driver software anyway" option to proceed.
4. Once the driver is installed, click the Close button.

Verifying Installation

Windows 2000/Server 2003/XP/Vista/7
From the main desktop, right-click on "My Computer" ("Computer" in
Vista), then select Manage. In the new Computer Management window,
select Device Manager from the left window panel.
Double-click on the "Ports (COM & LPT)" option. An additional USB
serial COM port should be visible. The port is ready to connect to new
devices.

DIP Switch Settings

Switch Switch Name
1 485/422
2 Echo/No Echo
3 No Term/Term
4
Switch
Position
(default)
No Echo
(default)
No Term
(default)
None On/Off
485
2-wire RS-485 mode
422 4-wire RS-422 mode
Transmitting data will be
Echo
Terminator resistor is
Terminator resistor is
Term
Switch is not enabled
3
Description
echoed back.
No data echo
disabled
enabled
