C141-E252-01EN
MBA3300RC
MBA3147RC
MBA3073RC
HARD DISK DRIVES
PRODUCT MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Fujitsu MBA3147RC - Enterprise 147 GB Hard Drive

Summary of Contents for Fujitsu MBA3147RC - Enterprise 147 GB Hard Drive

  • Page 1 C141-E252-01EN MBA3300RC MBA3147RC MBA3073RC HARD DISK DRIVES PRODUCT MANUAL...
  • Page 2 In addition, FUJITSU assumes no liability with respect to the application or use of any product or system in accordance with the descriptions or instructions contained herein; including any liability for incidental or consequential damages arising therefrom.
  • Page 3 REVISION RECORD Edition Date published Revised contents June, 2007 Specification No.: C141-E252-**EN C141-E252...
  • Page 4 Related Standards Product specifications and functions described in this manual comply with the following ANSI (*1) standards. Document number Title T10/1236D Rev.20 SCSI Primary Commands-2 (SPC-2) [NCITS.351:2001] T10/996D Rev. 8c SCSI-3 Block Commands (SBC) [NCITS.306:1998] T10/1157D Rev. 24 SCSI Architecture Model-2 (SAM-2) T10/1561D Rev.

  • Page 5: Preface

    Preface This manual describes MBA3300RC, MBA3147RC, and MBA3073RC 3.5 - inch hard disk drives with an embedded Serial Attached SCSI (SAS). This manual details the specifications and functions of the above disk drive, and gives the requirements and procedures for installing it into a host computer system. This manual is written for users who have a basic understanding of hard disk drives and their use in computer systems.
  • Page 6 Preface CONVENTIONS USED IN THIS MANUAL MBA3300RC, MBA3147RC, and MBA3073RC are described as "HDD" in this manual. Decimal number is represented normally. Hexadecimal number is represented as X'17B9', 17B9h or 17B9H. Binary number is represented as "010". Conventions for Alert Messages This manual uses the following conventions to show the alert messages.

  • Page 7: Important Alert Items

    Important Alert Items Important Alert Messages The important alert messages in this manual are as follows: A hazardous situation could result in minor or moderate personal injury if the user does not perform the procedure correctly. Also, damage to the product or other property, may occur if the user does not perform the procedure correctly.
  • Page 8 Data loss Save data stored on the HDD to other media before requesting repair. Maintenance Fujitsu does not assume responsibility if data is corrupted during servicing or repair. High temperature To prevent injury, never touch the HDD while it is hot. The DE and LSI become hot during operation and remain hot immediately after turning off the power.

  • Page 9: Manual Organization

    MANUAL ORGANIZATION PRODUCT MANUAL 1. General Description 2. Specifications (This manual) 3. Data Format 4. Installation Requirements 5. Installation 6. Diagnostics and Maintenance 7. Error Analysis SAS INTERFACE 1. SAS Interface MANUAL 2. Command Processing 3. Data Buffer Management 4. Command Specifications 5.
  • Page 10 This page is intentionally left blank.

  • Page 11: Table Of Contents

    CONTENTS Preface ........................1 Important Alert Items .....................3 MANUAL ORGANIZATION ..................5 CHAPTER 1 General Description..............13 Standard Features..................13 Hardware Structure ...................17 System Configuration ................18 CHAPTER 2 Specifications ................19 Hardware Specifications ................19 2.1.1 Model name and order number ..............19 2.1.2 Function specifications ................20 2.1.3 Environmental specifications..............23 2.1.4 Error rate ....................24 2.1.5 Reliability....................24...

  • Page 12: C141-E252

    Contents Defect Management ................. 36 3.3.1 Defect list ....................36 3.3.2 Alternate block allocation ................ 36 CHAPTER 4 Installation Requirements............41 Mounting Requirements................41 4.1.1 Dimensions....................41 4.1.2 Mounting orientations ................43 4.1.3 Notes on mounting ................... 44 Power Supply Requirements ..............48 Connection Requirements ................
  • Page 13 Contents CHAPTER 6 Diagnostics and Maintenance ...........65 Diagnostics....................65 6.1.1 Self-diagnostics..................65 6.1.2 Test programs....................68 Maintenance....................69 6.2.1 Precautions....................69 6.2.2 Maintenance requirements................70 6.2.3 Maintenance levels ...................71 6.2.4 Tools and test equipment ................71 6.2.5 Tests ......................72 Operation Check ..................73 6.3.1 Initial seek operation check ..............73 6.3.2 Operation test ....................73 6.3.3 Diagnostic test...................73 Troubleshooting ..................74...
  • Page 14 Contents 7.2.4 Sense data (5-2x-xx), (B-47-xx), (B-4B-xx) and (B-4E-00): interface error................... 84 Glossary ..................... 85 Abbreviation ..................... 87 Index ..................... 89 C141-E252...
  • Page 15 Contents Illustrations Figures Figure 1.1 Example of SAS system configuration (Dual port internal cabled environment) ..............18 Figure 1.2 Example of SAS system configuration (Dual port internal backplane environment) ..............18 Figure 3.1 Cylinder configuration..............28 Figure 3.2 Spare area in cell ................30 Figure 3.3 Alternate cylinder ................
  • Page 16 Contents Tables Table 2.1 Model names and order numbers........... 19 Table 2.2 Function specifications ..............20 Table 2.3 Environmental/Power requirements ..........23 Table 3.1 Format capacity ................34 Table 4.1 Surface temperature check point and maximum temperature ..46 Table 4.2 Interface connector (SAS plug) signal allocation:CN1 ....

