numbers Included.parts..A-5 Accessories..A-5 Cables..A-6 Button Labels ..A-8 ..A-5 ... A-5 MVX VGA A Matrix Switchers • Table of Contents ... 5-15...
  • Page 9 Table of Contents, cont’d 68-521-31.C 11.07 All trademarks mentioned in this manual are the properties of their respective owners. MVX VGA A Matrix Switchers • Table of Contents...

  • Page 10: Chapter One • Introduction

    MVX VGA A Matrix Switchers Chapter One Introduction About.this.Manual About.the.MVX.VGA.A.Matrix.Switchers Definitions Features...
  • Page 11 Introduction About this Manual This manual contains installation, configuration, and operating information for the Extron MVX VGA A wideband computer video (VGA) and audio matrix switchers. About the MVX VGA A Matrix Switchers The MVX matrix switchers distribute any input signal to any combination of outputs. The matrix switchers can route multiple input/output configurations simultaneously. The matrix switchers are single box solutions to complex wideband (figure 1-1) video and/or audio routing applications. Each input and output is individually isolated and buffered, and any input(s) can be switched to any one or to all outputs with virtually no crosstalk or signal noise between channels. The MVX matrix switchers are available in a variety of matrix sizes (the matrix size is the number of inputs and outputs): • MVX 128 VGA A • MVX 168 VGA A • MVX 1212 VGA A • MVX 1616 VGA A Extron VSC 500 Video Scan Converter Audio In Laptop Extron...

  • Page 12: Definitions

    Definitions The following terms, which apply to all Extron matrix switchers, are used throughout this manual: Tie — An input-to-output connection Set of ties — An input tied to two or more outputs. (An output can never be tied to more than one input.) Configuration — One or more ties or one or more sets of ties Current configuration — The configuration that is currently active in the switcher (also called “configuration 0”) Global memory preset — A configuration that has been stored. Up to 32 global memory presets can be stored in memory. Preset locations are assigned to the input buttons and output buttons. When a preset is retrieved from memory, it becomes the current configuration. The switchers have 32 presets. On the MVX 128 VGA A, up to 20 presets can be selected from the front panel for either saving or retrieving. Preset numbers larger than 20 are accessible via serial port control. MVX VGA A Matrix Switchers • Introduction...

  • Page 13: Features

    • Windows-based control program — For serial port remote control from a PC, the Extron Windows-based control software provides a graphical interface and drag-and-drop/point-and-click operation. The Windows-based control program also has an emulation mode that lets you create a switcher configuration file at the home office and then download it for use by the switcher on site. • Simple Instruction Set (SIS) — The remote control protocol uses Extron’s SIS for easy programming and operation. • Remote control panels and keypads — The matrix switchers are remote controllable, using the optional MKP 2000 and MKP 3000 remote control keypads. The remote control devices are easy to use and provide tactile buttons for quick selection. Each MKP can be used for input-to-output switching and one-touch switching for a particular output. The MKP 3000 also can be used for selection of global presets. MVX VGA A Matrix Switchers • Introduction...
  • Page 14 Global memory presets — 32 global memory presets are a time-saving feature that lets you set up and store input/output configurations in advance. You can then recall those configurations, when needed, with a few simple steps on the front panel. For the MVX 128 A, which has fewer input and output buttons, 20 global memory presets are available from the front panel; the remaining presets are available via serial port control. Rack mounting — Rack mountable in any conventional 19" wide rack. Three front panel security lockout modes (Executive modes) — If a matrix switcher is installed in an open area, where operation by unauthorized personnel may be a problem, either of two security lockout modes can be implemented (the third mode is unlocked). When a front panel locked mode is enabled, a special button combination or SIS command is required to unlock the front panel controller and make the front panel fully operational. Power — The matrix switcher’s 100 VAC to 240 VAC, autoswitchable, internal power supply provides worldwide power compatibility. MVX VGA A Matrix Switchers • Introduction ® P-Touch ™ or comparable labeler.
  • Page 15 Introduction, cont’d MVX VGA A Matrix Switchers • Introduction...

  • Page 16: Chapter Two • Installation

    MVX VGA A Matrix Switchers Chapter Two Installation Mounting.the.Switcher Rear.Panel.Cabling.and.Views Front.Panel.Configuration.Port...

  • Page 17: Ul.requirements

    (+50 °C) ambient temperature (Tma) specified by Extron. Reduced air flow — Install the equipment in a rack so that the amount of air flow required for safe operation of the equipment is not compromised. Mechanical loading — Mount the equipment in the rack so that a hazardous condition is not achieved due to uneven mechanical loading. Circuit overloading — Connect the equipment to the supply circuit and consider the effect that circuit overloading might have on overcurrent protection and supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern. Reliable earthing (grounding) — Maintain reliable grounding of rack- mounted equipment. Pay particular attention to supply connections other than direct connections to the branch circuit (e.g., use of power strips). Mounting instructions The MVX VGA A matrix switchers are housed in a rack-mountable, 2U (MVX 128 VGA A) or 3U (all other models) high metal enclosures with mounting flanges for standard 19" racks. If desired, rack mount the switcher as follows: Insert the switcher into the rack, aligning the holes in the mounting bracket with those in the rack. Secure the switcher to the rack using the supplied bolts. MVX VGA A Matrix Switchers • Installation...

  • Page 18: Rear Panel Cabling And Views

    Remove system power before making all connections. INPUTS A na he im, C A LISTED 1T23 ® I.T.E. SYNC IMPEDANCE 1 2 3 4 5 6 7 8 OUTPUT OUTPUT MVX VGA A Matrix Switchers • Installation COMPUTER OUT OUTPUTS COMPUTER OUT COMPUTER OUT...

  • Page 19: Video.connections

    Figure 2-3 — Sync Impedance switches Each switch provides the option of selecting either 50 ohms or 75 ohms. The 50 ohms position is required only when a sync problem is encountered. The normal position is 75 ohms. N An input producing an out-of-sync display — a display that is rolling vertically and/or tearing horizontally — could indicate an impedance problem. MVX VGA A Matrix Switchers • Installation 6 7 8...

