Type [Auto]
Selects the type of IDE drive. Setting to Auto allows automatic selection of the appropriate
IDE device type. Select CDROM if you are specifically configuring a CD-ROM drive. Select
ARMD (ATAPI Removable Media Device) if your device is either a ZIP, LS-120, or MO drive.
Configuration options: [Not Installed] [Auto] [CDROM] [ARMD]
This item only appears in the Primary IDE Master/Slave menus.
LBA/Large Mode [Auto]
Enables or disables the LBA mode. Setting to [Auto] enables the LBA mode if the device
supports this mode, and if the device was not previously formatted with LBA mode disabled.
Configuration options: [Disabled] [Auto]
Block (Multi-Sector Transfer) M [Auto]
Enables or disables data multi-sectors transfers. When set to [Auto], the data transfer from
and to the device occurs multiple sectors at a time if the device supports multi-sector transfer
feature. When set to [Disabled], the data transfer from and to the device occurs one sector
at a time. Configuration options: [Disabled] [Auto]
PIO Mode [Auto]
Selects the PIO mode. Configuration options: [Auto] [0] [1] [2] [3] [4]
DMA Mode [Auto]
Selects the DMA mode. Configuration options: [Auto]
SMART Monitoring [Auto]
Sets the Smart Monitoring, Analysis, and Reporting Technology.
Configuration options: [Auto] [Disabled] [Enabled]
32Bit Data Transfer [Enabled]
Enables or disables 32-bit data transfer. Configuration options: [Disabled] [Enabled]
2.3.5

Storage Configuration

The items in this menu allow you to set or change the configurations for the SATA devices
installed in the system. Select an item then press <Enter> if you want to configure the item.
ATA/IDE Configuration [Enhanced]
Allows you to set the ATA/IDE configuration.
Configuration options: [Disabled] [Compatible] [Enhanced]
[Disabled] - Disables the integrated SATA and PATA controller.
[Compatible] - Sets all SATA devices to operate in PATA mode. This allows a
[Enhanced] - Sets all SATA devices to operate in SATA mode.
Enhanced Mode Support On [S-ATA]
Sets Serial ATA, Parallel ATA or both as native mode.
Configuration options: [S-ATA] [S-ATA+P-ATA] [P-ATA]
2-10
maximum of four (4) ATA devices to be used simultaneously:
two PATA devices and two SATA mode.
