OWNER'S MANUAL
WARNING
If the information in this manual
is not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of
life. Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
FOR YOUR SAFETY: Do not store or use gasoline or other Flammable vapours and liquids in
Massachusetts installations (Warning): This product must be installed by a licensed
plumber or gas fitter when installed within the Commonwealth of Massachusetts. Other
Massachusetts code requirements:-Flexible connector must not be longer than 36
inches, shut off valve must be a "T" handle gas cock, only direct vent sealed combustion
products are approved for bedroom/bathrooms, fireplace dampers must be removed or
welded in the open position prior to the installation of a fireplace insert or gas log.
ASCOT
the vicinity of this or any other appliance.
B Y : S H E R W O O D I N D U S T R I E S L T D
WHAT TO DO IF YOU SMELL GAS
• Open windows/Extinguish any open flame.
• Do not try to light any appliance.
• Do not touch any electrical switch or use any
phone in your building.
• Immediately call your gas supplier from a
neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
This appliance may be installed in an after market
permanently located, manufactured (mobile) home,
where not prohibited by local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certified kit is used.
50-029

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ascot 50-029 and is the answer not in the manual?

Questions and answers

Summary of Contents for Enviro Ascot 50-029

  • Page 1 SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE OWNER’S MANUAL WARNING If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
  • Page 2: Safety Precautions

    Safety Precautions FOR SAFE INSTALLATION AND OPERATION OF YOUR “ENVIRO” HEATER, PLEASE CAREFULLY READ THE FOLLOWING INFORMATION: • All ENVIRO gas-fired appliances must be installed in accordance with their instructions. Carefully read all the instructions in this manual first. Consult the building authority having jurisdiction to determine the need for a permit prior to commencing the installation.
  • Page 3: Table Of Contents

    Table of Contents Safety Precautions...2 Table of Contents...3 Codes And Approvals...4 Specifications...5 Dimensions...5 Clearances to Combustibles...5 Operating Instructions...6 Lighting Instructions...6 Pilot Light...6 Maintenance And Service...7 Routine Maintenance...7 Cleaning The Glass...7 Cleaning The Firebox...7 Change Battery in Ignition Module...7 Replacing Glass...8 Opening The Door...8 Fuel Conversion...9 Initial Installation...10...
  • Page 4: Codes And Approvals

    After the unit has gone through the first burn, turn the unit off including the pilot, let the unit get cold then remove the glass door and clean it with a good gas fireplace glass cleaner, available at your local ENVIRO dealer.
  • Page 5: Specifications

    IMENSIONS �� � � � �� �������� �� � � � �� �������� �� � � �� �� �������� �� � � � �� �������� LEARANCES TO OMBUSTIBLES A) Sidewall to unit 10 inches (254 mm) B) Backwall to unit 21⁄2 inches (64 mm) C) Corner to unit 21⁄2 inches (64 mm)
  • Page 6: Operating Instructions

    Operating Instructions FOR YOUR SAFETY READ COMPLETELY BEFORE OPERATING. IGHTING NSTRUCTIONS CAUTION: FOR YOUR SAFETY: Do not operate this fireplace with the glass removed, cracked or broken. Replacement of this glass should be done by a licensed or qualified person! This appliance needs fresh air for safe operation and must be installed with provisio ns for combustion and ventilation air.
  • Page 7: Maintenance And Service

    Replace the logs and embers as in the L ET AND MBER NSTALLATION your nearest ENVIRO dealer. HANGE ATTERY IN GNITION If the unit does not spark when lighting, the battery in the electronic ignition could need replacing.
  • Page 8: Replacing Glass

    Do not operate with the glass front removed, cracked or broken. Removal and replacement of the glass from the door must be done by a licensed or qualified service person. The glass must be purchased from an ENVIRO dealer. No substitute materials are allowed.
  • Page 9: Fuel Conversion

    Maintenance And Service TO BE INSTALLED BY A QUALIFIED SERVICE AGENCY ONLY ONVERSION Warning: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction.
  • Page 10: Initial Installation

