Wegener iPUMP 562 User Manual

Digital media server
Hide thumbs Also See for iPUMP 562:
Table of Contents

Advertisement

Quick Links

Download this manual
iPump 562
Digital Media Server
iPump 562
Digital Media Server
User's Manual
800092-01 Rev. A

Advertisement

Table of Contents
loading

Related Manuals for Wegener iPUMP 562

Summary of Contents for Wegener iPUMP 562

  • Page 1 iPump 562 Digital Media Server iPump 562 Digital Media Server User’s Manual 800092-01 Rev. A...
  • Page 2 , MediaPlan , ENVOY , UNITY , UNITY·IP , and iPUMP are trademarks of Wegener Communications, Inc. All other trademarks are the property of their respective owners. © 2008 Wegener Communications, Inc . All rights reserved. Correspondence regarding this publication, 800092-01 Rev.

  • Page 3: Table Of Contents

    Unity 552 User’s Manual ABLE OF ONTENTS HAPTER ENERAL NFORMATION 1.1 Manual Overview ..........1 1.2 Product Overview .
  • Page 4 HAPTER PERATION 3.1 Controlling and Monitoring ........13 Front Panel Controls And Indicators .
  • Page 5 Unity 552 User’s Manual 3.3 View Alarms/Warnings........37 HAPTER EARCH UNCTIONS...
  • Page 6 This page intentionally left blank 800092-01 Rev. A www.wegener.com...
  • Page 7 Unity 552 User’s Manual IST OF ABLES Table 1.1: iPump 562 Interconnect Descriptions ............3 iPump 562 External Input/Output Interfaces ..........3 Table 1.2: iPump 562 RF Characteristics ..............5 Table 1.3: Table 1.4: iPump 562 Video Decoder .................6 iPump 562 Composite Video Output ............7 Table 1.5: Table 1.6: iPump 562 Component Video Output ............8...
  • Page 8 This page intentionally left blank 800092-01 Rev. A www.wegener.com...
  • Page 9 Unity 552 User’s Manual IST OF IGURES Figure 1.1: iPump 562 Rear Panel ................2 iPump 562 Front Panel ................13 Figure 3.1: OSD Main Menu ..................14 Figure 3.2: Figure 3.3: Diagterm Terminal Help Screen ...............15 iPump 562 OSD Carrier Settings Screen ..........17 Figure 3.4: iPump 562 OSD Current Channel Screen ..........18 Figure 3.5:...
  • Page 10 iPump 562 OSD Display Current Warnings ..........39 Figure 3.34: Figure Apx 3.1: RMA Request Form ................53 viii 800092-01 Rev. A www.wegener.com...

  • Page 11: Chapter 1 General Information

    We always appreciate constructive criticism. Address: Attn: Manuals Wegener Communications, Inc. Technology Park / Johns Creek 11350 Technology Circle Duluth, GA 30097-1502...

  • Page 12: Features And Options

    General Information Features and Some of the features and options of iPump 562 are highlighted below. Options Optimize bandwidth utilization by decoding MPEG-2 and MPEG-4/H.264 compression Save bandwidth with compliance to DVB-S2 QPSK /8PSK & DBV-S modulations Deploy in global markets by employing PAL and NTSC video formats Provide viewing options for both, HD and SD audiences Compel Play out media files and play lists received from...

  • Page 13: Rear Panel Connections

    Unity 552 User’s Manual Rear Panel The iPump 562 rear panel provides following connections: Connections Table 1.1: iPump 562 Interconnect Descriptions Port / Signal Connector Type Description DC IN M Power Jack +12 V DC 5 A RF Switch IN - Port 1 950 to 2150 MHz signal accepted;...
  • Page 14 General Information External Input/Output Interfaces C-Video Output Yellow RCA Audio 1 and 2 (two analog audio ports) Connector Input/Output Description Right Audio Output Red RCA Unbalanced Left Audio Output White RCA Unbalanced S/PDIF Digital Audio Connector Input/Output Description Output Coax/Electrical Output TosLink/Optical HDMI Digital Audio/Video...

