Specifications, Part Numbers, and Accessories

Specifications

Video
Gain ................................................ Unity
Bandwidth ..................................... 350 MHz (-3 dB), fully loaded

Video input

Number/signal type ..................... 1 UXGA-QXGA RGBHV, RGBS, RGsB,
Connectors .................................... 5 female BNC
Nominal level ................................ 1 Vp-p for Y of component video and
Minimum/maximum levels ........ Analog: 0.3 V to 1.5 Vp-p with no offset
Impedance ..................................... 75 ohms
Horizontal frequency .................... 15 kHz to 135 kHz
Vertical frequency .......................... 30 Hz to 150 Hz
Return loss ..................................... <-39 dB @ 5 MHz
DC offset (max. allowable)........... 0.2 V

Video output

Number/signal type
ADA 2/GLI 350xi .............. 2 RGBHV, RGBS, RGsB, RsGsBs,
GLI 350xi ............................ 1 RGBHV, RGBS, RGsB, RsGsBs,
Connectors
ADA 2/GLI 350xi .............. 2 x 5 BNC female
GLI 350xi ............................ 5 BNC female
Nominal level ................................ 1 Vp-p for Y of component video and
Minimum/maximum levels ........ Analog: 0.3 V to 1.5 Vp-p (follows input)
Impedance ..................................... 75 ohms
Return loss ..................................... <-45 dB @ 5 MHz
DC offset ........................................ ±10 mV
GLI 350xi & ADA 2/GLI 350xi • Specifications, Parts, Accessories
A-2
RsGsBs, component video, S-video,
composite video
S-video, and for composite video
0.7 Vp-p for RGB and for R-Y and B-Y of
component video
0.3 Vp-p for C of S-video
component video, S-video, composite
video
component video, S-video, composite
video
S-video, and for composite video
0.7 Vp-p for RGB and for R-Y and B-Y of
component video
0.3 Vp-p for C of S-video
Sync
Input type ...................................... RGBHV, RGBS, RGsB, RsGsBs
Output type .................................... RGBHV, RGBS, RGsB, RsGsBs (follows
Input level ..................................... RGBHV, RGBS (min./max.): 0.5 V to
Output level .................................. 0.3 V to 1.5 Vp-p, unterminated
Input impedance .......................... 510 ohms
Output impedance ....................... 75 ohms
Max. propagation delay ............... H = 60 ns, V = 226 ns
Max. rise/fall time ........................ 4 ns
Polarity............................................ Positive or negative (follows input)
General
External power supply (attached) 100 VAC to 240 VAC, 50/60 Hz, external;
Power input requirements ........... 12 VDC, 0.5 A
Temperature/humidity ................ Storage: -40 to +158 °F (-40 to +70 °C) /
Operating: ..................................... +32 to +104 °F (0 to +40 °C) / 10% to 90%,
Cooling ........................................... Convection, unvented
Rack mount .................................... Yes, with optional 1U, 9" deep rack shelf
Enclosure type .............................. Metal
Enclosure dimensions .................. 1.7" H x 4.3" W x 6.0" D (1U high, quarter
Product weight .............................. 0.8 lbs (0.4 kg)
Shipping weight ........................... 2 lbs (1 kg)
Vibration ........................................ ISTA 1A in carton (International Safe
GLI 350xi & ADA 2/GLI 350xi • Specifications, Parts, Accessories
input)
Tri-level on Y, R-Y, B-Y channels
(component video 720p, 1080i, 1080p)
Bi-level on Y channel (for all other
component video rates)
5.0 Vp-p (analog/TTL)
RGsB (nominal): 0.3 Vp-p (analog)
to 12 VDC, 1 A, regulated
10% to 90%, noncondensing
noncondensing
(RSU 129, #60-190-01; or RSB 129, #60-
604-01); 1U, 6" deep rack shelf (RSU 126,
#60-190-10; RSB 126, 60-604-10).
Also furniture mountable with optional
MBU 125 under-desk mounting kit, part
#70-077-01.
rack wide)
4.3 cm H x 11.0 cm W x 15.2 cm D
(Depth excludes connectors.)
Transit Association)
A-3
