Single-Phase AC Cabling for USA

Caution

Connecting the Power Supply Cord

Preparing for Installation
The DKC has two main disconnect devices (two main Breaker CB200s for
dual power lines) so that AC Power of the unit can be supplied from the
separate power distribution board with two power supply cords. Similarly,
each of the 1st DKU, the 2nd DKU, the 3rd DKU, the 4th DKU, the 5th
DKU, and the 6th DKU also has two main disconnect Devices (two main
breaker CB101s for dual power lines).
described in this manual before connecting the equipment to the
power source and before servicing.
The unit has two power supply cords with attachment plug type R&S
5720DP/0625. Be sure to prepare the following socket receptacles between
the power distribution board of the building and the attachment plugs for
the unit:
• Socket receptacle: R&S 3743 or 3913
• The power cord that is provided with your disk array is type SJT or
equivalent, nonshielded type, with three min. #10 AWG conductors,
terminated at one end with an assembled socket receptacle cap.
Observe all instructions
53
