100 Maintenance
You must log in to the Signaling Server to use the CLI commands. Refer
to Signaling Server Installation and Commissioning (NN43001-312) for
this procedure.
Table 4 "CDS OAM commands" (page 100)
CLI commands available on the Signaling Server from the OAM shell.
Table 4
CDS OAM commands
Command
cdsShow
cdsAgentShow
Table 5 "CDS PDT commands" (page 100)
CLI commands available on the Signaling Server from the PDT shell.
Table 5
CDS PDT commands
Command
cdsAmlTrace <level>
Communication Server 1000 to MCS 5100 Converged Desktop Type 2 Configuration Guide
Copyright © 2005-2008, Nortel Networks
.
Description
Displays the current Converged Desktop configuration.
The command is used to check the basic Converged
Desktop application status.
Displays the Personal Call Assistance (PCS) agent's
information and status.
Description
Sets the Application Module Link (AML) trace level for the
CDS application. Turns tracing on/off for troubleshooting
message flows between the Call Server and the Signaling
Server.
Where <level> is:
0 – turns off trace
1 – prints all input/output AML data buffer
2 – prints all input/output AML data buffer except POLLING
message
3 – prints all input/output AML data buffer except POLLING
message, with Information Element (IE)-type decoding
4 – prints all input/output AML data buffer except POLLING
message, with IE type and data decoding
Note: This command prints the AML messages to/from the
Call Server at the transport layer. Because sending and
receiving AML messages is based on each AML link instead
of each DN or TN, no good solution exists for filtering on
this AML trace tool. Nortel recommends that tracing not be
turned on in a busy system. Instead, Nortel recommends
the use of the cdsCallTrace tool or vtrkCallTrace tool.
Nortel Communication Server 1000
NN43001-321 01.05 Standard
Release 5.0 15 February 2008
