FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation.
TRADEMARK INFORMATION ® ® Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation. ® Pentium is a registered trademark of Intel Corporation. Macintosh is a trademark of Apple Computer, Inc. is a trademark. Other names and products may be trademarks or registered trademarks of their respective owners. READ THIS FIRST Notice: 1.
Safety Instructions Read and understand all Warnings and Cautions before using this product. WARNING If foreign objects or water have entered the camera, turn the power OFF and remove the battery and the AC power adapter. Continued use in this state might cause fire or electric shock. Consult the store of purchase. If the camera has fallen or its case has been damaged, turn the power OFF and remove the battery and the AC power adapter.
CAUTION Insert the battery paying careful attention to the polarity (+ or –) of the terminals. Inserting the battery with its polarities inverted might cause fire and injury, or damage to the surrounding areas due to the battery rupturing or leaking. Do not fire the flash close to anyone’s eyes.
Notes on Battery Usage When you use the battery, carefully read and strictly observe the Safety Instructions and the notes described below: Use only the specified battery (3.7V). Avoid using the battery in extremely cold environments as low temperatures can shorten the battery life and reduce camera performance.
CONTENT 32 Using the Optical Zoom 33 Using the Digital Zoom INTRODUCTION 34 Setting the Flash Overview 37 Setting the Self-timer 10 Package Contents 38 Exposure Compensation/Backlight Correction 11 GETTING TO KNOW THE CAMERA 39 [SCN] Scene Mode 41 [P] Program (Automatic Exposure) Photography 11 Front View Mode 12 Rear View...
56 Slideshow Display 57 Protecting Images 59 DPOF Settings 61 Copying Files from Internal Memory to a Memory Card 62 Changing the Camera Start Logo Image 63 [ ] Deleting Images 66 MENU OPTIONS 66 Photography Menu (Capture tab) 69 Photography Menu (Function tab) 71 Photography Menu (AE/AWB tab) 73 Playback Menu 74 Setup1 Menu...
INTRODUCTION Overview Congratulations on your purchase of the new digital camera. Capturing high-quality digital images is fast and easy with this state-of-the-art smart camera. Equipped with an 10.1 Mega pixel CCD, this camera is capable of capturing images with a resolution of up to 3648 x 2736 pixels.
Thumbnail display - Display your images in sets of nine on the LCD monitor for quick selection of an particular image. TV and PC connection - You may view your images on a television monitor or a computer using the USB or A/V cables.
Package Contents Carefully unpack your kit box and ensure that you have the following items: Digital Camera A/V cable USB cable User’s manual Software CD-ROM Camera strap Camera pouch Optional Accessories: SD memory card AC power adapter Rechargeable lithium-ion battery Battery charger Accessories may vary by retailer.
GETTING TO KNOW THE CAMERA Front View # Name Description 1. Mode dial Sets the camera mode. 2. Shutter button Focuses and locks both focus & exposure when pressed halfway down. Captures the image when pressed all the way down. 3.
Rear View Name Description Provides menu information to operate the camera, previews the image LCD monitor before capturing it and review it afterwards. Status LED Displays the camera current state. Zoom in button Zooms the lens to telephoto position. Zoom out button Zooms the lens to wide-angle position.
SET /Direction button Name Description button Scrolls upwards. Changes value of shutter speed, aperture, exposure compensation and manual focus. button Scrolls right. Flash button Allows you to choose the appropriate flash setting. button Scrolls downwards. Changes value of shutter speed, aperture, exposure compensation and manual focus.
Mode dial Name Description Auto The camera automatically sets for exposure, etc. 2. SCN Scene Mode Point-and-shoot simplicity when capturing images under 16 special conditions. 3. P Program In program mode the shutter speed and aperture will be set automatically, (auto exposure) but other parameters may be set manually.
Status LED Indicator The status LED indicates the current operational status of the camera. The meaning of the LED changes depending upon what the camera is doing. During During connection to a Color During power off State photography AE or AF is locked with T h e c o m p l e t i o n o f the shutter button held Green...
