SW2 VGA DA2 VGA Switcher Series
SW2 VGA DA2 A
Two Input, Dual Output VGA and Stereo Audio
Switcher with Rear Panel Inputs
unique FeAtureS
Rear panel inputs
•
External universal power supply included, part # 70-055-01
•
modeL
SW2 VGA DA2 A
SW2 VGA DA2 AF
Two Input, Dual Output VGA and Stereo Audio Switcher with
Front and Rear Panel Inputs
unique FeAtureS
Front and rear panel inputs
•
External universal power supply included, part # 70-055-01
•
modeL
SW2 VGA DA2 AF
SW2 VGA DA2 AF R
1U, Two Input, Dual Output VGA and Stereo Audio
Switcher with Front and Rear Panel Inputs
unique FeAtureS
Front and rear panel inputs
•
Front panel A/C outlet - USA Edison Female
•
Openings for two single space AAP - Architectural Adapter Plates
•
Removable rear cover for easy AAP installation
•
Rack mount brackets included
•
Internal international power supply
•
1U, full rack width metal enclosure
•
modeL
SW2 VGA DA2 AF R
SW2 VGA DA2 VGA Switcher Series Accessories
incLuded AcceSSorieS
For SW2 VGA DA2 AF R only
MBD 123
oPtionAL AcceSSorieS
For SW2 VGA DA2 A and SW2 VGA DA2 AF
RSU 126
MBU 125
MBD 129
For SW2 VGA DA2 AF R
MBU 123
For all models
IR 102 Remote Control Kit
EPS 1210 B
248
VerSion deScriPtion
Rear Inputs
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
VerSion deScriPtion
Front & Rear Inputs
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
VerSion deScriPtion
1U with Front & Rear Inputs
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
modeL deScriPtion
1U Full Rack Width Rack Mount for Two-Piece Enclosures
modeL deScriPtion
1U 6" Deep Universal Rack Shelf Kit
1U, 1/2 & 1/4 Rack Width, Under-Desk Mount Kit for Two-Piece Enclosure
1U, 1/2 & 1/4 Rack Width Through-Desk Mount Kit for Two-Piece Enclosure
VersaTools Mini Under-Desk Mount Kit
®
IR to RS-232 or Contact Closure Conversion Kit
Extron EPS 1210 B Power Supply - 12VDC, 2A
USA West USA West
+1.714.491.1500 / +800.633.9876 +1.714.491.1500 / +800.633.9876
+1.714.491.1517 FAX +1.714.491.1517 FAX
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
USA east USA east
+1.919.863.1794 / +800.633.9876 +1.919.863.1794 / +800.633.9876
+1.919.863.1797 FAX +1.919.863.1797 FAX
c o m p u t e r & r G B S w I t c h e r S
PArt #
60-297-11
PArt #
60-297-12
PArt #
60-368-11
PAGe PArt #
page 817 70-485-01
PAGe PArt #
page 819 60-190-10
page 815 70-077-01
. . . . .
page 817 70-077-02
. . .
page 815 70-212-01
page 271 70-224-01
page 694 70-055-01
www.extron.com www.extron.com
© 2008 Extron Electronics. All rights reserved. © 2008 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice. Pricing and specifications may change without notice.
Continued
