Pair Operation
(continued)
or COPY status to the PSUS/PSUE status
or PSUS/PSUE status to SMPL status.
162 Continuous Access Journal GUI reference
HOLD: A pair for delta resync operation is created.
HLDE: An error occurred with the pair for delta resync operation.
HOLDING: The pair status is changing to HOLD while creating a delta resync pair.
Suspending: The P-VOL and the S-VOL are not synchronized. This pair is in transition from the PAIR
Deleting: The P-VOL and the S-VOL are not synchronized. This pair is in transition from the PAIR, COPY,
JNL-MirrorID: A journal number and a mirror ID. The number on the left of the hyphen (-) is a journal
number. The number on the right of the hyphen is a mirror ID. This column is blank if the volume in the
local storage system is neither a P-VOL nor a S-VOL.
S/N (LDKC): The serial number and the LDKC number of the remote storage system. This column is
blank if the volume of local storage system is neither a P-VOL nor a S-VOL. This column can be blank
while the pair is in transition to the SMPL status. To view the latest information in this column, refresh
the screen.
CTRLID (Model Name): The serial number and the controller ID of the remote storage system. The model
name is enclosed by parentheses. The controller ID for a P9500 storage system is 6. The controller ID
for a XP24000/XP20000 Disk Array storage system is 5. The controller ID for a XP12000 Disk
Array/XP10000 Disk Array is 4. This column can be blank while the pair is in transition to the SMPL
status. To view the latest information in this column, refresh the screen.
Paired VOL: A data volume in the remote storage system. See the figures following this table for an
example. This column indicates a P-VOL if the remote storage system is a primary storage system. This
column indicates a S-VOL if the remote storage system is a secondary storage system. A device ID
ending in X (for example, 00:00:3C X) indicates the LDEV is a Thin Provisioning virtual volume. A
device ID ending in # (for example, 00:00:3C #) indicates the LDEV is an external volume. If a volume
is a volume of XP24000/XP20000 Disk Array, "00" appears for the LDKC number. This column shows
the port ID, GID, and LUN of the volume specified in the remote storage system when creating the
pair. If you change or delete the port ID, GID, or LUN of the volume in the remote storage system,
incorrect information will appear in this column. So, unless you have any special circumstances, do
not change or delete the port ID, GID, or LUN specified when creating the pair. This column is blank
if the volume in the local storage system is neither a P-VOL nor a S-VOL