  • Page 17: Chapter 1 General Description

    CHAPTER 1 General Description Standard Features Hardware Structure System Configuration This chapter describes the feature and configuration of the MBA3xxxRC. The HDDs are high performance large capacity 3.5-inch hard disk drives with an embedded Serial Attached SCSI (SAS) controller. The interface used to connect the HDDs to the host system complies with ANSI T10/1601-D Serial Attached SCSI-1.1 (SAS-1.1), which covers items ranging from SAS physical layers to SCSI command protocols.
  • Page 18 General Description Dual SAS port support The HDDs have two pairs of driver and receiver set (PHY) for the SAS to support dual SAS port connection. On the HDDs, Primary and Secondary Ports on SAS plug connector (2 physical links plus power connections) are used for SAS port connection.
  • Page 19 1.1 Standard Features Command queuing feature The HDDs can queue maximum 128 commands, and optimizes the issuing order of queued commands by the reordering function. This feature realizes the high speed processing. (10) Reserve and release functions The HDDs can be accessed exclusively in the multi-host or multi-initiator environment by using the reserve and release functions.
  • Page 20 General Description (16) Large capacity A large capacity can be obtained from the HDDs by dividing all cylinders into several partitions and changing the recording density on each partition (constant density recording). The disk subsystem with large capacity can be constructed in the good space efficiency. (17) Start/Stop of spindle motor Using the SAS primitive or the SCSI command, the host system can start and stop the spindle motor.

  • Page 21: 1.2 Hardware Structure

    1.2 Hardware Structure Hardware Structure The HDDs have a disk enclosure (DE) and a printed circuit board assembly (PCBA). The DE includes heads on an actuator and disks on a spindle motor mounted on the DE. The PCBA includes a read/write circuit and a controller circuit. Disks The disks have an outer diameter of 70 mm (2.8 inch).

  • Page 22: System Configuration

    General Description System Configuration For the Serial Attached SCSI, the ANSI standard defines Point-to-Point technology. Figure 1.1 and Figure 1.2 give examples of the SAS system configuration. Figure 1.1 Example of SAS system configuration (Dual port internal cabled environment) Figure 1.2 Example of SAS system configuration (Dual port internal backplane environment) Port addressing Every device connected with the SAS protocol has a unique address (SAS address).

  • Page 23: Chapter 2 Specifications

    CHAPTER 2 Specifications Hardware Specifications This chapter describes specifications of the HDDs. Hardware Specifications 2.1.1 Model name and order number Each model has different recording capacities. Table 2.1 lists the model name and order number. The data format can be changed by reinitializing with the user's system. Table 2.1 Model names and order numbers Capacity...

  • Page 24: Function Specifications

    Specifications 2.1.2 Function specifications Table 2.2 shows the function specifications of the HDDs. Table 2.2 Function specifications Specification Item MBA3300RC MBA3147RC MBA3073RC Formatted capacity (*1) 300 GB (*2) 147 GB (*2) 73.5 GB (*2) Number of disks Number of heads Tracks per Surface 82604 cyl typ.
  • Page 25 2.1 Hardware Specifications (*1) The formatted capacity can be changed by changing the logical block length and using spare sector space. See Chapter 3 for the further information. The formatted capacity listed in the table is an estimate for 512 bytes per sector. (*2) One gigabyte (GB) = one billion bytes;...
  • Page 26 Specifications (*8) The eye mask is as follows: Normalized time [U1] Parameter Unit 1.5Gbps 3.0Gbps 2xZ2 mVp-p 1,600 1,600 2xZ1 mVp-p 0.275 0.275 (*9) 1 MB = 1,048,576 bytes. C141-E252...

  • Page 27: Environmental Specifications

    2.1 Hardware Specifications 2.1.3 Environmental specifications Table 2.3 lists environmental and power requirements. Table 2.3 Environmental/Power requirements (1/2) Specification Item MBA3300RC MBA3174RC MBA3073RC Operating 5 to 55 °C Non-operating –40 to 70 °C Temperature Transport –40 to 70 °C (*1) DE surface temperature at 5 to 60 °C operating...

