I See Warranty on page 6 for important information about €ommerdal use of this product. I
Oilless
Compressors
@
Description
Oillesscompressors are designed for
do-it-yoursefferswith a variety of home
and automotive jobs. These compres-
sorswill power spray guns. impact
wrenches and other tools. These units
operate without oil.
Safety Guidelines
This manual contains information that
is very important to know and
understand. This information is
provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS. To help
recognize this information, observe the
following symbols.
Dmnger lndl(ates
mn Imminently
h_atdoum situation whld_ If not
avolde_ will result In death or serious
Injury.
Warning Indicates
a_la_l, could _H In death or
s_s I_ury.
• _ed. my _su_ In m_ or
_r_ Injury.
Not,_'_ _dlc_s
} NOTICE I J_._t,.t
in_orm,tlon, that ff not followed, may
cause damage to eq_lpm_t
Unpacking
After unpacking the unit. inspect
carefully for any damage that may have
occurred during transit, Make sure to
tighten fittings, bolts, etc,, before
putting unit into service. In case of
questions, damaged or missing parts,
please call 1-800-543-6400 for customer
assistance or call the nearest Campbell
Hausfeld Authorized Service Center.
A listing of service center locations is
enclosed. Have the serial number,
model number and parts list (with
miSSing parts circledbefore calling).
O DO NOT RE]IJRN THE
PRODUCT TO THE
REI"AILERI
Record the Model and Serial numbers
(located on the compressor) and the
date of purchase in the spaces below.
Model No.
Serial No.
Date of purchase
Retain these numbers for future
reference.
&WARNINGI _o noto_e,'ate
unit if damaged
during shipping handling or use.
Damas_ may result in bursting and
€_use In_ry or property damage,
General Safety
Since the air compressor and other
components (material pump, spray
guns, filters, lubricators, hoses, etc.)
used. make up a high pressure pumping
system, the following safety precautions
must be observed at all times:
Breathable Air Warning
This comprusorlpump is NOT
equipped and should NOT be used
"as is" to supply breathing quality
air. For any application of air for
human consumption, you must fit
the air corn_prressor/pump with
suitable in-line safety and alarm
equipment. This additional
equipment is necessary to propedy
filter and purify the air to meet
minimal specifications for Grade D
breathing as described in
Compressed Gas Association
Commodity Specification G 7.1 -
1966, OSHA 29 CFR 1910. 134,
and/or Canadian Standards
Associations (CSA).
DISCLAIMER OF WARRAN_ES
IN THE EVENT THE COMPRESSOR iS
USED FOR THE PURPOSE OF
BREATHING AIR APPLICATION AND
PROPER IN-LINE SAFETY AND
ALARM EQUIPMENT IS NOT
SIMULTANEOUSLY USED, EXISTING
WARRANTIES ARE VOID, AND
CAMPBELL HAUSFELD DISCLAIMS
ANY UABILITY WHATSOEVER FOR
ANY LOSS, PERSONAL INJURY OR
DAMAGE.
1. Read all manuals |I
included with this
product carefully. Be
thoroughly familiar
with the controls and |
the proper use of the
L
equipment.
2, Follow all local electrical and safety
codes, as well as in the U.S.A.,
National Electrical Codes (NEC) and
Occupational Safety and Health Act
(OSHA).
3. Only persons well acquainted with
these rules of safe operation should
be allowed to use the compressor.
4. Keep visitors away and NEVER allow
children in the work area.
REMINDER: Keep dated proof of purchase for Attach it to this manual file ]
your warran_ purposesl or it for safekeeping.
