Lightolier 40828 Specification

Decorative, bowshield, wall mounted inc

Advertisement

Decorative, Bowshield, Wall Mounted INC
13 ⅛"
(333mm)
Total
Fixture
Height
(Art Glass)
13 ⅝"
(346mm)
Total
Fixture
Height
(Screen &
Textured Glass)
ADA Compliant
Complete Fixture consists of Lightshield and Backplate Assembly. Order each separately.

Lightshield Ordering Information

Catalog No.
Pattern/Description/Color
40871
40865
40862

Backplate Assembly Ordering Information

Catalog No.
Lamps
40828
2x60W T-10 Incandescent
40829
2x60W T-10 Incandescent

Features

Die-cast zinc alloy. Satin brass or satin nickel
1. Diffuser Holder:
finish with clear lacquer.
Turned brass. Satin brass or satin nickel
2. Diffuser Support Peg:
finish with clear lacquer.
20 ga. (.036") Die-formed steel, gloss white finish.
3. Backplate:
Medium Base, Porcelain, Nickel Plate Screw Shell.
4. Socket:
T-10, Medium Base, by others.
5. Lamps:
6mm thick (Max.) Glass. See chart above for options.
6. Diffuser:
Nylon. 8-32. To secure Diffuser.
7. Screw:
Labels
cUL listed suitable for damp locations.
13
"
1 32
(331mm)
Rolled "rain" pattern texture, silk-screened white/clear
Three dimensional "squares" white/clear silk-screened pattern
"Ceramic white" silk-screened and sandblasted
Finish
Satin Brass
Satin Nickel
Job Information
Job Name:
Cat. No.:
Notes:
5
6
4
1
2
4"
(102mm)
Type:
40828
Page 1 of 2
3
7
7
"
3 16
(183mm)
To Outlet
Box Center

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 40828 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lightolier 40828

  • Page 1 40828 Decorative, Bowshield, Wall Mounted INC Page 1 of 2 13 ⅛" (333mm) Total Fixture Height (Art Glass) 13 ⅝" (346mm) Total Fixture Height " 3 16 (Screen & (183mm) Textured Glass) To Outlet Box Center 4" " 1 32 ADA Compliant (102mm) (331mm)
  • Page 2 Footcandles are on floor. 5’6” Multiplier Factors Data shown is based on an “All White” lightshield. For colors use 0.8 multiplier 7’ 7’ 14’ Philips Lightolier Job Information Type: e: lol.webmaster@philips.com t: (508) 679-8131 w: www.lightolier.com 40828 May 9, 2011 Specifications are subject to change without notice.