  • Page 20: Audio.connections

    The audio level for each input can be individually set via the front panel or serial port control to ensure that the level on the output does not vary from input to input. See chapter 3, “Operation”, chapter 4, “Programmer’s Guide”, and chapter 5, “Matrix Software”, for details. Sleeve Ring Sleeve (s) Sleeve Ring Balanced Stereo Input Unbalanced Stereo Input (high impedance) (high impedance) Tip (+) Ring (-) Sleeve ( ) 3.5 mm Stereo Plug Connector (balanced) MVX VGA A Matrix Switchers • Installation...

  • Page 21: Rs-232/Rs-422.Connection

    RS-232/RS-422 port from the front panel. If desired, connect an MKP 2000 or MKP 3000 remote control panel to the switcher’s RS-232/RS-422 connector. Refer to the MKP 2000 Remote Control Panel User’s Manual or the MKP 3000 Remote Control Panel User’s Manual for details. MVX VGA A Matrix Switchers • Installation NO GROUND HERE. Sleeve(s) NO GROUND HERE. Unbalanced Stereo Output Connect the sleeve to ground (Gnd).

  • Page 22: Reset Button

    See “Rear Panel Operations” in chapter 3, “Operation”, for details. • Rear panel (mode 5) system reset — Press and hold the Reset button until the Reset LED blinks three times (approximately 9 seconds), then release the button and press it again. This reset clears all ties and presets and resets all audio gains to 0 dB. • Hard reset — Press and hold the Reset button while powering up the switcher to restore the switcher to the default factory conditions. N Hard reset does not clear the current configuration. Power connection AC power connector — Plug a standard IEC power cord into this connector to connect the switcher to a 100 VAC to 240 VAC, 50 or 60 Hz power source. MVX VGA A Matrix Switchers • Installation RESET...

  • Page 23: Front Panel Configuration Port

    Distances of about 50 feet (15 m) are typically not a problem. In some cases the matrix switcher may be capable of serial communications via RS-232 up to 250 feet (76 m) away. MVX VGA A Matrix Switchers • Installation VIEW RGBHV...

  • Page 24: Chapter Three • Operation

    MVX VGA A Matrix Switchers Chapter Three Operation Front.Panel.Controls.and.Indicators Front.Panel.Operations Rear.Panel.Operations Optimizing.the.Audio Troubleshooting Configuration.Worksheets...

  • Page 25: Front Panel Controls And Indicators

    Configuration — One or more ties or one or more sets of ties Current configuration — The configuration that is currently active in the switcher (also called “configuration 0”) Global memory preset — A configuration that has been stored. Up to 32 global memory presets can be stored in memory. Preset locations are assigned to the input buttons and output buttons. When a preset is retrieved from memory, it becomes the current configuration. The switchers have 32 presets. On the MVX 128 VGA A, up to 20 presets can be selected from the front panel for either saving or retrieving. Preset numbers larger than 20 are accessible via serial port control. MVX VGA A Matrix Switchers • Operation INPUTS OUTPUTS CONTROL ENTER PRESET VIEW VIDEO AUDIO CONFIG MVX SERIES VGA MATRIX SWITCHER ADPS™...

  • Page 26: Input.and.output.buttons

    ❏ Display the audio level of the selected input. See “Viewing and adjusting the input audio level” on page 3-25. ❏ Select a preset. See “Using global presets” on page 3-21. Input and output label windows — These translucent panels can be removed and replaced to insert labels behind them. To remove a panel, insert the Phillips-head end of a Tweeker or a small Phillips-head screwdriver into the hole in one end of the panel, and gently slide the tab at the edge of the panel out of the recess in the switcher housing. Input and output labels can be created easily with Extron’s button label generator software, is shipped with every Extron matrix switcher, or with any Brother P-Touch labeler. Each input and output can be labeled with names, ® ™ alphanumeric characters, or even color bitmaps for easy and intuitive input and output selection (figure 3-2). See chapter 5, “Matrix Software”, for details on using the label software. Rack DVD (ISS 506) Figure 3-2 — Sample label MVX VGA A Matrix Switchers • Operation INPU...

  • Page 27: Control.buttons

    Preset button and/or LED — The Preset button and LED have two primary functions (•) and three secondary functions (❏): • Activates Save Preset mode to save a configuration as a preset and Recall Preset mode to activate a previously-defined preset. • Blinks when Save Preset mode is active and lights steadily when Recall Preset mode is active. With the Enter, View, and Esc buttons, selects Serial Port Configuration ❏ mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-38. Selects 19200 baud for the Remote port in Serial Port Configuration mode. ❏ See “Selecting the rear panel Remote port protocol and baud rate” on page 3-38. Indicates that the Remote port is set to 19200 baud in Serial Port ❏ Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-38. MVX VGA A Matrix Switchers • Operation Specify RGBHV, audio, or both (see I/O selection buttons [ Press the desired input button ( Press the desired output button(s) ( Press the Enter button. ] and...
  • Page 28 • Flashes once to indicate that the escape function has been activated. ❏ Increases the audio level of the selected input. See “Viewing and adjusting the input audio level” on page 3-25. ❏ Indicates a positive (gain) audio level. See “Viewing and adjusting the input audio level” on page 3-25. ❏ Increases the volume of the selected output. See “Viewing and adjusting the output volume” on page 3-30. ❏ With the Enter, Preset, and View buttons, selects Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-38. ❏ Selects 115200 baud for the Remote port in Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-38. ❏ Indicates that the Remote port is set to 115200 baud in Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-38. MVX VGA A Matrix Switchers • Operation < ) button and LED have two > ) button and LED have two primary...

