3-Phase AC Cabling for Europe

Caution

Connecting the Power Supply Cord

Preparing for Installation
The DKC and the basic DKU commonly have two main disconnect devices
(two main breakers for dual power lines) so that AC Power of the unit can
be supplied from the separate power distribution board with two power
supply cords. Similarly, each of the 2nd DKU, the 3rd DKU, the 4th DKU,
the 5th DKU, and the 6th DKU also has two main disconnect devices.
Observe all instructions described in this manual before connecting the
equipment to the power source and before servicing.
50Hz European disk arrays are shipped with an unterminated power cord.
Your electrician must select and install the correct power plug. Be sure to
prepare the following socket receptacles and power cords between the
power distribution board of the building and the attachment plugs for the
unit:
A power cord of type H07RN-F or equivalent, with five 6.0mm
provided with the unit.
Be sure to connect a power cord to the distribution box as illustrated below.
Miswiring of the neutral conductor may cause damage to your disk array.
To reduce the risk of a wrong connection, you should use a plug and socket
that is approved for this disk array. It is your electrician's responsibility to
select and install the proper plug.
