32
DKC Service Clearance (in)
3.5"
2.4"
4.6"
26.8"
22.2"
4.6"
2.4"
11.0"
6.5"
3.4"
0.6"
Floor cutout area for cables
Screw jack
Caster
Service clearance
Grid panel(Perforated tile) (over 450mm x
G
450mm)
29.5"
(Unit: inches)
22.4"
3.5"
G
7.9"
15.7"
7.9"
G
16.5"
6.5"
22.8"
3.4"
28.3"
0.6"
Front
HP SureStore E Disk Array XP512: Site Prep Guide
31.5"
94.5"
31.5"
31.5"