  • Page 15: Technical Specifications

    Unity 552 User’s Manual External Input/Output Interfaces Contact Closure GPIO DB-9 Female Connector Pin Input/Output Description Alarm Common Alarm Normally Open Contact Closure Common No Connection Input Contact Closure GPIO Input (Factory use only) Alarm Normally Closed Contact Closure Normally Closed Contact Closure Normally Open Ground Power DC IN 12 V 5 A...

  • Page 16: Video Decoder

    General Information RF Characteristics Aggregate MPEG Transport Rate 8PSK = 80.346; S1 QPSK = TBD 2.5 to 48.38 Mbps (limited by max symbol-rate and inner FEC chosen), defined for 188-byte MPEG transport packets Max/Min Eb/No @ Video Threshold S1QPSK: FEC: Eb/No (dB) 1/2: 4.5 2/3: 5.0 3/4: 5.5...

  • Page 17: Composite Video Output

    Unity 552 User’s Manual Video Decoder Supported Digital Video Resolutions 480I / 29.97 480P / 59.94 576I / 25 576P / 50 Horizontal: 720, 704, 640, 544, 528, 480 and 352 1080I / 29.97 Horizontal: 1920, 1440, 1280, and 960 1080I / 25 Horizontal: 1920, 1440, 1280, and 960 720P / 50...

  • Page 18: Unbalanced Audio Output

    General Information Table 1.6: iPump 562 Component Video Output Component Video Output Line 21 Closed captioning Divicom and ATSC EIA-608-B TELETEXT CCIR/ITU-R Broadcast Teletext System B Output Level Y = 1 Vp-p, Pb/Pr = 700mVp-p Output Impedance 75 Ohms Multi-burst Frequency Response NTSC: From 0.5 to 4.2 MHz: <...

  • Page 19: Serial Port

    Unity 552 User’s Manual Serial Port Table 1.10: iPump 562 Serial Port Serial Port RS-232 RJ11 Selectable services Auxiliary character-based async output E-mail character-based async output Terminal monitoring and control Baud Rates 2400 to 115200 baud Formatting 8 data-bits, one start, one stop-bit, half-duplex, no parity Local Hard Disk Driver (HDD) Table 1.11: iPump 562 HDD Local Hard Disk Driver (HDD)

  • Page 20: Physical Characteristics

    General Information Physical Characteristics Table 1.14: iPump 562 Physical Characteristics Physical Characteristics Chassis Height 1 RU for desktop - 1RU using supplied rack ears Chassis Width 16.5 inches - with optional rack ears - 19 inches Chassis Depth 11.5 inches Weight 7.5 lbs.

  • Page 21: Chapter 2 Installation

    Unity 552 User’s Manual HAPTER NSTALLATION This chapter provides instructions on unpacking, mounting, and connecting your iPump 562 as well as connector information including detailed pinouts. 2.1 Unpacking and Inspection Carefully unpack the unit and its ac power cord and inspect for obvious signs of physical damage that might have occurred during shipment.

  • Page 22: Circuit Overloading

    Installation loading must be considered. Also, do not rest any unsupported equipment on a rack- mounted iPump 562 unit. Circuit Overloading Consideration should be given to the connection of the equipment to the supply circuit and the effect that overloading of circuits could have on overcurrent protection and supply wiring.

  • Page 23: Controlling And Monitoring

    Unity 552 User’s Manual HAPTER PERATION This chapter provides information and procedures for powering up, operating the unit, upgrading software and tracking alarm conditions. Information on four-port RF option and Universal LNB Power is also presented. 3.1 Controlling and Monitoring The IRD can be controlled via Compel network, front-panel using push-buttons and OSD (On-Screen Display) or LCD menus or the diagterm terminal using commands.

  • Page 24: Chapter 3 Operation

    Operation Figure 3.2: OSD Main Menu Push-buttons Use the arrow buttons and Enter on the front panel to navigate and edit the fields on LCD and OSD menus. Any of the push buttons activate OSD and LCD. The arrow buttons are used to navigate through menus and to either change or display items to set desired options for the IRD.

  • Page 25: Diagterm Terminal (Commands)

    Unity 552 User’s Manual indicate that, although output is being produced, there is a problem that could require attention. The most common conditions that produce alarms or warnings are listed in Table Table 3.2: iPump 562 Front Panel Status LED Alarm and Warning Indications Mode LED Status Condition...

