SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARNING:
If the information in this
manual is not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of
life. Installation and service must be
performed by a qualified installer, service
agency or the gas supplier.
- Do not store or use gasoline or other
flammable vapours and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
-
• Open windows/extinguish any open
flame.
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Immediately call your gas supplier from
a neighbour's phone.
supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
- Installation and service must be performed
by a qualified installer, service agency or
the gas supplier.
This appliance may be installed in an aftermarket permanently located, manufactured home (USA only) or
This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a certified kit is used.
Sienna
OWNER'S
Massachusetts installations (Warning): This product must
be installed by a licensed plumber or gas fitter when
Follow the gas
installed within the Commonwealth of Massachusetts. Other
Massachusetts code requirements: Flexible connector must
not be longer than 36in., a shut off valve must be installed;
only direct vent sealed combustion products are approved for
bedrooms/bathrooms. A carbon monoxide detector is required
in all rooms containing gas-fired direct vent appliances. The
fireplace damper must be removed or welded in the open
position prior to installation of a fireplace insert.
mobile home, where not prohibited by local codes.
B Y : S H E R W O O D I N D U S T R I E S L T D
MANUAL
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
50-1096
Advertisement
Table of Contents
Related Manuals for Enviro C-11212
Summary of Contents for Enviro C-11212
- Page 1 SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Safety Precautions
Safety Precautions FOR SAFE INSTALLATION AND OPERATION OF YOUR “ENVIRO” HEATER, PLEASE CAREFULLY READ THE FOLLOWING INFORMATION: • All ENVIRO gas-fired appliances must be installed in accordance with their instructions. Carefully read all the instructions in this manual first. Consult the building authority having jurisdiction to determine the need for a permit prior to commencing the installation. -
Page 3: Table Of Contents
Table of Contents Safety Precautions...2 Table of Contents...3 Codes And Approvals...4 Specifications...5 Rating Label Location...5 Dimensions...5 Operating Instructions...7 Pilot Lighting Instructions...7 Burner Lighting...7 Remote Controls - Optional...7 Turn Off Unit...8 Blower Speed...8 Normal Sounds During Operation...8 Adjusting Venturi Air Settings...8 Maintenance And Service...9 Cleaning The Glass...9 Cleaning The Firebox and Burner...9... -
Page 4: Codes And Approvals
TESTED TO: ANSI Z21.88a-2003/CSA 2.33a-2003 VENTED GAS FIREPLACE HEATERS CAN/CGA 2.17-M91 GAS-FIRED APPLIANCES FOR HIGH ALTITUDES CSA P.4.1-02 TESTING METHOD FOR MEASURING ANNUAL FIREPLACE EFFICIENCY This ENVIRO SIENNA Fireplace: • Has been certified for use with either natural or propane gases. (See rating label.) •... -
Page 5: Specifications
ATING ABEL OCATION The rating label is located under the control panel and is attached to a rectangular metal sheet that is chained to the fireplace. IMENSIONS Table 1: Sienna exterior dimensions. (Shaded dimensions shown in Figure 1 & 2.) Surround Style Arched Surround 33”... - Page 6 21" (533 mm) With Trim 46 Without Trim 46" (1168 mm) " (775 mm) Figure 2: Sienna exterior dimensions; example 2. Specifications Sensor Flue (441 mm) " (333 mm) " (1171 mm) " (383 mm) Shown: B-Vent with 33" x 46" (84cm x 193 cm) surround panel with trim "...
