Position
S2
S3
S4
S5
S6
S7
S8
S9
S10
When the system maintenance switch position 6 is set to the On position, the system is prepared to erase
all system configuration settings from both CMOS and NVRAM.
CAUTION:
properly configure the server or data loss could occur.

HP c-Class Blade SUV Cable

Item Connector
1 Server blade
Default Function
Off Off = System configuration can be
changed.
On = System configuration is
locked.
Off Reserved
Off Reserved
Off Off = Power-on password is
enabled.
On = Power-on password is
disabled.
Off Off = No function
On = Clear NVRAM
— Reserved
— Reserved
— Reserved
— Reserved
Clearing CMOS and/or NVRAM deletes configuration information. Be sure to
Description
For connecting to the SUV connector on the
server blade front panel
Component identification 11
