Casablanca Stealth Instructions Manual

INTRODUCTION
mOUNTINg ReCOmmeNDaTIONs
PRePaRaTION INsTRUCTIONs
faN INsTaLLaTION
CONTROL feaTURes:
INTELI•TOUCH OPERATION
INTELI•TOUCH TROUBLESHOOTING
READ AND SAVE THESE INSTRUCTIONS
Safety and the proper operation of your Casablanca fan both require a thorough knowledge of the product
and proper installation; therefore, before attempting to install and operate your Casablanca fan, read this
owner's manual completely and carefully. Retain this manual for future reference.
CAUTION: To avoid possible electrical shock, make certain that electricity is turned off
at the circuit breaker or fuse box before attempting any installation procedure.
• CAUTION: RISK OF ELECTRICAL SHOCK! All wiring must be performed in accordance with national and local electrical
codes. If you are unfamiliar with the wiring codes, you should use a qualified electrician. To avoid overheating and pos-
sible damage to other equipment, do not install control to a receptacle, fluorescent light fixture, motor operated appliance,
or transformer-supplied appliance..
• This fan is designed to be installed on an existing electrical outlet box. The outlet box must be UL Listed for ceiling fan
installations, if it is not, a new box must be installed. Casablanca extension poles are available for sloped or high ceiling
installations.
• This ceiling fan requires a grounded electrical supply of 120 VAC, 60 Hz and a minimum 15 amp circuit. The maximum
current requirement for the fan with light fixture is 2 amps. The fan uses about 1 amp or 100 watts. Maximum light current
is 1.0 amps or 100 watts of lighting.
• Where wire nuts are employed, be sure all bare wires are within the connectors. When installing the canopy hatch, make
sure all wires are within the canopy and that no wires are being pinched.
use only genuine Casablanca blades, light fixtures, and accessories.
• The blades in each pack are matched for equal
weight to assure smooth fan operation. If more
than one fan is being installed, be careful not to
mix blades from different cartons.
• Inspect the contents of your carton for possible
shipping or handling damage and report any such
damage directly to your authorized Casablanca
dealer.
• It is always a good idea to have an assistant to help
with the installation.
• When cleaning, painting, or working near your fan,
be very careful of the fan and blades. Always turn
the power OFF to the ceiling fan before servicing
it, working on it, or replacing light bulbs.
• Never insert anything into the path of the fan blades
while the fan is in operation.
• Never install a fan over a pool or spa.
• Never operate a fan that has been damaged in
any way. Contact Casablanca Fan Company by
calling toll free 1-888-227-2178, or contact your
local authorized Casablanca dealer for assistance
in obtaining service.
CONTENTS

SAFETY FIRST

BEFORE YOU START
For best performance and for your warranty to be valid,
SAFE USE
(remove fuse for The
circuiT you will be
working on)
CIRCUIT BREAKER
(Trip breaker for The
circuiT you will be
working on)
PN 3243Z
S
FUSE BOX
HN1209
®
tealth
16
18"
70"
84"
1
1
2
3
4
8
