CAUTION: To avoid damage to the system board:
Do not touch the processor socket contacts.
•
• Always install the processor socket cover after removing the processor from the socket.
Do not tilt or slide the processor when lowering the processor into the socket.
•
CAUTION: To avoid damage to the processor:
Handle the processor only by the edges.
•
Do not touch the bottom of the processor, especially the contact area.
•
CAUTION: To prevent possible server blade malfunction and damage to the equipment,
multiprocessor configurations must contain processors with the same part number.
CAUTION: To prevent possible server blade overheating, always populate processor socket 2
with a processor and a heatsink or a processor socket cover and a heatsink blank.
CAUTION: The heatsink thermal interface media is not reusable and must be replaced if the
heatsink is removed from the processor after it has been installed.
IMPORTANT:
bracket with the alignment holes in the heatsink.
IMPORTANT:
server blade does not power up.
NOTE: Do not discard the processor protective cover. Always install the processor protective
cover if the processor is removed from the socket.
IMPORTANT:
processor, update the system ROM before installing the processor.
To install the component:
Update the system ROM.
1.
Locate and download the latest ROM version from the HP website (http://www.hp.com/support).
Follow the instructions on the website to update the system ROM.
Power down the server blade (on page 13).
2.
Remove the server blade (on page 14).
3.
Remove the access panel (on page 15).
4.
If installed, disconnect the hard drive power and data cables from the system board.
5.
Remove the air baffle (on page 15).
6.
Open the processor retaining latch and the processor socket retaining bracket.
7.
When installing the heatsink, align the guide pins on the processor retention
Processor socket 1 must always be populated. If processor socket 1 is empty, the
When installing a processor with a faster speed or adding an additional
Hardware options installation 25