  • Page 29: I/O.controls

    • Selects and deselects audio for a configuration that is being created or viewed. • Lights to indicate that audio is available for configuration or viewing. ❏ Selects the Audio mode, in which you can adjust the input audio level. See “Viewing and adjusting the input audio level” on page 3-25. ❏ With the Enter button and RGBHV button, selects between front panel locks (Lock mode 2 and Lock mode 0). See “Setting the front panel locks (Executive modes)” on page 3-36. ❏ With the RGBHV button, selects between front panel locks (Lock mode 2 and Lock mode 1). See “Setting the front panel locks (Executive modes)” on page 3-36. ❏ With the RGBHV button, initiates the front panel system reset. See “Performing a system reset from the front panel” on page 3-37. ❏ Selects the RS-422 protocol for the Remote port in Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-38. ❏ Indicates that the Remote port is set to the RS-422 protocol in Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-38. MVX VGA A Matrix Switchers • Operation ) and Audio ( ) buttons.

  • Page 30: Front Panel Operations

    • Lock mode 1 — All changes are locked from the front panel (except for setting Lock mode 2). Some functions can be viewed. • Lock mode 2 — Advanced features are locked and can be viewed only. Basic functions are unlocked. N The switcher is shipped from the factory in Lock mode 2. See “Setting the front panel locks (Executive modes)” on page 3-36 for a detailed list of basic and advanced functions and the procedure to set the various front panel locks. Power Apply power by connecting the power cord to an AC source. When AC power is applied, the switcher performs a self-test that flashes the front panel LEDs and then turns them off. An error-free power up self-test sequence leaves the RGBHV LED and the Audio LED on, and all other LEDs unlit. The current configuration and all presets are saved in non-volatile memory. When power is applied, the most recent configuration is retrieved. The previous presets remain intact. If an error occurs during the self-test, the switcher locks up and does not operate. If your switcher locks up on power-up, call the Extron S Hotline. Sales & Technical Support MVX VGA A Matrix Switchers • Operation...

  • Page 31: Creating.a.configuration

    • • • MVX VGA A Matrix Switchers • Operation Only one video input and one audio input can be tied to an output. If a tie is made between an input and an output, and the selected output was previously tied to another input, the older tie is broken in favor of the newer tie.

  • Page 32: Example 1: Creating A Set Of Video And Audio Ties

    Press and release the Input 5 button. The Input 5 LED lights. Figure 3-5 — Select an input MVX VGA A Matrix Switchers • Operation RGBHV AUDIO Press the Audio button to toggle on and off. The LED lights when selected.
  • Page 33 Input 5 (video and audio) is tied to output 3, output 4, and output 8. Input 5 (video/audio) tied Figure 3-8 — Example 1, final configuration 3-10 MVX VGA A Matrix Switchers • Operation OUTPUTS The Enter LED and all input LEDs and output LEDs return to the unlit state. to outputs 3, 4, and 8...

  • Page 34: Example 2: Adding A Tie To A Set Of Video And Audio Ties

    The Output 3, Output 4, and Output 8 LEDs light to indicate the RGBHV ties created in example 1. OUTPUTS OUTPUTS MVX VGA A Matrix Switchers • Operation ENTER PRESE The Enter LED blinks to indicate the need to confirm the change.
  • Page 35 • Input 5 (audio) is tied to output 3, output 4, and output 8. Figure 3-14 — Example 2, final configuration 3-12 MVX VGA A Matrix Switchers • Operation The Enter LED and all input LEDs and output LEDs return to the unlit state. Input 5 video tied to outputs 1, 3, 4, and 8...

  • Page 36: Example 3: Removing A Tie From A Set Of Video And Audio Ties

    The Output 3, Output 4, and Output 8 LEDs light to indicate the audio ties created in example 1. The output 1 LED does not light to indicate the tie created in example 2 because that tie is RGBHV only. OUTPUTS MVX VGA A Matrix Switchers • Operation 3-13...
  • Page 37 • Audio — Input 5 (audio) is tied to output 3 and output 8. (Input 5 audio is no longer tied to output 4.) Figure 3-20 — Example 3, final configuration 3-14 MVX VGA A Matrix Switchers • Operation OUTPUTS The Enter LED and all input LEDs and output LEDs return to the unlit state. Input 5 video tied to outputs 1, 3, 4, and 8...

  • Page 38: Viewing.a.configuration

    N This example assumes that you have performed example 1, example 2, and example 3. Press and release the Esc button (figure 3-21). Press the Esc button to clear all selections. CONTROL ENTER PRESET VIEW = LED blinks once. Figure 3-21 — Clear all selections Press and release the View button to enter View-only mode. The View LED lights. The LED blinks once. MVX VGA A Matrix Switchers • Operation 3-15...
  • Page 39 LEDs light for all of the outputs that are tied to the input. 3-16 MVX VGA A Matrix Switchers • Operation In this example, the Audio LED blinks to indicate audio breakaway (assuming you have performed examples 1, 2, and 3).
  • Page 40 The output buttons for outputs that are tied to input 5 light to indicate audio ties (audio breakaway). OUTPUTS The output buttons for outputs that are not tied to input 5 are unlit. OUTPUTS MVX VGA A Matrix Switchers • Operation 3-17...

  • Page 41: Muting.and.unmuting.video.and/Or.audio

    Figure 3-27 — Clear all selections Press and release the View button to enter View-only mode. The View LED lights. 3-18 MVX VGA A Matrix Switchers • Operation You can mute video and audio, video-only, or audio-only outputs. Pressing and releasing the RGBHV button and the Audio button toggles each selection on and off.
  • Page 42 Output 4 buttons. The LEDs blink to indicate that the RGBHV and audio outputs are muted. Release the buttons. = Blinking LED Figure 3-29 — Mute the outputs MVX VGA A Matrix Switchers • Operation OUTPUTS OUTPUTS 2 seconds OUTPUTS 3-19...
  • Page 43 View-Only mode. CONTROL SET VIEW Figure 3-31 — Press the View button to exit View-only mode 3-20 MVX VGA A Matrix Switchers • Operation Press and hold the Output 3 and Output 4 buttons. OUTPUTS 2 seconds OUTPUTS that the RGBHV and audio outputs are unmuted.

  • Page 44: Using Global Presets

    OUTPUTS Preset Preset Preset Preset Preset Preset Preset Preset Preset Preset Preset INPUTS OUTPUTS Preset Preset Preset Preset Preset Preset Preset MVX VGA A Matrix Switchers • Operation Preset Preset Preset Preset Preset Preset Preset Preset 3-21...

