Lightolier Lytecaster 406X Specification

Page 1 of 2
Complete fixture consists of Reflector Trim & Frame-In Kit. Select each separately
Reflector Trim
406WHX
White Eyeball and Black Step Baffle
406WWX Stainless Steel Plated
Features
1. Flange Housing: Cold rolled steel 22 ga. White trim flange.
2. Eyeball Housing: Die-formed, one piece steel; provides 358° horizontal
rotation and 0° to 45· vertical adjustment.
3. Step Baffle: Die cast aluminum with stepped conical surface for low
brightness, black or white finish.
4. Mounting Clips (3): 24ga. spring steel, zinc plated. Provide easy snap-in/
snap-out action.
5. Lamp Guard: 2" (51mm) dia. borosilicate glass.
Frame-In Kit
Note: For complete Frame-In Kit specifications, see 400 frame specifica-
tion sheets.
Accessories
Square Face Plate
400SQWH White
400SQBK Black
Lightolier is a Philips group brand
5 3/4"
1 1/4"
Lytecaster Recessed Downlighting
5 1/4"
Frame-In Kit
Remodeler 400MRX
Remodeler 3401MREX
Non-IC 402MRX
Non-IC 402MREX
IC 402MRIC9X
Non-IC 602MR
Non-IC 603MR
Non-IC 604MR
Non-IC 604MR
Labels
CSA, UL (Suitable for damp and wet locations.)
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • C0708
4 3/4" Aperture Adjustable Eyeball MR16
1" MAX
Lamp
75W MR16
50W MR16
75W MR16
75W MR16
50W MR16
75W MR16
75W MR16
75W MR16
75W MR1
Type:
406X
