Installation Quick Start Guide
General Information
The Wegener
server. It receivers real-time broadcast-quality transmissions via a QPSK L-band input while it
simultaneously receives IP data files from either a satellite or terrestrial IP connection. It supports
streaming video and audio services via routing, recording, or direct playback. It can even convert
traditional MPEG satellite channels into locally streamed services. Additional information may be
found on the Wegener web site at: www.wegener.com.
Unpacking and Inspection
The box containing the unit should include:
Carefully unpack the unit and the ac power cord and inspect for obvious signs of physical damage
that might have occurred during shipment. Any damage claims must be reported to the carrier
immediately. Be sure to check the package contents carefully for important documents and
materials.
Save the original packing materials and shipping containers in case the unit must be
NOTE:
returned for repair. Packing the unit in another container in such a way that the unit is
damaged will void the warranty.
Environmental Operating Conditions and Physical Specifications
The table below lists the
ITEM/LIMIT
Use
Altitude
Temperature Range
Relative Humidity (max.)
Weight
Dimensions (H x W x D)
Input Power Rating
www.wegener.com
iPump 622
Streaming Media Decoder
iPump 622 Enterprise Media Server
the iPump 622 Enterprise Media Server
this Quick Start Guide
an IR remote control
iPump 622
Indoor
Up to 2000 meters
o
o
10
C to 35
C
80% for temperatures up to 31
~20 pounds or 9.1 kilograms
4.49" x 15.35" x 14.45" or 114.0 mm x 390.0 mm x 367.0 mm
100 to 127 V, or 200 to 240 V AC, 60/50 Hz, 5/3A, Power Supply (115/230V selectable
switch)
622 QSG-800067-02 Rev. B.fm
is an integrated satellite receiver and video
Environmental Limits and Physical Specifications
SPECIFICATION
o
C decreasing linearly to 50% relative humidity at 35
a UL Safety Sheet
an AC power cord
bagged accessories
o
C
1