LCD Monitor Icons For Photography modes: [ ], [ SCN ] Mode icon Continuous [ AEB] Auto Exposure Date and time 01/08/2008 12:38 Flash mode Bracketing [Blank] Automatic Burst Red-eye Reduction Pre-Shot Forced Flash ] Coupling Shot Flash Off * In [SCN] mode, Night Battery condition Portrait and Fireworks can ] Full battery power...
For Photography modes: [P], [Tv], [Av], [M], [ ], [ ] Mode icon 2 . Date and time 01/08/2008 Flash mode 12:38 Battery condition Storage media Voice memo Histogram Main focus area Capture mode icon F2.8 1/200 00004 10. Image quality 11.
For Photography mode: [ ] 1. Mode icon 2. Image to be captured indicator 3. Flash mode 4. Battery condition 5. Storage media 6. White balance 7. Metering 8. Main focus area 00004 9. Image quality 10. Image resolution 11. Available number of shots 12.
For Video mode [ 1. Mode icon 2. Date and time 01/08/2008 3. Battery condition 12:38 4. Storage media 5. Self-timer icon 6. Video quality 7. Video resolution 8. Available recording time/Elapsed time 9. Zoom status 0:18 10. White balance icon 11.
GETTING STARTED Attaching the Camera Strap Attach the camera strap as shown in the illustration. Inserting and Removing the Battery We highly recommend using specified rechargeable lithium-ion battery (3.7V) to realize the full capability of your camera. Charge the battery fully before using the camera. Make sure that the power of the camera is off before inserting or removing the battery.
Charging the Battery Using the optional AC power adapter may charge the battery or operate the camera as power supply. Make sure that the power of the camera is off and then insert the battery before starting. 1. Insert one end of the AC power adapter into the DC IN 5V terminal of the camera.
Using an AC Power Adapter Using an AC power adapter prevents the camera from automatically powered off while transferring files to your computer. Perform the steps in the preceding section “Charging the Battery”. Make sure to use only the AC power adapter specified for the digital camera. Damage caused by the use of an incorrect adapter is not covered under the warranty.
Turning the Power On/Off 1. Load the battery or connect the AC power adapter to your camera. 2. Press the POWER button to turn on your camera. The status LED lights green and the camera is initiated. The power indicator lights on when the camera power is turned When the power is turned on, the camera will start in the mode that is currently selected.
Setting the Date and Time The date/time needs to be set if/when: Camera is turned on for the first time. Camera is turned on after leaving the camera without the battery for an extended period of time. When the date and time information is not displayed on the LCD monitor, follow these steps to set the correct date and time.
5. Select [Format] with buttons,and press the SET button. Select the date display format you want with buttons. Setup 2006 6. Select [On/Off] with buttons,and press the SET button. MENU:Exit SET:Enter If your choice is Off, there is no date/time information displayed on the LCD monitor.
Formatting an SD Memory Card or Internal Memory This function formats the internal memory (or memory card) and deletes all stored still images / video clips and data. 1. Slide the mode switch to [ ], and press the MENU button. 2.
Setting Image Resolution and Quality Resolution and quality settings determine the pixel size (dimension), image file size, and compression ratio for your images. These settings affect the number of images that can be stored. As you get to know the camera, it is recommended that you try each quality and resolution setting to get an appreciation for the effects that these settings will have on your images.
Possible number of shots (still image) The following table shows the approximate shots that you can capture at each setting based on the capacity of the internal memory and an optional SD memory card. SD memory card capacity Internal Size Quality Memory 32MB 64MB 128MB 256MB...
Possible recording time / sec (video clip) SD memory card capacity Internal Quality Size Memory 256MB 32MB 64MB 128MB 512MB Fine 0:28 0:31 1:04 2:11 4:21 8:46 16:52 34:19 640 x 480 Standard 0:39 0:43 1:29 3:00 6:00 12:05 23:15 47:17 Frame rate of video recording would be different depending on the SD memory card access speed.