  • Page 26: Compel™ System Control

    Operation Compel™ The iPump 562 IRD is most often controlled via the WEGENER Compel Control System . This system is managed at the uplink site, sending a control stream with the usual audio System and video data streams. The Compel System addresses units, and commands them to Control perform various functions.

  • Page 27: Tune To A Carrier

    Unity 552 User’s Manual Tune to a Carrier Settings screen carrier Use following steps to display Carrier Settings screen on the OSD menu: 1. Press any push-button on the front-panel to display the Main Menu . 2. Press the down arrow button to select Carrier Settings . 3.

  • Page 28: Configure Lnb Options

    Operation Figure 3.5: iPump 562 OSD Current Channel Screen Use the Current Channel screen to set or display the channel information. Table 3.3: Channel Information Options Option Possible values Comments Preset Perm, Command, Last Only Perm option allows other options to be set. Success or Current Compel The channel set using the...

  • Page 29: Monitor Signal Quality

    Unity 552 User’s Manual Figure 3.6: iPump 562 OSD LNB Setup Screen Use the LNB Setup screen to set and display the LNB configuration. Table 3.4: LNB configuration options Option Possible values Comments LNB Type Local Oscillator or Universal/ASTRA Only Local Osc option allows other options to be set.

  • Page 30: Indicator Threshold Screen

    Operation Figure 3.7: iPump 562 OSD Signal Quality Setup Screen Indicator Threshold screen Use following steps to display the Indicator Threshold screen on the OSD menu: 1. From the Signal Quality Setup screen, ensure that Indicator Thresholds is selected. 2. Press Enter to display the Indicator Threshold screen shown in Figure 3.5 . 3.

  • Page 31: Signal Strength Meter Screen

    Unity 552 User’s Manual Table 3.5: Indicator Threshold screen options Option Possible values Comments Errored Secs per Min 10 to 19 Set the threshold for how many errors per minutes before raising a warning condition. Signal Strength Meter screen Use following steps to display Signal Strength Meter screen on the OSD menu: 1.

  • Page 32: Configure The Unit For Operation

    Operation Figure 3.10: iPump 562 OSD Subtitling Screen Use the Subtitling Setup screen to set and display the Subtitling information. Table 3.6: Subtitling Setup screen options Option Possible values Language English, French, Spanish or 1st Available Style Normal, Normal + Captioning or Off Configure the Advanced Setup screen unit for...

  • Page 33: Unit Setup Screen

    Unity 552 User’s Manual Figure 3.11: iPump 562 OSD Advanced Setup Unit Setup screen Use following steps to display Unit Setup screen on the OSD menu: 1. Press any push-button on the front-panel to display the Main Menu . 2. Press the down arrow button to select Advanced Setup . 3.

  • Page 34: Set Decoder Options

    Operation LAN IP Networking Carrier Settings Terminal options User Relay Date and Time information Unit Label settings Switch Application Set Video Decoder options Set Decoder Options Use following steps to display Decoder Setup screen on the OSD menu: 1. Navigate to the Unit Setup screen, see Unit Setup screen on page 23. 2.

  • Page 35: Setup Audio

    Unity 552 User’s Manual Option Possible values Comments Composite Out NTSC_M, NTSC_J, PAL/50 or Selects video output format PAL/60 Component Out 480i, 480p, 576i, 576p, 720p or Selects video output format. When a DVI/HDMI device 1080i is connected, the mode shall be automatically set to Slave.

  • Page 36: Set Lan-Based Decode Options

    Operation Set LAN-based Decode options Use following steps to display Decoder Source screen on the OSD menu: 1. Navigate to the Decoder Setup screen 2. Press the up or down arrow buttons to select Decoder Source . 3. Press Enter . 4.

  • Page 37: Set Terminal Options

    Unity 552 User’s Manual Figure 3.16: iPump 562 OSD LAN IP Setup Use the LAN IP Setup screen to set and display the networking configuration. Table 3.10: Networking Configuration Settings Option Possible values Comments LAN Configuration Static or DHCP LAN IP Address IP Address LAN Netmask IP Net-mask...