    Initial Installation ERMINATION ESTRICTIONS Fixed Closed Openable Termination Cap Letter Canadian Installation 12 in (30 cm) 12 in (30 cm) 12 in (30 cm)* 24 in (60 cm)* 18 in (45 cm)* 12 in (30 cm)* 12 in (30 cm)* 3 ft (91 cm) within a height of 15 ft (4.5 m) above the meter/ regulator assembly...
  • Page 11: Vent Parts

    Initial Installation ARTS Simpson Duravent (SD), Selkirk (SEL), and Security Chimneys (SC), must state if galvanized or black wanted, PART NUMBERS: Description 4DT-6 SV4L6 6” pipe length 4DT-9 9” pipe length 4DT-12 SV4L12 12” pipe length 4DT-24 SV4L24 24” pipe length 4DT-36 SV4L36 36”...
  • Page 12: Vent Restrictor Setting

    Initial Installation ESTRICTOR ETTING To access restrictor plate, look at the left hand rear corner of the unit. There is a small rectangular hole in the air jacket Loosen the 1⁄4” hex head bolt and adjust to the correct setting. Slide the hex bolt to the next setting and retighten the bolt to ensure the plate does not move...
  • Page 13: Planning Your Installation

    Initial Installation QUALIFIED INSTALLERS ONLY LANNING NSTALLATION When planning your installation, it will be necessary to select the proper length of vent pipe for your particular requirements. It is important to note when passing through a wall, the maximum allowable wall thickness is 10 inches (25.4 cm), 11⁄2 inches (3.8 cm) clearance to combustibles must be maintained.
  • Page 14: Horizontal Installation

    Initial Installation ORIZONTAL NSTALLATION STEP 1. Set the appliance in the desired location. Check to determine if wall studs or roof rafters are in the way when the venting system is attached. If this is the case, you may want to adjust the location of the appliance.
  • Page 15 Initial Installation QUALIFIED INSTALLERS ONLY STEP 3. With the pipe attached to the stove in the correct location, mark the wall for a 10” (25.4 cm) x 10” (25.4 cm) square hole (refer to Figure 13). The center of the square hole should match the center line of the horizontal pipe.
  • Page 16 Initial Installation Interior Wall Surface Inside Finished Collar If installed on a carpeted surface a hearth is required Figure 17: Straight Through Wall Installation. NOTE: Vent pipe must not be longer than 18” (457 mm) maximum when installing straight through exterior wall. Maintain manufacturer’s clearances to combustibles with venting.
  • Page 17: Vertical Installation

    Initial Installation QUALIFIED INSTALLERS ONLY ERTICAL NSTALLATION STEP 1. Check the instructions for required clearances (air spaces) to combustibles when passing through ceilings, walls, roofs, enclosures, attic rafters, or other nearby combustible surfaces. Do not pack air spaces with insulation. STEP 2.
  • Page 18 Initial Installation STEP 6. Once the pipe sections have been joined, and run up through the hole in the roof, slip an elbow strap over the exposed sections, bend the support straps outwards, and push the elbow strap down to the roof level, as shown in Figure 21. Tighten the clamp around the pipe section. Use a level to make sure the pipe is truly vertical.
  • Page 19: Freestanding Drafthood Adaptor

    Initial Installation QUALIFIED INSTALLERS ONLY REESTANDING RAFTHOOD DAPTOR This Drafthood Adaptor is a complete assembly and is ready to fit onto your Westport in a vertical vent application only. With the Drafthood Adaptor correctly installed and wired to the gas control valve. Your Direct Vent Fireplace can be vented like a B-Vent Fireplace.
  • Page 20: General Venting Information

    Initial Installation GENERAL VENTING INFORMATION: Canadian Installations The venting system must be installed in accordance with the current CSA B149 installation code and/or local codes having jurisdiction. U.S.A. Installations The venting system must be installed in accordance with the current National Fuel Gas Code, ANSI Z223.1, and/or local codes having jurisdiction.
  • Page 21: Automatic Safety Shut Down

    Initial Installation 4. After a minimum of 10 minutes operation, test the chimney draft with a smoke match at the top row of the pattern to confirm that there is adequate draft or ‘pull’ at the openings around the body of the Drafthood Adaptor, as shown in Figure 26.
  • Page 22: Hearth Mount Installation

