3.7 AC INPUT POWER CONNECTION

Connection of this power supply to an AC power source
should be made by an electrician or other qualified personnel
The power supply shall be connected to the AC source via protective device (circuit breaker, fuses,
etc.) rated 30A max..
The power supply ON/OFF switch is not the main disconnect device and does not completely discon-
nect all the circuits from the AC source.
An appropriately rated disconnect device such as circuit breaker, type B plug on power cord,...etc.,
shall be provided in the final installation. The disconnect device shall comply with UL/IEC 60950-1 re-
quirements and shall be easily accessible.

3.7.1 AC Input Connector

The AC input connector is a header (Phoenix Contact P/N:PC6-16/4-GF-10,16) with a screw plug in
connector (Phoenix Contact P/N:PC 6/4-STF-10,16), located on the rear panel.
Use suitable wires and tightening torque as follows:
1. Wire diameter:.
12AWG for three-phase 200V models and
14AWG for three-phase 400V models. Refer to Table 1-1 for details.
2. Tightening torque: 10.7-13.4Lb-inch. (1.2-1.5Nm).

3.7.2 AC Input Cord

Refer to Section 1.3.4 for details of the AC input cords and to section 3.7 for disconnected device
requirement.

3.7.3 AC Input Wire Connection

1. Strip the outside insulation of the AC cable approx. 10cm (3.94 inches). Trim the wires so that
the ground wire is 10mm longer than the other wires. Strip 10mm (0.4 inches) at the end of
each of the wires.
There is a potential shock hazard if the power supply chassis
(with cover in place) is not connected to an electrical safety
ground via the safety ground in the AC input connector.
Some components inside the power supply are at AC voltage
even when the On/Off switch is in the "Off" position. To avoid
electric shock hazard, disconnect the line cord and load and
wait two minutes before removing cover.
The AC input cord is not provided with the power supply
CAUTION
WARNING
WARNING
WARNING
15
83-515-000 Rev. B