  • Page 38: Set Printer Options

    Operation Figure 3.17: iPump 562 OSD Terminal Setup Use the Terminal Setup screen to set and display the terminal options. Table 3.11: Terminal Options Option Possible values Console Baud-rate 2400, 9600, 19200, 38400, 57600, 115200 Set Printer Options Use following steps to display Printer Setup screen on the OSD menu: 1.

  • Page 39: Set User Relay

    Unity 552 User’s Manual Set User Relay Use following steps to display User Relay Setup screen on the OSD menu: 1. Navigate to the Unit Setup screen. 2. Press the down arrow button to select User Relay Setup . 3. View the details as shown in Figure 3.19 Figure 3.19: iPump 562 OSD User Relay Setup Use the User Relay Setup screen to set the User Relay Setup options.

  • Page 40: Set Unit Label

    Operation Figure 3.20: iPump 562 OSD Date/Time Setup Use the Date/Time Setup screen to set and display the date and time information. Table 3.13: Date and Time Information Settings Option Possible values Current Date Yyyy/mm/dd Current Time Hh:mm:ss Time zone All available…...

  • Page 41: Monitor Status Information

    Unity 552 User’s Manual backup. Use the Version Information screen to find out about the software versions installed in the system. Figure 3.21: iPump 562 OSD Application Switch Monitor The following types of status information are available for viewing: Status Signal Quality Information Current Quality...

  • Page 42: Signal Quality Screen

    Operation Figure 3.22: iPump 562 OSD Unit Status Signal Quality screen Use following steps to display the Signal Quality screen on the OSD menu: 1. Navigate to the Unit Status screen, see Unit Status screen on page 31. 2. Press the down arrow button to select Signal Quality Status . 3.

  • Page 43: History This Setting Screen

    Unity 552 User’s Manual 2. Press the down arrow button to select Current Quality . 3. View the details as shown in Figure 3.24 . Figure 3.24: iPump 562 OSD Current Quality History This Setting screen Use following steps to display the History This Setting screen on the OSD menu: 1.

  • Page 44: Elapsed Times Screen

    Operation Elapsed Times screen Use following steps to display the Elapsed Times screen on the OSD menu: 1. Navigate to the Signal Quality screen. See Signal Quality screen on page 32 from a Signal Quality sub-screen, press the left arrow button to go back to the Signal Quality screen.

  • Page 45: Display Lan Ip Network Information

    Unity 552 User’s Manual Figure 3.27: iPump 562 OSD Network History Display LAN IP Network information Use following steps to display LAN IP Info screen on the OSD menu: 1. Navigate to the Unit Status screen, see Unit Status screen on page 31. 2.

  • Page 46: Clear Statistics Used For Diagnosis

    Operation 3. Press Enter . 4. View the details as shown in Figure 3.29 . Figure 3.29: iPump 562 OSD Version Info Clear Statistics used for diagnosis Use following steps to display Clear Signal Counters screen on the OSD menu: 1.

  • Page 47: Play Out Play Lists Of Media Files

    Unity 552 User’s Manual Play out play lists of media files Play lists of media files can be sent to iPump 562 from Compel uplink using Assured Files Delivery (AFD) for playing immediately upon receipt (Un-timed). The OSD Main Menu screen displays name of the play list currently being played under Current Program .

  • Page 48: Figure 3.32: Ipump 562 Osd Main Menu

    Operation Figure 3.32: iPump 562 OSD Main Menu 2. Press the down arrow button to select Alarms/Warnings . 3. Press Enter . Figure 3.33: iPump 562 OSD Alarms / Warnings 4. Select Display Current Warnings . 5. Press Enter . 800092-01 Rev.
  • Page 49 Unity 552 User’s Manual Figure 3.34: iPump 562 OSD Display Current Warnings www.wegener.com 800092-01 Rev. A...
  • Page 50 Operation This page intentionally left blank 800092-01 Rev. A www.wegener.com...