    Initial Installation EARTH OUNT NSTALLATION This unit may be installed as a hearth mounted unit. Install two 3’ inch pipes up the chimney to a seal plate and cap assembly, one exhaust pipe, and one air intake pipe Using venting manufactures coaxial to co-linear adapters at the unit and at the chimney termination. Maximum vertical chimney height 15 feet (4.57 m) 2"-3"...
  • Page 23: Gas Line Connection And Testing

    Initial Installation ONNECTION AND ESTING WARNING: Only persons licensed to work with gas piping may make the necessary gas connections to this appliance. GAS LINE CONNECTION This stove is equipped with a certified flexible pipe located on the right side of the unit terminating in •...
  • Page 24: Electrical Requirements

    LECTRICAL EQUIREMENTS The ENVIRO ASCOT will operate without electrical power. This model has a millivolt gas control, which uses the pilot flame to generate enough electricity to operate the main burners. The appliance when equipped with an optional blower must be electrically connected and grounded in accordance with local codes or in the absence of local codes, with the current CSA C22.1 CANADIAN ELECTRICAL CODE Part...
  • Page 25: Secondary Installation

    If over time, through cleaning and servicing, these embers replacement, contact the nearest ENVIRO dealer for replacement embers. 1. Carefully remove logs from box. Check to ensure there is no damage. It is very important to install all logs in their proper position to insure safe, optimum operating conditions.
  • Page 26 After the unit has gone through the first burn turn the unit off including the pilot, let the unit get cold then remove the glass door and clean it with a good gas fireplace glass cleaner, available at your local ENVIRO dealer. See Routine M AINTENANCE CAUTION: NEVER OPERATE THIS APPLIANCE WITH THE DOOR REMOVED.
  • Page 27: Trouble Shooting

    Trouble Shooting Problem Possible Cause Spark will not light the Defective piezo ignitor. pilot after repeatedly pressing the spark ignitor Broken spark electrode. Low battery or bad electronic module. Misaligned spark electrode. Pilot will not remain lit Problem with thermocouple circuit Air in gas line (pilot dies while knob is depressed)
  • Page 28: Parts List

    Reference Description Number 120°F (49°C) Ceramic Fan Temperature Sensor S.I.T. Nova Valve NG (50% turn down) S.I.T. Nova Valve LP (50% turn down) Thermocouple Spark Electrode with Ignitor Cable Thermopile Pilot Orifice NG Threaded Pilot Orifice LP Threaded Pilot Gasket SS Flex Connector 3⁄8”...
  • Page 29 Reference Description Number Dual Convection Blower (no mount) - 115V Burner Switch Wiring Harness Fan Kit Wiring Harness Electronic Ignition Module Dual Bulb Door Gasket (10 ft) Glass with Gasket Hinge pin - silver Drafthood Adaptor (Complete) Drafthood Adaptor Spill Switch Assembly (with Wiring Harness) Drafthood Adaptor Decorative Brass Ring Three Flame Pilot Hood Cast Description...
  • Page 30 Reference Cast Description Number Side panel (left)- Wedgewood Blue Side panel (left)- Westport Green Side panel (left) - Antique Chestnut Cast ash shelf - Painted Black Cast ash shelf - Antique White Cast ash shelf - Diamond Black Cast ash shelf - Inferno Red Cast ash shelf - Pearl Grey Cast ash shelf - Wedgewood Blue Cast ash shelf - Westport Green...
  • Page 31: Parts Diagram

    Parts Diagram...
  • Page 32: Warranty

    Warranty Sherwood Industries Ltd. offers a Limited Lifetime Warranty on this gas product. This limited lifetime warranty covers the appliance for a period of seven years from the date of installation. This warranty applies only to the original owner in the original location Covered under the lifetime warranty are, Surround Panels and Chassis and Heat Exchanger.
  • Page 33: Installation Data Sheet

    Installation Data Sheet The following information must be recorded by the installer for warranty purposes and future reference. NAME OF OWNER: _________________________________________ ADDRESS: _________________________________________ _________________________________________ _________________________________________ PHONE:___________________________________ MODEL:___________________________________ SERIAL NUMBER:___________________________ DATE OF PURCHASE: _____________ DATE OF INSTALLATION:___________ � � NATURAL GAS (NAT) INLET GAS PRESSURE:_________in wc MAIN BURNER ORIFICE:__________# DMS PILOT ORIFICE #_________OR________in diam.
