Installthe hanger a ssembly o ntothe uprightsupportbracket u singa
carriage bolt (710-0276) andwingknob(720-04122) from hardware pack
689-00312. SeeFigure 9.
Installthe grass catchercoverontothe bagsupportassembly, asseenin
Figure 11.Thegrass catcher c overgoesinside of the two mountingtabson
the bagsupportassembly.
Assembling RemainingBaggerComponents
Nowthat the mountingbrackets areassembled a ndareinplaceonthe tractor,
followthesestepsto assemble the remaining baggercomponents.
1. Snap the plastic upperchutesupportinplacebyfirst clippingthe side
portionontothe bagsupportrailwith the edge of the snapfeaturealigned
with the redline (1),asshownin the insetof Figure 10.
2. Snap thefront portionof the upperchutesupport t o the bagsupportrailas
seenin2 of Figure 10.
Figure 11
Slide the hingepin intothe hole located onthe mountingtab,asin Figure
12. Use the cut-outwindow(See inset inFigure 12)to lineup the hingepin
on the othersideandpushpinall the wayinuntil it reaches t he end-stop.At
thispointthe pin clipsinto placeandissecured byatab in the bagger c over.
SeeFigure 13.
Figure12
Figure 10
10