-
Page 7: Operating Instructions
Operating Instructions For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OF LOSS OF LIFE. ILOT IGHTING NSTRUCTIONS Hot while operating. -
Page 8: Turn Off Unit
After the unit has gone through the first burn, turn the unit OFF, including the pilot, and let the unit get completely cold. Then remove the glass and clean it with a good gas fireplace glass cleaner, available at your local Enviro dealer. See “D ” sections. -
Page 9: Maintenance And Service
When the glass door assembly is being transported, it must be wrapped in newsprint and tape and/or a strong plastic bag. The glass must be purchased from an ENVIRO dealer. No substitute materials are allowed. LEANING... -
Page 10: Glass Door Removal
Maintenance And Service LASS EMOVAL Figure 8: Top bolts for glass door. & B URNER LOWER EMOVAL 1. Turn the unit off and allow the unit to cool completely. 2. Remove the fascia or louvers, open the door (see M AINTENANCE AND ERVICE ), and remove the log set. -
Page 11: Fuel Conversion
Maintenance And Service ONVERSION TO BE INSTALLED BY A QUALIFIED SERVICE AGENCY ONLY Please read and understand these instructions before installing. Warning: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction. - Page 12 Maintenance And Service Loosen Tighten Figure 12: Removing valve screw. g) Re-attach the black protection cap that was removed in step a (Figure 11). Reinstall the burner, brick panels, log set, embers, and glass door. Also refer to S ECONDARY NSTALLATION NSTALLING ET AND...
-
Page 13: Initial Installation
Initial Installation WARNING: Operation of this heater when not connected to a properly installed and maintained venting system can result in carbon monoxide (CO) poisoning and possible death. LEARANCES TO OMBUSTIBLES Maintain sufficient clearances for operation, service and maintenance. • A clearance of 25 1⁄2” (648 mm) minimum is required from the center of the unit to the sidewalls. •... -
Page 14: Minimum Fireplace Size
Initial Installation WARNING: Operation of this heater when not connected to a properly installed and maintained venting system can result in carbon monoxide (CO) poisoning and possible death. INIMUM IREPLACE Table 2: Minimum dimensions of fireplace for Sienna to be installed into. Description of Fireplace Dimension At Back Width... -
Page 15: Direct Vent Model
4. Remove the vent collar plate from the top of the stove by unscrewing the two (2) T-20 Torx screws located on the center top of the stove. Slide the collar plate backwards. If the fireplace that the unit is to be installed into is high, the collar plate does not need to be removed. -
Page 16: Venting Fireplace Inserts
IREPLACE NSERTS The ENVIRO SIENNA may be installed and vented into any solid fuel fireplace that has been installed in accordance with the National, Provincial/State and local building codes and has been constructed of non-combustible materials. This appliance must not be connected to a chimney flue serving a separate solid fuel-burning appliance. -
Page 17: Zero Clearance Fireplace Installation
Initial Installation QUALIFIED INSTALLERS ONLY Minimum Clearance Clearance above the highest point where it passes through a roof surface, refer 3 ft (0.9 m) to Figure 21. Clearance above a roof ridge, any other portion of a building, or any other ob- 24 in (0.6 m) struction within a horizontal distance of 10 feet (3 m), refer to Figure 21. -
Page 18: Electrical Requirements
Initial Installation LECTRICAL EQUIREMENTS Figure 22: Fan wiring diagram. Optional Remote Control 7 0 ° F Purple Blue BV Only 7 0 ° F F (149 Temperature Sensor D O W N C O O L / H E A T (DV has only P R O G R A M connectors) -
Page 19: Gas Line Connection
Initial Installation QUALIFIED INSTALLERS ONLY ONNECTION Warning: Only persons licensed to work with gas piping may make the necessary gas connections to this appliance. Gas Line Connection: •This fireplace is equipped with a certified flexible pipe located on the right side of the unit, terminating in a 3⁄8”... -
Page 20: Converting A Direct Vent Fireplace To A B-Vent Fireplace
Initial Installation ONVERTING IRECT 1. Remove Direct chimney connector assembly by taking out the two (2) T-20 screws at the front of the unit. Push the assembly out from under the brackets at the back and remove (see Figure 24). 2. -
Page 21: Secondary Installation
Secondary Installation NSTALLATION OF URROUND The Sienna must have one of the panels installed around the unit; the unit panel, the filler panel, or the filler panel with trim. If you have trim for your filler panel, the trim must be installed before installing the filler panel onto the unit. -
Page 22: Log Set And Ember Installation
Secondary Installation ET AND MBER NSTALLATION NOTE: The logs are fragile and should be handled gently. The placement of the logs is not arbitrary. If they are positioned incorrectly, the flames can be “pinched” and will not burn correctly. The burner, and a few of the logs come with locator pins, notches and ledges, which make alignment easier. - Page 23 Secondary Installation Figure 34: The front end of the right/center log has a notch in it that is to rest around the right/center post of the grate. The back end of the log rests on the burner tray (see Figure 33). Ensure the log does not block any burn ports.