PHOTOGRAPHY MODE ] Auto Mode Auto photography mode is the most commonly used photography mode. Images can be captured simply because the exposure (the combination of shutter speed and aperture setting) is determined automatically to suit the photographic conditions. Your camera is equipped with a 2.8” TFT color LCD monitor to help you compose images, playback recorded images/movie clips or adjust menu settings.
Recording Voice Memos A voice memo can be recorded once for 30 seconds at still image mode immediately following a still image capture. 1. Slide the mode switch to [ ] and set the mode dial to one of the photography modes, except for [ ] and [ ] modes.
Using the Optical Zoom Zoom photography allows you to capture images magnified up to 6 times or wide-angle photography depending on the distance up to the subject. You can also enlarge the center of the screen and capture images in the digital zoom mode. 1.
Using the Digital Zoom Using a combination of 6 times optical zoom and 10.4 times digital zoom permits zoom photography up to 62.4 times to suit the subject and the distance. While digital zoom can be a useful feature, the more an image is enlarged (zoomed), the more pixelated (grainier) the image will appear.
Setting the Flash Set the flash for capturing images. The flash firing mode can be set to suit for the photographic conditions. 1. Slide the mode switch to [ 2. Toggle the button to select the desired flash mode. The table below will help you choose the appropriate flash mode: Flash mode Description The flash fires automatically to suit the photographic conditions.
The available flash settings in different photography modes: [Blank] Auto Flash Auto Program Shutter Speed Priority Aperture Priority Mode Dial Manual User Setting Video Panorama Anti-Shake Sport Portrait Night Portrait Night Candlelight Fireworks Landscape Scene Mode Natural Green Sunrise Sunset Text Black &...
Ajustar el enfoque Las imágenes pueden capturarse con la distancia al sujeto ajustada a Enfoque automático, [ ] Enfoque automático macro, [ ] Enfoque automático súper macro, [ ] Infinito o [ MF ] Enfoque manual. 1. Deslice el interruptor de modos a [ ] y ajuste el dial de modos a uno de los modos de fotografía.
Setting the Self-timer This setting allows images to be captured with the self-timer. and set the mode dial to one of the 1. Slide the mode switch to [ photography modes. 2. Toggle the button to select the setting. Each press of the button moves the icon one step through the sequence and displays it on the screen.
Exposure Compensation/Backlight Correction Images can be captured with the overall scene intentionally made brighter or darker. These settings are used when a suitable brightness (exposure) cannot otherwise be obtained in circumstances where the difference in brightness between the subject and the background (the contrast) is large, or when the subject that you wish to capture is very small within the scene.
Printed matter comprising white text on blackish paper Weak reflecting bodies such as evergreen trees or darkish leaves Backlight correction (+1.3 EV, fixed) When the background is bright and the subject is dark. When subjects (people) have a light source such as the sun to their backs. For [ ] mode, only backlight correction can be set.
The table below will help you choose the appropriate scene mode: Scene mode Description ] Sport Select this mode when you want to capture fast-moving subjects. Select this mode when you want to capture an image that makes the person ] Portrait stand out against a defocused (blurred) background.
[P] Program (Automatic Exposure) Photography Mode The camera automatically sets the shutter speed and the aperture to suit the brightness of the subject. This allows you to capture image with ease just like when the [ ] mode is selected. 1.
[Tv] Shutter Speed Priority Photography Mode In this mode, images are captured with the priority given to shutter speed. The aperture is automatically set according to the shutter speed. If you set a fast shutter speed, you can capture images of moving subjects that look as if they are still.
[Av] Aperture Priority Mode In this mode, images are captured with the priority given to aperture. The shutter speed is automatically set according to the aperture. The aperture will affect the depth-of-field of the camera. If you set a small aperture (higher F value), both close objects and distant objects will be in focus, for example when capturing landscape images.