  • Page 45: Example 6: Saving A Preset

    Preset 13 Preset 14 = Blinking LED Figure 3-36 — Select the preset 3-22 MVX VGA A Matrix Switchers • Operation CONTROL The LED blinks once. All input and output LEDs with assigned presets light. If you then save the configuration to a lit preset number, the configuration data at that preset location is overwritten.

  • Page 46: Example 7: Recalling A Preset

    Press and release the Preset button (figure 3-39). Press and release the Preset button. The Preset LED lights. PRESET Figure 3-39 — Enter Recall Preset mode MVX VGA A Matrix Switchers • Operation All input LEDs return to the unlit state. All input and output LEDs with assigned presets light.
  • Page 47 ENTER PRESET VIEW The Enter and Preset LEDs return to the unlit state. Figure 3-41 — Press the Enter button 3-24 MVX VGA A Matrix Switchers • Operation ENTER PRESET VIEW Preset 15 Preset 16 The Enter LED blinks to indicate the need to recall the preset.

  • Page 48: Viewing And Adjusting The Input Audio Level

    Or, press and hold either button to change the level at a rate of 3 dB per second until the button is released or the upper or lower limit is reached. Output Level CONTROL VIDEO AUDIO ENTER PRESET VIEW MVX SERIES VGA MATRIX SWITCHER WITH ADSP No noticeable volume differences between sources < ) LEDs display the polarity (gain [+] or attenuation > ) and View ( < ) buttons to increase and decrease MVX VGA A Matrix Switchers • Operation Audio System 3-25...

  • Page 49: Example 8: Viewing And Adjusting An Input Audio Level

    = Blinking LED Figure 3-44 — Select Audio mode 3-26 MVX VGA A Matrix Switchers • Operation Pressing the Enter or Preset button also exits Audio mode. Pressing the Preset button changes to Recall Preset mode. There is one audio level setting per input. The audio level setting is shared by the left and right audio inputs.
  • Page 50 Audio input level settings MVX 128 A Output LED View Esc MVX VGA A Matrix Switchers • Operation MVX 1212, 168, 1616 A Output LED = on, = blinking fast, = blinking slowly, View Esc = off 3-27...
  • Page 51 Figure 3-46 — Level display on a 16-output-LED switcher Press and release the View ( audio level by 1 dB. Press and release the View ( decrease the input audio level by 1 dB per button push. Note the output button indication changes that occur each time the View ( 3-28 MVX VGA A Matrix Switchers • Operation Press and release the Input 5 button. The LED lights. OUTPUTS F = Fast blinking LED < ) button once (figure 3-47) to decrease the input <...
  • Page 52 The RGBHV button lights. Figure 3-49 — Deselect Audio mode < ) button a total of nine The View and Esc LEDs display the polarity (gain or attenuation). MVX VGA A Matrix Switchers • Operation VIEW The View and Esc LEDs display the polarity (gain or attenuation). 3-29...

  • Page 53: Viewing And Adjusting The Output Volume

    N • • • • 3-30 MVX VGA A Matrix Switchers • Operation > < ) and View ( ) buttons to increase and decrease There is one audio volume level setting per output. The audio level setting is shared by the left and right audio inputs.

  • Page 54: Reading The Displayed Volume

    Switchers with 12 input buttons —The Input 1 through 4 LEDs light  steadily. Switchers with 16 input buttons — The Input 1 through 5 LEDs light  steadily and the Input 6 button blinks. When all input LEDs are lit for any switcher model, the audio output is 100% of the audio input level. Another way to view the volume level is to think in terms of the attenuation that is applied to the output. Attenuation reduction is indicated by the lit or blinking input LEDs: when fewer input LEDs are lit, attenuation is greater (and the volume is quieter). • At minimum volume, all input LEDs are unlit and 76 dB of attenuation is applied to the output. The audio output is effectively muted. • The first step of volume increase causes the Input 1 LED to blink (slowly, in the case of switchers with 12 input buttons). Attenuation is reduced by 13 dB (63 dB of attenuation is applied to the output). • The second step of volume increase reduces the attenuation by an additional 1 dB (62 dB of attenuation is applied to the output). • Successive steps of volume increase cause consecutive LEDs to first blink, then light steadily. MVX VGA A Matrix Switchers • Operation 3-31...
  • Page 55 86.5% 89.5% 92.5% 95.5% 98.5% 100% = on, = blinking fast, = blinking slowly, 3-32 MVX VGA A Matrix Switchers • Operation MVX 1212 A, MVX 168 A, MVX 1616 A Output dB of volume attenuation 5.5% 8.5% 11.5% 14.5% 17.5%...

  • Page 56: Example 9: Viewing And Adjusting An Output Volume Level

    Figure 3-50 — Clear all selections Press and hold the Audio button for approximately 2 seconds (figure 3-51). Press and hold the Audio button. 2 seconds RGBHV AUDIO The LED blinks to indicate Audio mode. = Blinking LED Figure 3-51 — Select Audio mode MVX VGA A Matrix Switchers • Operation AUDIO Release the button. 3-33...
  • Page 57 N You can press and hold the Esc ( down by 3 dB per second to the high or low limit. 3-34 MVX VGA A Matrix Switchers • Operation 39 dB attenuation, 41.5% volume INPUTS = Slow blinking LED...
  • Page 58 RGBHV AUDIO The Audio LED stops blinking and lights steadily. The RGBHV button lights. Figure 3-56 — Deselect Audio mode > ) button a total of 13 times. 26 dB attenuation, 61% volume INPUTS = Slow blinking LED MVX VGA A Matrix Switchers • Operation 3-35...

  • Page 59: Setting The Front Panel Locks (Executive Modes)

    Lock mode 2 or to toggle between mode 2 and mode 0. ENTER Figure 3-57 — Toggle front panel lock on or off 3-36 MVX VGA A Matrix Switchers • Operation 2 seconds RGBHV AUDIO ENTER RGBHV AUDIO...