  • Page 51: Chapter 4 Search Functions

    Unity 552 User’s Manual HAPTER EARCH UNCTIONS 4.1 Perms/Temps/Searching & Settings The term "settings" is used throughout this document and includes the following set of parameters: Table 4.1: Settings Parameters for the iPump 562 Setting Description Modulation S28PSK/S2QPSK/QPSK RF Switch/Pol If IRD is configured for Universal LNB, H or V are valid.

  • Page 52: Settings Table (Or Search Table)

    Search Functions Table 4.2: iPump 562 Settings Groups Settings Description Group Temp These settings are entered via Compel or the TEMP / TEMPCH terminal commands. The unit is said to be inserting when it is configured to the temp settings. The maximum length of an insert is approximately 18 hours (65535 seconds).

  • Page 53: Frequency Tagging

    Unity 552 User’s Manual Table 4.3: Signal Quality Information Parameter Description Modulation 8PSK/QPSK/S1 RF Switch/Pol If IRD is configured for Universal LNB, H or V are valid. Specify RF port 1-4 for four-port RF configuration. Carrier The downlink frequency specified in MHz with up to two decimal places. This value’s absolute difference with the LNB LO frequency is used as specified in the technical specifications.
  • Page 54 Search Functions This page intentionally left blank 800092-01 Rev. A www.wegener.com...

  • Page 55: Chapter 5 Customer Service

    HAPTER USTOMER ERVICE 5.1 Warranty The following warranty applies to all Wegener Communications products including the iPump 562 All Wegener Communications products are warranted against defective materials and workmanship for a period of one year after shipment to customer. Wegener...
  • Page 56 Customer Service This page intentionally left blank 800092-01 Rev. A www.wegener.com...

  • Page 57: Appendix 1 Terminal Diagterm Commands

    Unity 552 User’s Manual PPENDIX ERMINAL IAGTERM OMMANDS The iPump 562 provides command-line interface, Diagterm. The diagterm can be accessed either using a RS-232 serial port or logging through LAN IP interface using Linux. The diagterm commands are used to control or monitor the IRD operations. This method may be used in conjunction other ways to control or monitor, namely, Compel and OSD.
  • Page 58 groups Report List of Groups Group Name: rdbs Command Synopsis report Report RBDS Status test Send test message to RBDS port "test <port> <message> Group Name: lan Command Synopsis Set Static LAN IP Address of the Unit gateway Set Network Gateway for LAN Interface mode Set LAN Addressing Mode (DHCP, STATIC,WEG) setup...

  • Page 59: Table Apx 1.2: Diagterm Individual Commands

    Unity 552 User’s Manual Following is a list of commands along with synopsis. A general syntax for the group command is: Table Apx 1.2: Diagterm Individual Commands Command Synopsis abortrec Tune to Last Successful (S) or Last commanded (C) abort Abort Temporary Insert adds Add Location Settings...
  • Page 60 Command Synopsis spdif Set SPDIF Mode Select default program for carrier (program #) tempch Set temp settings from settings table temp Set temp settings 800092-01 Rev. A www.wegener.com...

  • Page 61: Appendix 2 Menu Tree

    Unity 552 User’s Manual PPENDIX The following page shows the LCD navigation for the iPump 562 . www.wegener.com 800092-01 Rev. A...
  • Page 62 MAIN MENU CURRENT SUBTITLING CARRIER ADVANCED AUDIO 1 LANG AUDIO 2 LANG EXIT OSD PROGRAM SETUP SETTINGS SETUP UNIT LANGUAGE STYLE UNIT SETUP STATUS CURRENT LNB LO LNB DC SNR MARGIN SIGNAL SIGNAL STATUS DECODER AUDIO LAN IP CARRIER SERIAL USER RELAY DATE/TIME CHANNEL...

  • Page 63: Appendix Rma Request Form

    Unity 552 User’s Manual 3 RMA R PPENDIX EQUEST Apx 3.1 Return Materials Authorization Request Form http://www.wegener.com/custservrma.htm Figure Apx 3.1: RMA Request Form E-mail: service@wegener.com Fax: (678) 624-0294 Company Name: Bill-To Address: Ship-To Address: Contact Name: Phone # Fax #: Complete Model #: Serial #: In Warranty:...
  • Page 64 This page intentionally left blank 800092-01 Rev. A www.wegener.com...
