Extron electronics P/2 DA4xi User Manual

Specifications
Vertical frequency ....................... 30 Hz to 150 Hz
Return loss .................................... <-45 dB @ 5 MHz
Video output
Number/signal type
P/2 DA4xi ......................... 4 VGA-UXGA RGBHV, RGBS, RGsB, RsGsBs
P/2 DA6xi ......................... 6 VGA-UXGA RGBHV, RGBS, RGsB, RsGsBs
Connectors
P/2 DA4xi ......................... (4) 15-pin HD female
P/2 DA6xi ......................... (6) 15-pin HD female
Nominal level ............................... 0.7 V p-p for RGB
Minimum/maximum levels ...... 0.3 V to 5.0 V p-p (follows input)
Impedance .................................... 75 ohms
Return loss .................................... <-45 dB @ 5 MHz
DC offset ....................................... ±_5 mV with input at 0 offset
Sync
Input type ..................................... RGBHV, RGBS, RGsB, RsGsBs
Output type .................................. RGBHV, RGBS, RGsB, RsGsBs (follows input)
Input level ..................................... 1.8 V to 5.0 V p-p
Output level .................................. TTL: 5.0 V p-p, unterminated
Input impedance .......................... 510 ohms
Output impedance ....................... 50 ohms
Max. propagation delay ............. 60 ns
Max. rise/fall time ....................... 2 ns
Polarity .......................................... Positive or negative (follows input)
General
Power ............................................. 100 VAC to 240 VAC, 50/60 Hz, 12 watts,
internal, autoswitchable
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to
90%, noncondensing
Operating +32° to +122°F (0° to +50°C) / 10% to
90%, noncondensing
Rack mount ................................... Yes, with optional 1U rack shelf, part #60-190-01
or 60-604-01
Also furniture mountable with optional brackets
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.6" H x 8.7" W x 6.0" D (1U high, half rack wide)
4.1 cm H x 22.1 cm W x 15.2 cm D
(Depth excludes connectors.)
4 P/2 DA 4xi/6xi • Specifications
e-mail: info@direktronik.se
tel: 08-52 400 700 fax: 08-520 18121
Specifications, cont'd
Product weight ............................. 2.0 lbs (0.9 kg)
Shipping weight
P/2 DA4xi ......................... 4 lbs (2 kg)
P/2 DA6xi ......................... 5 lbs (3 kg)
Vibration ....................................... ISTA 1A in carton (International Safe Transit
Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
All nominal levels are at ±10%.
Specifications are subject to change without notice.
Included parts
Included parts
12VDC, 1A external power supply
IEC power cord
Rubber feet (4)
P/2 DA4xi and P/2 DA6xi User's Manual
Optional accessories
Accessories
1U Universal Rack Shelf
1U Basic Rack Shelf
Through-desk mounting kit
Under-desk mounting kit
VGAM MHR, Male to Male cable, 6'
Extron Electronics, USA Extron Electronics, Europe Extron Electronics, Asia
1230 South Lewis Street Beeldschermweg 6C 135 Joo Seng Road, #04-01
Anaheim, CA 92805 3821 AH Amersfoort PM Industrial Building
USA The Netherlands Singapore 368363
714.491.1500 +31.33.453.4040 +65.6383.4400
www.extron.com Fax 714.491.1517 Fax +31.33.453.4050 Fax +65.6383.4664
© 2004 Extron Electronics. All rights reserved.
User's Guide
Replacement part number
70-055-01
Part number
60-190-01
60-604-01
70-077-02
70-077-01
26-238-01
Extron Electronics, Japan
Daisan DMJ Building 6F
3-9-1 Kudan Minami
Chiyoda-ku, Tokyo 102-0074 Japan
+81.3.3511.7655
Fax +81.3.3511.7656
P/2 DA4xi
P/2 DA6xi
Distribution Amplifiers
68-942-01 Rev. A
Printed in the USA
04 04