  • Page 60: Selecting.lock.mode.2.Or.toggling.between.mode.2.And.mode.1

    RGBHV and Audio LEDs turn on. Release the RGBHV and Audio buttons. Figure 3-59 — System reset The RGBHV and Audio LEDs blink twice to indicate the mode change. Release the buttons. RGBHV AUDIO ZXXX SIS command (see chapter 4, Power MVX VGA A Matrix Switchers • Operation 3-37...

  • Page 61: Selecting.the.rear.panel.remote.port.protocol.and.baud.rate

    If front panel Lock mode 2 is selected and you try to perform step 3 (on the next page), the actions are ignored; and the Enter, RGBHV, and Audio LEDs flash. 3-38 MVX VGA A Matrix Switchers • Operation CONTROL ENTER PRESET VIEW All Control LEDs light with one LED flashing.
  • Page 62 N The switcher requires some time to save the new serial port settings. Wait at least 5 minutes before removing power from the switcher, or the settings may be lost. MVX VGA A Matrix Switchers • Operation RGBHV AUDIO CONTROL RGBHV AUDIO Each I/O LED returns to its previous state.

  • Page 63: Rear Panel Operations

    Reset button. = blink three times, Figure 3-63 — System reset Release the Reset button and then immediately press and release the Reset button again. The reset does not occur if the second momentary press does not occur within 1 second. 3-40 MVX VGA A Matrix Switchers • Operation ZQQQ SIS command (see Reset LED blinks three times. Release, then immediately 9 seconds RESET press and release again.

  • Page 64: Performing A Hard Reset From The Rear Panel

    Optimizing the Audio Each individual input audio level can be adjusted within a range of -18 dB to +24 dB, so there are no noticeable volume differences between sources and for the best headroom and signal-to-noise ratio. Adjust the audio gain and attenuation as follows: Connect audio sources to all desired inputs and connect the audio outputs to output devices such as audio players. See “Audio connections”, in chapter 2, “Installation”. For best results, wire all of the inputs and the outputs as balanced. Power on the audio sources, the switcher, and the audio players. Switch among the inputs (see “Creating a configuration”, on page 3-8), listening to the audio with a critical ear or measuring the output audio level with test equipment, such as a VU meter. As necessary, adjust the input audio level of each input (see “Viewing and adjusting the input audio level”, on page 3-25) so that the approximate output level is the same for all selected inputs. As necessary, adjust the output audio level of each input (see “Viewing and adjusting the output volume”, on page 3-30). RESET RESET Release the Reset button. MVX VGA A Matrix Switchers • Operation Power 3-41...

  • Page 65: Troubleshooting

    Indicate if the configuration is for video, audio, or both. Figure 3-65 — Worksheet example 1: System equipment Inputs include PCs, an audio CD player, cameras, and an Extron VTG 300. Output devices include monitors, front and rear projectors, a stereo, and a VCR for recording presentations. The VTG 300 video test generator connected to input 12 enables a video test pattern to be sent to one, several, or all output devices for problem isolation or adjustment purposes. An audio test tape or CD could be used in a similar manner to check out the audio components. 3-42 MVX VGA A Matrix Switchers • Operation Sales & Technical Support Hotline if necessary. Input sources Classroom Classroom Laptop Rack DVD #1 VCR #2 VCR RGB 202...

  • Page 66: Worksheet Example 2: Daily Configuration

     Played in the lobby (output 8)  Input sources Classroom Classroom Laptop Rack DVD #1 VCR #2 VCR RGB 202 (USP 405) USP 405 USP 405 DA 6 (VSC 500) Output destinations Video: Audio: MVX VGA A Matrix Switchers • Operation VTG 300 3-43...

  • Page 67: Worksheet Example 3: Test Configuration

    Fill in the preset number and use colors, dashes, etc., to make connecting lines. Indicate if the configuration is for video, audio, or both. Figure 3-67 — Worksheet example 3: Test configuration 3-44 MVX VGA A Matrix Switchers • Operation Input sources Classroom Classroom...
  • Page 68 MVX VGA A Matrix Switchers • Operation 3-45...
  • Page 69 Operation, cont’d 3-46 MVX VGA A Matrix Switchers • Operation...

  • Page 70: Chapter Four • Programmer's Guide

    MVX VGA A Matrix Switchers Chapter Four Programmer’s Guide Serial.Ports Host-to-Switcher.Instructions Switcher-Initiated.Messages Switcher.Error.Responses Using.the.Command/Response.Table Command/Response.Table.for.SIS.Commands...

  • Page 71: Serial Ports

    See “Selecting the rear panel Remote port protocol and baud rate” in chapter 3, “Operation”, to configure the rear panel Remote port from the front panel. MVX VGA A Matrix Switchers • Programmer’s Guide • no parity • 8-bit • no flow control...

  • Page 72: Front.panel.configuration.port

    ), which signals the end of the response character string. A string is one or more characters. Switcher-Initiated Messages When a local event such as a front panel operation occurs, the switcher responds by sending a message to the host. The switcher-initiated messages are listed below (underlined). (C) Copyright 2006, Extron Electronics CP 300 450 MAV IP, Vx.xx, 60-nnn-01 The switcher initiates the copyright message when it is first powered on. Vx.xx is the firmware version number; nnn is the part number for your switcher model. The switcher initiates the Qik message when a front panel switching operation has occurred. Sprnn The switcher initiates the Spr message when a memory preset has been saved from the front panel. nn is the preset number. Rprnn The switcher initiates the Rpr message when a memory preset has been recalled from the front panel. nn is the preset number. MVX VGA A Matrix Switchers • Programmer’s Guide 6 feet (1.8 m) Part #70-335-01 Ring Sleeve (Gnd) TRS Plug Ring Sleeve...

