4X1 DVI KVM DL/SL SWITCHER REMOTE INSTALLATION
To use the RMT-4IR remote, remove the battery cover on the back of the remote
to reveal the battery compartment. Insert the included battery into the open battery
slot. The positive (+) side should be facing up. Ensure that both DIP (Dual Inline
Package) switches are in the OFF position. Replace the battery cover. The remote
ships with 2 batteries. One battery is needed for operation and the other battery is
complimentary.
Empty Battery Slot
IR Code Dip Switches
8