[M] Manual Mode In manual mode, the aperture value and the shutter speed can be varied individually. 1. Slide the mode switch to [ ] and set the mode dial to [M]. 2. Toggle the button to select the shutter speed or aperture. 3.
] User Setting Mode This mode allows you manually set the setting parameters and all these settings will be memorized. 1. Slide the mode switch to [ ] and set the mode dial to [ 2. Compose the image, press the shutter button down halfway, then press it down fully.
] Panorama Mode This mode is designed to make it easier to take a series of shots then stitch them together with software to make a single photo. You can capture a photographic subject that won’t fit into a single frame, such as a landscape, and stitch it together later with a program such as Cool 360 or Photoshop application.
Recording a Subject onto an Existing Background Image (Pre- Shot) Pre-Shot helps you get the background you want, even if you need to ask someone else to record the image for you. Basically, Pre-Shot is a two-step process. 1. You compose the background you want and press the shutter button, which causes a semi-transparent image of the background to remain on the monitor screen.
1. Slide the mode switch to [ ] and set the mode dial to one of the photography modes, except for [ ], ] and [ a. Press the MENU button. b. Select [Function] with the button. c. Select [Capture Mode] with the button, and press the SET button.
Combining Shots of Two People into a Single Image (Coupling Shot) The Coupling Shot mode lets you record images of two people and combine them into a single image. This makes it possible for you to include yourself in group images, even when there is no one else around to record the image for you.
] PLAYBACK MODE Playing Back Still Images You can play back the still images on the LCD monitor. 1. Slide the mode switch to [ The last image appears on the screen. 2. The images can be displayed in reverse or forward with the buttons.
Playing Back Video Clips You can play back recorded video clips on the LCD monitor. You can also play back voice. 1. Slide the mode switch to [ The last image appears on the screen. 2. Select the desired video clip with the buttons.
Playing Back Still Images/Video Clips on a TV You can also play back your images on a TV screen. Before connecting to any video devices, make sure to select NTSC/PAL to match the broadcast standard of the video equipment you are going to connect to the camera.
Attaching Voice Memo A maximum of 30 seconds of audio can be recorded like a memo annotation for each still image. The voice memo can be recorded only once. 1. Slide the mode switch to [ The last image appears on the screen. 2.
Thumbnail Display This function allows you to view 9 thumbnail images on the LCD monitor at the same time which can help to quickly search for the image that you want. 1. Slide the mode switch to [ The last image appears on the screen. 2.
Zoom Playback This mode also allows you to enlarge your image on the selected portion of the image to check for small details. 1. Slide the mode switch to [ 2. Press the buttons to select the image you want to enlarge. You can also select the image you want to enlarge from the thumbnail display.
Slideshow Display The slideshow function enables you to play back your still images automatically in sequential order as a slideshow. This is very useful and entertaining feature for reviewing captured images and for presentations. 1. Slide the mode switch to [ Play 2.
Protecting Images Set the data to read-only to prevent images from being erased by mistake. Protecting Images 1. Slide the mode switch to [ 2. Select the image that you want to protect with the buttons. 3. Press the MENU button. The playback menu is displayed.
Canceling the Protection To cancel protection, display the image that you want to remove the image protection. 1. Select [Protect] with the buttons from the playback menu, and press the SET button. 2. Select [Single] or [All] with the buttons, and press the SET button. 3.
DPOF Settings DPOF is the abbreviation for Digital Print Order Format, which allows you to embed printing information on your memory card. You can select the images to be printed and how many prints to make with the DPOF menu in the camera and insert the memory card to the card compatible printer. When the printer starts printing, it will read the embedded information on the memory card and print the specified images.
9. Select date to [On] or [Off] with the buttons, and press the SET button. On: The date of the photograph will also be printed. Off: The date of the photograph will not be printed. 10.Select [Print Enable] with the buttons, and press the SET button.