  • Page 73: Switcher Error Responses

    The switcher initiates the Exe message when executive mode is toggled on or off from the front panel. n is the executive mode status: 1 = on, 0 = off. Switcher Error Responses When the switcher receives an SIS command and determines that it is valid, it performs the command and sends a response to the host device. If the switcher is unable to perform the command because the command is invalid or contains invalid parameters, the switcher returns an error response to the host. The error response codes are: E01 — Invalid input channel number (too large) E10 — Invalid command E11 — Invalid preset number E12 — Invalid output number (too large) E13 — Invalid value (out of range) E14 — Illegal command for this configuration E17 — Timeout (caused only by direct write of global presets) E22 — Busy Using the Command/Response Table The command/response table begins on page 4-6. Lower-case letters are acceptable in the command field except where indicated for the gain and attenuation commands. The table below shows the hexadecimal equivalent of each ASCII character used in the command/response table. ASCII to HEX Conversion Table Space MVX VGA A Matrix Switchers • Programmer’s Guide...

  • Page 74: Command/Response Table For Sis Commands

    = Temperature 01 – 16 00 – 16 (00 = untied) 01 – 16 –18 to +24 (45 steps of gain or attenuation) (fefault = 0 dB) 0 – 24 (1 dB/step) 1 – 18 (1 dB/step) 0 – 64 (1 dB/step except for 0-to-1, which is 13 dB) (default = 64 [0dB]) (See the table on page 4-8.) 0 = off/mode 0/not OK 1 = on/mode 1/OK 2 = mode 2 0 - 32 (0 = current configuration) 0 = no mute 1 = video mute 2 = audio mute 3 = video and audio mute 12 characters maximum for input, output, and global preset names Upper- and lower-case alphanumeric characters and _ / and spaces are valid. 1 (front) or 2 (rear) 9600, 19200, 38400, 115200 Odd, even, none, mark, space (Only the first letter is required.) 7, 8 1, 2 0 = RS-232, 1 = RS-422 12 or 16 8, 12, or 16 68-nnn-nn Positive or negative voltage and magnitude Degrees Fahrenheit MVX VGA A Matrix Switchers • Programmer’s Guide...

  • Page 75: Command/Response Table For Sis Commands

    N The & read tie command for RGB and the % read tie command for video can be used interchangeably on the matrix switchers. Read RGB output tie & Read video output tie Read audio output tie MVX VGA A Matrix Switchers • Programmer’s Guide Response (switcher to host) • • Out03 •...

  • Page 76: Audio Output Volume

    Aud-09 X#• X&] • Out01 Vol50 X#• X&] • Out01 Vol51 X#• X&] X&] Amt1 Amt0 MVX VGA A Matrix Switchers • Programmer’s Guide Additional description Mute output RGB (video off). Unmute output RGB (video on). 1 = mute on, 0 = mute off. Mute all RGB outputs. Unmute all RGB outputs. Set input 1 audio gain to +2 dB. Increase gain by 1 dB. Increase Audio input 5 level from +2 dB to +3 dB.
  • Page 77 Output value attenuation volume 5.5% 8.5% 11.5% 14.5% 17.5% 20.5% 23.5% 26.5% 29.5% 32.5% 35.5% MVX VGA A Matrix Switchers • Programmer’s Guide dB of Output value attenuation volume 38.5% 41.5% 44.5% 47.5% 50.5% 53.5% 56.5% 59.5% 62.5% 65.5% 68.5%...
  • Page 78 [unassigned]. X! , X1#] Nmi01 Podium cam X1#] X! , X1#} Nmo01,Main PJ1 X1#] Spr9 Rpr05 $ ... & Spr27 Spr27 MVX VGA A Matrix Switchers • Programmer’s Guide Additional description Name global preset 1 “Security 1”. Name input 1 “Podium cam”. Name output 1 “Main PJ1”. Command character is a comma. Save current ties as preset 9. Command character is a period. Recall preset 5, which becomes the current configuration.
  • Page 79 View RGBHV output tie & Example: 5& View video output tie Example: View audio output tie Example: View input gain Example: View output volume Example: View output mutes Example: 4-10 MVX VGA A Matrix Switchers • Programmer’s Guide Response (switcher to host) Exe1 Exe2 Exe0 X&] , ... 02301000 Additional description Enable Lock mode 1. Enable Lock mode 2. Enable Lock mode 0. Clear all global presets and their names.

  • Page 80: Serial Port Configuration

    Output: 02 03 04 05 06 07 08 09 10 11 12 X1& •Ccp X1& X1*] X1(] Cpn1•Cty X1(] MVX VGA A Matrix Switchers • Programmer’s Guide Additional description Show preset ’s video configuration. Show the input tied to 16 sequential outputs. •Vid 13 14 15 16 Show preset ’s audio...
  • Page 81 Meaningless data MVX firmware version for this switcher model Request system status Response description: +3.3V•+5V•-5V•+15V•-15V•temperature (degrees fahrenheit) Example: 3.3V power system at 3.29V 4-12 MVX VGA A Matrix Switchers • Programmer’s Guide Response (switcher to host) X2!] •A X2@] X1!] 1.23 X1@]...

  • Page 82: Chapter Five • Matrix Software

    MVX VGA A Matrix Switchers Chapter Five Matrix Software Matrix.Switchers.Control.Program Button.Label.Generator.Program.

  • Page 83: Installing The Software

    N For full functionality, install both of the following programs: • • Insert the CD-ROM into the drive. The installation program should start automatically. If it does not self-start, run Launch.exe from the CD. The Extron software CD window appears (figure 5-1). Figure 5-1 — Software CD window Click the Software tab (figure 5-1). Scroll to the desired program and click Install (figure 5-2). Figure 5-2 — Software installation MVX VGA A Matrix Switchers • Matrix Software The Matrix Switchers Control Program The Firmware Loader...

