  • Page 1 © 2004 Extron Electronics. All rights reserved. User’s Guide Extron Electronics, Japan Daisan DMJ Building 6F 3-9-1 Kudan Minami Chiyoda-ku, Tokyo 102-0074 Japan +81.3.3511.7655 Fax +81.3.3511.7656 P/2 DA4xi P/2 DA6xi VGA Distibution Amplifiers 68-991-01 Rev. A Printed in the USA 07 04...

  • Page 2: Fcc Class A Notice

    Precautions Safety Instructions • English Warning This symbol is intended to alert the user of important Power sources • This equipment should be operated only from the power source indicated on the product. This equipment is intended to be used with a main operating and maintenance (servicing) instructions power system with a grounded (neutral) conductor.

  • Page 3: Installation

    The P/2 DA4xi and P/2 DA6xi can be mounted on a rack shelf, under-desk or through-desk. Rack mounting To install and set up the P/2 DA4xi or P/2 DA6xi on a rack, follow these steps: Power off the computer and its local monitor.

  • Page 4: Under-Desk Mounting

    P/2 DA4xi and P/2 DA6xi, cont’d Mount the unit on the rack shelf, as shown above, using two 4-40 x 3/16 screws in opposite (diagonal) corners to secure the case to the shelf. 6" Deep Rack Shelf Front false faceplate uses 2 screws.

  • Page 5: Rear Panel Features

    Signal input and output connections All connections, including power, input, and output are located on the back of the rear panel of the P/2 DA4xi and P/2 DA6xi. P/2 DA4xi/6xi • Installation P/2 DA4xi/6xi • Operation...

  • Page 6: Video Gain

    Included parts Included Parts 12VDC, 1A external power supply IEC power cord Rubber feet (4) P/2 DA4xi and P/2 DA6xi User’s Guide Optional accessories Accessories 1U 6” Deep Rack Shelf Kit 1U 6” Deep Basic Rack Shelf 1U Universal Rack Shelf Kit...

  • Page 7: Video Input

    Vertical frequency ... 30 Hz to 150 Hz Return loss ... <-40 dB @ 5 MHz Video output Number/signal type P/2 DA4xi ... 4 VGA-UXGA RGBHV, RGBS, RGsB, RsGsBs, component video, S-video, composite video (follows input type) P/2 DA6xi ... 6 VGA-UXGA RGBHV, RGBS, RGsB,...
  • Page 8 P/2 DA4xi and P/2 DA6xi, cont’d This page is intentionally left blank. This page is intentionally left blank. P/2 DA4xi/6xi • Installation P/2 DA4xi/6xi • Installation...
  • Page 9 P/2 DA4xi and P/2 DA6xi, cont’d This page is intentionally left blank. P/2 DA4xi/6xi • Installation...
