Introduction
About the GLI 350xi and ADA 2/GLI 350xi
This manual contains information about the Extron
GLI 350xi ground loop isolator and the Extron ADA 2/GLI
350xi distribution amplifier with built-in ground loop isolator.
Extron ground loop isolators eliminate "hum" bars and common
mode noise caused by improper equipment grounding in video
systems.
Both models are rack and furniture mountable. The GLI 350xi
is a one-input, one-output model; the ADA 2/GLI 350xi is a
one-input, two-output unit. The terms "GLI" and "ground loop
isolator" are used interchangeably in this manual to refer to
either model.
Features
NTSC, PAL, and SECAM compatible — Both models are
NTSC, PAL, and SECAM compatible with computers
and other high resolution sources that output RGBHV,
RGBS, RsGsBs, and RGsB video. The RGB channels are
also compatible with low resolution video signals in
component, S-video, and composite video formats.
Bandwidth — 350 MHz (-3 dB) RGB video bandwidth, fully
loaded
Video input horizontal frequency range — 15 kHz - 135 kHz
Mounting options — The GLIs are rack and furniture
mountable.
GLI 350xi & ADA 2/GLI 350xi • Introduction
1-2
GLI 350xi & ADA 2/GLI 350xi
Chapter Two
Mounting.the.GLI.350xi.and.ADA.2/GLI.350xi
2
Installation
Application.Examples
