Lightolier Lytecaster 404X Specification

Page 1 of 2
Complete fixture consists of Reflector Trim & Frame-In Kit. Select each separately
Reflector Trim
404BAX Specular Black Cone and White Flange
404CLX Specular Clear Cone and White Flange
404GDX Specular Gold Cone and White Flange
404CCDX Clear Diffuse and White Flange
Features
1. Flange Housing: Cold rolled steel 22ga. White trim flange.
2. Cone: 18ga. hydroformed aluminum and 0° to 35° vertically.
3. Adjustable Lampholder Support: 27ga. steel; Rotates 358° horizontally
4. Mounting Clips (3): 24ga. spring steel, zinc plated. Provide easy snap-in /
snap-out action.
5. Lamp Guard: 2" (51mm) dia. borosilicate glass.
Frame-In Kit
Note: For complete Frame-In Kit specifications, see 400 frame and 600 Recessed
Linear frame specification sheets.
Accessories
Square Face Plate
400SQBK Black
400SQWH White
Lightolier is a Philips group brand
Lytecaster Recessed Downlighting
4 1/2"
1/8"
Frame-In Kit
Remodeler
Remodeler
Non-IC
Non-IC
IC
Non-IC
Non-IC
Non-IC
Non-IC
4 3/4" (121mm) Aperture Adjustable Anodized Cone MR16
4 1/8"
5 3/4"
400MRX
3401MREX
402MRX
402MREX
402MRIC9X
602MR
603MR
604MR
604SQMR
Labels
CSA, UL. (Suitable for damp locations.)
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • B0708
404X
1" MAX
Lamp
50W MR16
50W MR16
75W MR16
50W MR16
75W MR16
75W MR16
75W MR16
75W MR16
75W MR16
Type:
