Lightolier Alabaster 40624U Specification

Page 1 of 2
6 15/16"
High
4 1/4"
To Outlet
Box Center
Order Information
Spec ID Backplate
40624UC 40614U
40614
40624C
Must Order Backplate and Diffuser separately.
Features
1. Diffuser: Translucent alabaster. Removable by unscrewing two holder knobs.
2. Ballast: Rated Class "P". See chart for electrical specifications.
3. Backplate: Die-formed 20 ga. steel, matte white finish.
4. Holder Knobs: Available with product: set of either polished brass or satin
nickel both with clear lacquer
Lamping
Compact Fluorescent: 26W Quad Tube 4-Pin, G24q-3 base
General Electric
F26 DBXT4/SPX*/4P
* Manufacturers' color temperature designation.
Mounting
Fixture is provided with a mounting plate suitable for direct mounting to most
outlet boxes or directly to wall over an outlet box.
Electrical
Lampholders: Compact Fluorescent: 4-pin, G24q-3 base
Ballasts:
Total input Watts
Max.line Current (Amps)
Power Factor
Ballast Factor
THD
Min. Starting Temp.
Lightolier is a Philips group brand
Decorative ADA Alabaster
13 15/16" Wide
Top View
2
Front View
Diffuser Lamp
72305 (1) 26W Quad 4-Pin, Electronic
72305
(1) 40W T-10, Incandescent
Osram/Sylvania Phillips
CF26DD/E/* PL-C26W/*/4P
Electronic120/277V
29
.17 / .11
>.97
>.98
<10%
-18°C (0°F)
®
1
Volts
120-277V
120V
Finish
Satin Nickel and Polished Brass
Labels
UL listed suitable for damp locations, I.B.E.W.
Fixture conforms to Americans with Disabilities Act (ADA) Federal Regulations—
Protruding Objects.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • B0508
40624U
Diffused Light
Wall Mounted Fluorescent
3
4
4" Extension
Side View
Type:
