HP SureStore E Disk Array XP512 Upgrade Product Weights
Product Description
A5953U 4-ExSA channel adapter pair
A5954U 8-ExSA channel adapter pair
A5956U 8 port Fibre Channel adapter pair
A5961U Additional power supply for chips 3 to 4
A5962U 1GB cache memory
A5963U 256MB shared memory module
A5964U Additional ACP pair
A5965A 60 Hz disk array frame with 2 disk canister mount
Opt 001 platforms: 3 phase power
60 Hz disk array frame with 1 canister
mount platform
Additional disk canister mount platform
A5965A 50 Hz disk array frame with 2 disk canister mount
Opt 002 platforms: 3 phase power
A5965A 60 Hz disk array frame with 2 disk canister mount
Opt 003 platforms: 1 phase power
60 Hz disk array frame with 1 canister
mount platform
Additional disk canister mount platform
A5965A 50 Hz Disk Array frame with 2 disk canister mount
Opt 004 platforms: 1 Phase Power
50 Hz disk array frame with 1 canister
mount platform
Additional disk canister mount platform
A5966U 18GB array group, 4 drives per group
A5967U 47GB array group, 4 drives per group
Preparing for Installation
kg lb
2.0 4.41
4.0 8.82
4.0 8.82
8.0 17.74
0.1 0.2
0.1 0.2
3.5 7.72
267 588.6
197 434.3
70 154
267 588.6
267 588.6
197 434.3
70 154
(continued)
267 588.6
197 434.3
70 154
8.59 18.74
9 19.84
