3-5 Battery charger usage

Optional
1. Insert the battery into the battery holder as shown above
2. Connect the DC JACK to the power electrical outlet.
3. Plug the power code into the electrical outlet.
4. Once the charging is completed, remove the battery from the holder.
3-5-1 The status of lamp in charging
Status charging
Red
Charging Lamp
NOTE
In the case the battery is not fixed properly in the holder, the red lamp will be
blinking, Then, extract and reinsert the battery.
8
Lamp
DC Jack
charging complete
Green

3-6 Usage of Cigar Jack for charging

Optional
Battery holder
Connect the car cigar JACK charger into the printer or battery holder.
Input
12 ~ 24V
Output
8.4V 0.8 ~ 1.2A
NOTE
Use the Cigar Jack offered by the manufacturer
Printer
.