- Page 24 Secondary Installation Figure 37. Sienna complete log set-up with embers burning. NOTE: While the glass is still removed, it is recommended that the gas line be purged by lighting the pilot. Re-install the glas door. Never operate the fireplace with the glass door removed. When lighting the fireplace for the first time since the log set and embers have been installed/replaced, watch for ignition at ALL the burner ports.
-
Page 25: Removing The Brick Panel
Secondary Installation EMOVING RICK ANEL The brick panel set is fragile, handle with extreme care. The brick panel set comes pre-installed. The centre and top panel are the only panels that need to be removed if the complete gas and electrical tray assembly must be removed. The side panels may remain installed unless they are to be replaced. -
Page 26: Trouble Shooting
Trouble Shooting Problem Possible Cause The main burner The gas valve may not be on. does not ignite Thermostat is not calling for when called for. heat. Problem with gas valve. Spark will not Defective piezo ignitor. light the pilot after repeatedly Broken spark electrode. -
Page 27: Parts List- Unit Components
Parts List- Unit Components Replacement parts must be purchased from an ENVIRO dealer. Reference # Part Description 120°F Ceramic Fan Temperature Sensor 300°F (149°C) Manual Reset Spill Switch (Normally Closed) S.I.T. Nova Valve Convertible Thermocouple Spark Electrode with Ignitor Cable... -
Page 28: Parts Diagram - Components
Parts Diagram - Components... -
Page 29: Parts Diagram - Burner
Parts Diagram - Burner �� �� �� � � �� � �� � � � � SIENNA - Burner � October 2004... -
Page 30: Parts List - Options
Parts List - Options Reference Number Option Description The Cottage Trim Kit - Gold The Cottage Trim Kit - Pewter The Cottage Trim Kit - Antique Copper The Cottage Trim Kit - Painted Black Cape Cod Doors Unit Panel & Keystone Cottage Filler Panel Louvers (set of 2) -
Page 31: Parts Diagram - Options
Parts Diagram - Options �� �� �� �� �� �� �� SIENNA - Options October 2004... -
Page 32: Warranty
Industries, our commitment to the highest level of quality and customer service is the most important thing we do. Each Enviro stove is built on a tradition of using only the finest materials and is backed by our Exclusive Lifetime Limited Warranty to the original purchaser. With Enviro, you’re not just buying a fireplace or stove, you’re buying a company with years of unequalled performance and quality. - Page 33 Sherwood Industries Ltd. The use of such products may nullify the Limited Warranty on this stove. If unsure as to the extent of this Limited Warranty, contact your authorized Enviro dealer before installation.
-
Page 34: Installation Data Sheet
If the stove is used for commercial purposes, it is excluded from the Limited Warranty. 24. No dealer, distributor, or similar person has the authority to represent or warrant Enviro products beyond the terms contained within the Limited Warranty. Sherwood Industries Ltd. assumes no liability for such warranties or representations. -
Page 35: Installation Data Sheet
6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 NAME OF DEALER: _________________________________________ ADDRESS: _________________________________________ _________________________________________ _________________________________________ PHONE:___________________________________ NAME OF INSTALLER: _________________________________________ (dd/mm/yyyy) ADDRESS: (dd/mm/yyyy) _________________________________________ B-VENT _________________________________________ PROPANE(LPG) _________________________________________ PHONE:___________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. www.enviro.com February 19, 2007 C-11212...