  • Page 84: Using The Matrix Switcher Control Software

    Serial port configuration commands on page 4-11 to configure either port using an SIS command. Using the Matrix Switcher Control software Many items found in the Matrix Switcher Control Program are also accessible via front panel controls (see chapter 3, ”Operation”) and under SIS control (see chapter 4, “Programmer’s Guide”). The Matrix Switcher+ Help Program provides information on settings and on how to use the control program itself. To run the Matrix Switcher Control Program, click Start > Programs > Extron Electronics > Matrix Switchers > MATRIX Switcher + Control Pgm. The Comm Port Selection window (figure 5-3) appears. Figure 5-3 — Comm port selection window MVX VGA A Matrix Switchers • Matrix Software...
  • Page 85 “Operation”, on page 3-38, to identify the selected baud rate from the front panel. Click OK and proceed to step 3. If you selected Emulate, click OK and see “Using Emulation mode” on  page 5-13. The Extron Matrix Switcher Control Program window (figure 5-4 and figure 5-5) appears. The window displays the current configuration of the attached matrix. Figure 5-4 — Extron Matrix Switcher Control Program window (blank) MVX VGA A Matrix Switchers • Matrix Software...
  • Page 86 Figure 5-5 — Sample program window (complete) • To set up audio in Follow mode (audio and video have the same tie configuration), select the Follow checkbox at the bottom of the window. To set up audio in breakaway mode (audio and video have different tie configurations), deselect the Follow checkbox. • To make the control program easier to use, assign a device icon to each input and output. Click on a box that represents an input or output, and drag the desired icon onto the box from the icon palette that appears. • To create a tie, drag an input box to one or more output boxes. To remove a tie, drag the output box to its tied input box or to the trash can. • For quick display of information on a specific input or output device, position the cursor over that device in the control program window. The program opens a window that details the connections to that device, the audio level, and the frequency of the video signal input from or output to that device. See the inset box in figure 5-5. MVX VGA A Matrix Switchers • Matrix Software...

  • Page 87: Updating.firmware

    Visit the Extron Web site, www.extron.com, click the Download Center tab, and then click the Firmware link (figure 5-6). Figure 5-6 — Location of firmware upgrade files Select the appropriate firmware file (CrossPoint 300 Series/ MVX 128/1212/168/1616 VGA A) to download and click Download. Enter the requested personal information and then click Download to copy the firmware to your computer. Click Run twice (figure 5-7). The PC downloads the firmware update from the Extron Web site and starts the Extron Installation Program to extract the firmware file. Click Next. The program extracts the firmware files and places them in a folder identified in the InstallShield Wizard window. N Note the folder to which the firmware file is saved. Click Finish to exit the program. MVX VGA A Matrix Switchers • Matrix Software...
  • Page 88 Figure 5-7 — Downloading firmware upgrade files MVX VGA A Matrix Switchers • Matrix Software Folder where firmware is installed.
  • Page 89 N The original factory-installed firmware is permanently available on the MVX matrix switcher. If the attempted firmware upload fails for any reason, the switcher reverts to the factory-installed firmware. MVX VGA A Matrix Switchers • Matrix Software...
  • Page 90 If you are no longer able to communicate with the switcher after the firmware upload completes, see “Selecting the rear panel Remote port protocol and baud rate” in chapter 3, “Operation”, on page 3-38. MVX VGA A Matrix Switchers • Matrix Software...

  • Page 91: Windows Buttons, Drop Boxes, And Trash Can

    Save matrix settings as ... — Saves a complete set of up to 32 presets, plus the last active setting (preset #0), to a file. Saved settings include audio gain settings (if specified), assigned icons, and icon captions. Restore matrix settings from ... — Loads and activates a previously saved setting file. Save this-session’s settings — Saves the current assigned icons and icon captions. Restore last-session’s settings — Loads the icons and icon captions that were saved during the last session. If you saved the previous session’s changes to disk the last time you exited the program, the ties from that session are also loaded. Select printer — Selects the target printer. Print tie map — Prints the tie set that is displayed on the screen. Exit — Closes the Matrix Switcher Control Program. 5-10 MVX VGA A Matrix Switchers • Matrix Software...

  • Page 92: Tools Menu

    N The following characters are invalid in preset names: + ~ , @ = ‘ [ ] { } < > ’ “ ; : | \ and ?. Show RS-232 strings — Displays the ASCII commands that are used by the current configuration. You can refer to these for RS-232 programming. MVX VGA A Matrix Switchers • Matrix Software 5-11...

  • Page 93: Preferences Menu

    Ties as crosspoints — Displays ties as a matrix of inputs and outputs (figure 5-12). Ties that have been made are indicated as amber (video and audio), green (video only), and red (audio only) boxes. Ties that will take effect when you click the Take button are indicated by +. Ties that will be broken when you click the Take button are indicated by –. Figure 5-12 — Ties shown as crosspoints Icons in I/O boxes — Erases any numbers in the I/O boxes in the Control Program window (figure 5-5). You can place icons in the boxes. Numbers in I/O boxes — Erases any icons in the I/O boxes in the Control Program window and fills each box with the associated input or output number. Master-Reset selection Master reset clears all ties and presets, all video and audio mutes, resets all I/O grouping, sets all input audio levels to unity gain (+0 dB), and sets all output volume levels to 100% (0 dB of attenuation). 5-12 MVX VGA A Matrix Switchers • Matrix Software...

  • Page 94: Using Emulation Mode

    (figure 5-13), and download and install the program. Figure 5-13 — Location of software on the web site N The Button Label Generator software is also included on the Extron Software Products CD-ROM that accompanies the switcher. MVX VGA A Matrix Switchers • Matrix Software 5-13...

  • Page 95: Using The Button-Label Generator Software

    ButtonLabelGenerator directory and places the Button Label Generator icon into a group or folder named “Extron Electronics”. Using the Button-Label Generator software To run the Button-Label Generator program, click Start > Programs > Extron Electronics > Button Label Generator > Button Label Generator. The Button-Label Generator window appears (figure 5-14). Figure 5-14 — Extron’s Button-Label Generator window In the Systems drop box, choose either the CP 300 128 Series / MVX 128 / MTX 50 or the CP 300 Series 1616 Series option to match the label strip size for your MVX switcher. Using normal Windows controls, you can create and print labels that can be placed in the label windows on the front panel of the switcher. Click the Clear All Buttons button and create new labels as many times as necessary to make all of the button labels that you need. To access the help program, click the Help menu. 5-14 MVX VGA A Matrix Switchers • Matrix Software...