Copying Files from Internal Memory to a Memory Card This function allows you to copy your files from the digital still camera’s internal memory to a memory card. Of course, you can only do this if you have a memory card installed and some files in internal memory. 1.
Changing the Camera Start Logo Image You can specify the start logo image for your camera. You can select the new start logo image among the captured still images. 1. Slide the mode switch to [ 2. Select the image that you want to protect with the buttons.
] Deleting Images Immediate Erasure (Quick Delete Function) The quick delete function enables you to delete the last-captured image during capture. 1. Slide the mode switch to [ ] and set the mode dial to one of the photography modes. 2.
Deleting in Playback Mode Deleting a single image/Deleting all images 1. Slide the mode switch to [ The last image will be displayed on the screen. 2. Select the image you want to erase with the buttons. 3. Press the button.
Deleting selected images This deletes a number of selected images. 1. Slide the mode switch to [ 2. Press the button. The deletion menu will be displayed. 3. Select [Select] with the buttons, and press the SET button. The images are displayed in the thumbnail display. 4.
MENU OPTIONS Photography Menu (Capture tab) This menu is for basic settings used when capturing images in the photography modes. These settings are retained even if the camera is turned off or the Auto OFF function is activated. Available menu options in each photography mode: Program / Tv / Av / M / User Setting Auto Capture...
Anti-Shake Capture Function AE/AWB Size Capture Mode White Balance Quality Manual WB Sharpness LCD Bright. Metering Contrast Digital Zoom Focus Area Color Preview Flash Offset Date Print Beep 1. Slide the mode switch to [ ] and set the mode dial to one of the photography modes.
Size (resolution) This sets the resolution of the still-image that will be captured. * [10 0 0 0 0 M] 3648 x 2736 * [6 6 6 6 6 M] 2816 x 2112 * [3M] 2048 x 1536 * [0 0 0 0 0 .3M] 640 x 480 Quality This sets the quality (compression rate) at which the image is captured.
Photography Menu (Function tab) 1. Slide the mode switch to [ ] and set the mode dial to one of the photography modes. 2. Press the MENU button, and select the [Function] menu with the button. The [Function] tab of the photography menu is displayed. 3.
LCD Bright. Select a brightness level for the LCD monitor. The LCD becomes brighter with the button and darker with the button. The adjustment range is from -5 to +5. Digital Zoom This sets whether or not to use digital zoom at the time of photography. * On / Off Preview This sets whether or not to display the captured image on the screen immediately after the image is captured.
Photography Menu (AE/AWB tab) 1. Slide the mode switch to [ ] and set the mode dial to one of the photography modes. 2. Press the MENU button, and select the [AE/AWB] menu with the button. The [AE/AWB] tab of the photography menu is displayed. 3.
This sets the sensitivity for capturing images. When the sensitivity is raised (and the ISO figure is increased), photography will become possible even in dark locations, but the more pixelated (grainier) the image will appear. * 64 / 100 / 200 / 400 / Auto In the [Auto] setting, the ISO value is automatically selected from ISO 64 to ISO 200.
Playback Menu In the [ ] mode, set which settings are to be used for playback. 1. Slide the mode switch to [ 2. Press the MENU button. The playback menu is displayed. 3. Select the desired option item with the buttons, and press the SET button to enter its respective menu.
Setup 1 Menu Set your camera’s operating environment. 1. Slide the mode switch to [ 2. Press the MENU button, and select the [Setup1] menu with the button. The [Setup1] menu is displayed. 3. Select the desired setting with the buttons, and press the SET button to enter its respective menu.
Setup 2 Menu 1. Slide the mode switch to [ 2. Press the MENU button, and select the [Setup2] menu with the button. The [Setup2] menu is displayed. 3. Select the desired [Setup2] option item with the buttons, and press the SET button to enter its respective menu. 4.
TRANSFERRING RECORDED IMAGES AND VIDEOS TO YOUR COMPUTER System Requirements (Windows) Pentium 166 MHz or higher Windows 2000/XP 128MB RAM 128MB hard disk space CD-ROM drive Available USB port System Requirements (Macintosh) PowerPC G3/G4 OS 9.0 or later 128MB RAM 128MB hard disk space CD-ROM drive Available USB port...
Connecting the Camera to Your Computer 1. Connect one end of the USB cable to the USB terminal of the camera. 2. Connect the other end of the USB cable to an available USB port on your computer. 3. Turn on your camera. The [USB] screen appears.
Downloading Images and Video Files When the camera is turned on and connected to your computer, it is considered to be a disk drive, just like a floppy disk or CD. You can download (transfer) images by copying them from the “Removable disk” (“untitled”...
CONNECTING TO A PICTBRIDGE COMPLIANT PRINTER If a printer that supports PictBridge is available, images can be printed by connecting the digital still camera directly to the PictBridge-compatible printer without using a computer. Connecting the camera to the printer 1. Connect one end of the USB cable to your camera. 2.
3. If you select [Single] in the previous step, the figure shown on the right hand side will appear. Select the image that you want to print with the / buttons. Select the [Print Num.] (up to 99) with the buttons.
EDITING SOFTWARE INSTALLATION Installing Photo Explorer ® Ulead Photo Explorer provides a simple and efficient way to transfer, browse, modify and distribute digital media. Acquire photos, video or sound clips from various digital device types and easily browse or add personal descriptions; make timely modifications; or distribute the media through the medium of your choice: E-mail, Print, Slideshow Presentations.
Installing Photo Express ® Ulead Photo Express is a complete photo project software for digital images. The step-by-step workflow, visual program interface, and in-program help assist users in creating exciting photo projects. Acquire digital photos effortlessly from digital cameras or scanners. Organize them conveniently with the Visual Browse mode.
Installing Cool 360 ® Ulead COOL 360™ quickly and easily allows photo editing consumers to transform a series of photos into 360 or wide-angle panoramic scenes for an immersive viewing experience. COOL 360’s intuitive interface and easy-to-use wizard deliver great-looking panoramas fast while advanced warping, blending and alignment tools ensure excellent results.
CAMERA SPECIFICATIONS Item Description Image sensor 1/1.7” CCD sensor (10.1 Mega pixels) <Still image> 3648 x 2736, 2816 x 2112, 2048 x 1536, 640 x 480 Image resolution <Video clip> 640 x 480 LCD monitor 2.8” full color TFT LCD (230K pixels) Recording media 32 MB internal memory (26 MB available for image storage) Supports SD memory card (up to 2 GB) (optional)
TROUBLESHOOTING Refer to the symptoms and solutions listed below before sending the camera for repairs. If the problem persists, contact your local reseller or service center. Power Supply Cause Symptom Solution The battery in not inserted. The power does not come Insert the battery correctly.
Shooting Cause Solution Symptom The battery is running low. Recharge the battery. The power is not on. Turn the power on. The camera is not in shooting mode. Slide the mode switch to shooting mode. The shutter button is not pressed all Press the shutter button all the way the way down.
Playback Symptom Cause Solution Cannot playback. It is not set to playback mode. Slide the mode switch to playback mode. The contents of memory card You played back a memory card that Insert a memory card that was cannot be played back. was not formatted by this device.
This Quick Start Guide is only for quick reference. For more details on advanced functions, you can refer to GETTING STARTED your user’s manual. Rear View SET / Direction button GETTING TO KNOW YOUR CAMERA Attaching the Camera Strap Attach the camera strap as shown in the illustration. Front View Helpline No.: 08704460806 Inserting the Battery...
Transferring Recorded Images to Your Computer Taking Pictures Viewing Images Erasing Images 1. Press the POWER button to turn on the camera. 1. Slide the mode switch to [ Downloading Your Images 1. Slide the mode switch to [ ] and set the mode dial to one of the The last image appears on the screen.