  • Page 96: Appendix A • Specifications, Part Numbers, Accessories

    MVX VGA A Matrix Switchers A ppendix A Specifications, Part Numbers, Accessories Specifications Part.Numbers.and.Accessories Button.Labels...

  • Page 97: Video Input

    Connectors 128/168 Series .. 8 female 15-pin HD 1212 Series ... 12 female 15-pin HD 1616 Series ... 16 female 15-pin HD Nominal level ... 1 Vp-p for Y of component video and S-video, and for composite video 0.7 Vp-p for RGB and R-Y and B-Y of component video 0.3 Vp-p for C of S-video Minimum/maximum levels .. 0 V to 2.0 Vp-p (follows input) Impedance .. 75 ohms Return loss .. <-30 dB @ 5 MHz DC offset .. ±10 mV with input at 0 offset MVX VGA A Matrix Switchers • Specifications, Part Numbers, Accessories...
  • Page 98 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV 2 dBu Audio output — audio models only Number/signal type .. 8, 12, or 16 stereo, balanced/unbalanced Connectors ... (8, 12, or 16) 3.5 mm captive screw connectors, 5 pole Impedance .. 50 ohms unbalanced, 100 ohms balanced Gain error ... ±0.1 dB channel to channel Maximum level (Hi-Z) ... >+21 dBu, balanced or unbalanced at 0.1% THD+N Maximum level (600 ohm) .. >+15 dBm, balanced or unbalanced at 0.1% THD+N Output volume range ... 0 to 64 (-75.8 dB to 0 dB) in 1 dB increments from steps 1 to 64, 12 dB increment from step 0 to 1; default = 64 = 0 dB MVX VGA A Matrix Switchers • Specifications, Part Numbers, Accessories...
  • Page 99 Vibration .. ISTA 1A in carton (International Safe Transit Association) Listings... UL, CUL Compliances .. CE, FCC Class A, VCCI, AS/NZS, ICES MTBF .. 30,000 hours Warranty .. 3 years parts and labor All nominal levels are at ±10%. Specifications are subject to change without notice. MVX VGA A Matrix Switchers • Specifications, Part Numbers, Accessories ® ™...

  • Page 100: Button Labels

    MKP 1000 remote keypad Black White RAL9010 white WT (water-tight) MCP 1000M (master) MKP 2000 matrix switcher X-Y remote control panel Black White RAL9010 white MKP 3000 Black White RAL9010 white MVX VGA A Matrix Switchers • Specifications, Part Numbers, Accessories Replacement part number 60-799-01 60-858-01 60-838-01 60-839-01 Replacement part number Part number 100-457-01 60-239-02 60-239-03 60-239-05...

  • Page 101: Cables

    VGA 75' MHR, 75' (22.8 m) VGA 100' MHR, 100' (30.4 m) Male-to-male VGA molded connector cables VGA M3' MHR, 3' (0.9 m) VGA M6' MHR, 6' (1.8 m) VGA M10' MHR, 10' (3.0 m) VGA M15' MHR, 15' (4.5 m) VGA M25' MHR, 25' (7.6 m) VGA M35' MHR, 35' (10.6 m) VGA M50' MHR, 50' (15.2 m) VGA M75' MHR, 75' (22.8 m) VGA M100' MHR, 100' (30.4 m) MVX VGA A Matrix Switchers • Specifications, Part Numbers, Accessories Part number 26-112-17 26-112-15 26-112-01 26-112-05 26-112-28 26-112-29 26-112-30 26-112-31 Part number 26-112-35 26-112-36...
  • Page 102 Male-to-male VGA molded connector cables VGA M3' MHR, 3' (0.9 m) VGA M6' MHR, 6' (1.8 m) VGA M10' MHR, 10' (3.0 m) VGA M15' MHR, 15' (4.5 m) VGA M25' MHR, 25' (7.6 m) VGA M35' MHR, 35' (10.6 m) VGA M50' MHR, 50' (15.2 m) VGA M75' MHR, 75' (22.8 m) VGA M100' MHR, 100' (30.4 m) MVX VGA A Matrix Switchers • Specifications, Part Numbers, Accessories Part number 26-238-24 26-238-25 26-238-26 26-238-27 26-238-28 26-238-16 26-238-04 26-238-05 26-238-06...

  • Page 103: Button Labels

    Specifications, Part Numbers, Accessories, cont’d Button Labels Figure A-1 provides 16-button strips of blank button labels. If desired, photocopy them or cut them out of the manual, write button information in each button area as desired, and put them in the switcher’s label window. For 12- or 8-button strips, use scissors to trim the blank to the appropriate length. To remove a panel, insert the Phillips-head end of a Tweeker or a small Phillips- head screwdriver into the hole in one end of the panel, and gently slide the tab at the edge of the panel out of the recess in the switcher housing. MVX VGA A Matrix Switchers • Specifications, Part Numbers, Accessories...
  • Page 104 MVX VGA A Matrix Switchers • Specifications, Part Numbers, Accessories...
  • Page 105 Specifications, Part Numbers, Accessories, cont’d A-10 MVX VGA A Matrix Switchers • Specifications, Part Numbers, Accessories...
  • Page 106 Extron Electronics warrants this product against defects in materials and workmanship for a period of three years from the date of purchase. In the event of malfunction during the warranty period attributable directly to faulty workmanship and/or materials, Extron Electronics will, at its option, repair or replace said products or components, to whatever extent it shall deem necessary to restore said product to proper operating condition, provided that it is returned within the warranty period, with proof of purchase and description of malfunction to:...
  • Page 107 Extron Electronics, USA 1230 South Lewis Street Anaheim, CA 92805 800.633.9876 714.491.1500 FAX 714.491.1517 www.extron.com Extron Electronics, Asia Extron Electronics, Europe 135 Joo Seng Rd. #04-01 Beeldschermweg 6C PM Industrial Bldg., Singapore 368363 3821 AH Amersfoort, The Netherlands +800.7339.8766 +65.6383.4400 +800.3987.6673 +31.33.453.4040 FAX +65.6383.4664 FAX +31.33.453.4050...