  • Page 28: Error Rate

    Specifications Table 2.3 Environmental/Power requirements (2/2) Specification Item MBA3300RC MBA3174RC MBA3073RC Power requirement Ripple (+5V, +12V) 250mVp-p or less (*7) (*5) (*1) For detail condition, see Section 4.1. (*2) Vibration applied to the HDD is measured at near the mounting screw hole on the frame as much as possible.
  • Page 29 2.1 Hardware Specifications Note: The MTBF is defined as: Operating time (hours) at all field sites MTBF = The number of equipment failures from all field sites Failure of the equipment means failure that requires repair, adjustments, or replacement. Mishandling by the operator, failures due to bad environmental conditions, power trouble, host system trouble, cable failures, or other failures not caused by the equipment are not considered.
  • Page 30 Specifications Data security at power failure Integrity of the data on the disk is guaranteed against all forms of DC power failure except on blocks where a write operation is being performed. The above does not applied to formatting disks or assigning alternate blocks.

  • Page 31: Chapter 3 Data Format

    CHAPTER 3 Data Format Data Space Logical Data Block Addressing Defect Management This chapter explains data space definition, logical data block addressing, and defect management on the HDDs. Data Space The HDDs manage the entire data storage area divided into the following three data spaces. User space: Storage area for user data Internal test space: Reserved area for diagnostic purposes System space: Area for exclusive use of HDDs themselves...

  • Page 32: Figure 3.1 Cylinder Configuration

    Data Format Note: Spare sectors on the last track in each cell are not necessarily placed at the end of the track because of a track skew or a cylinder skew. (Details are explained in Subsection 3.1.3) Figure 3.1 Cylinder configuration Apart from the above logical configuration, the HDDs intend to increase the storage capacity by dividing all cylinders into several zones and changing a recording density of each zone.
  • Page 33 3.1 Data Space User space The user space is a storage area for user data. The data format on the user space (the length of data block and the number of data blocks) can be specified with the MODE SELECT or MODE SELECT EXTENDED command.

  • Page 34: Alternate Spare Area

    Data Format 3.1.2 Alternate spare area The alternate spare area consists of the last track of each cell in the user space and an alternate cylinder allocated to the last 10 cylinders of the last zone in the user space. The spare area in each cell is placed at the end of the last track as shown in Figure 3.2.

  • Page 35: Track Format

    3.1 Data Space 3.1.3 Track format Physical sector allocation Figure 3.4 shows the allocation of the physical sectors in a track. The length in bytes of each physical sector and the number of sectors per track vary depending on the logical data block length. The unused area (G4) exists at the end of the track in formats with most logical data block lengths.

  • Page 36: Sector Format

    Data Format Track skew Head Track skew Head skew Head Leading logical sector in head p+1 Figure 3.5 Track skew/head skew The number of physical sectors (track skew factor and head skew factor) corresponding to the skew time varies depending on the logical data block length because the track skew and the head skew are managed for individual sectors.
  • Page 37 3.1 Data Space Each sector on the track consists of the following fields: Gaps (G1, G2, G3) No pattern is written on the gap field. PLO Sync In this field, pattern X'00' is written. Sync Mark (SM1, SM2) In this field, special pattern is written. This special pattern indicates the beginning of the data field. Data field (DATA1-DATA4) User data is stored in the data field of the sector.

  • Page 38: Format Capacity

    Data Format 3.1.5 Format capacity The size of the usable area for storing user data on the HDDs (format capacity) varies according to the logical data block or the size of the spare sector area. Table 3.1 lists examples of the format capacity when the typical logical data block length and the default spare area are used.
  • Page 39 3.2 Logical Data Block Addressing Block address of user space The logical data block address number is consecutively assigned to all of the data blocks in the user space starting with 0 to the first data block. The HDDs treat sector 0, track 0, cylinder 0 as the first logical data block. The data block is allocated in ascending order of addresses in the following sequence (refer to Figure 3.5): 1) Logical data blocks are assigned in ascending order of sector number in the same track.

  • Page 40: Defect Management

    Data Format Defect Management 3.3.1 Defect list Information of the defect location on the disk is managed by the defect list. The following are defect lists which the HDDs manage. P list (Primary defect list): This list consists of defect location information available at the HDD shipment and is recorded in a system space.

  • Page 41: Figure 3.7 Alternate Block Allocation By Format Unit Command

    3.3 Defect Management Alternate block allocation during FORMAT UNIT command execution When the FORMAT UNIT command is specified, the allocation of the alternate block to those defective sectors included in the defect list (P, G, or D) is continued until all spare sectors in the same cell are used up.

  • Page 42: Command

    Data Format Certification is permitted when DCRT flag is cleared (DCRT flag=0) in FORMAT UNIT command. The HDDs check all initialized logical data blocks by reading them out after the above alternate block allocation is made to initialize (format) the disk. Alternate block allocation by REASSIGN BLOCKS command When the REASSIGN BLOCKS command is specified, the alternate block is allocated to the defective logical data block specified by the initiator by means of alternate sector treatment.
  • Page 43 3.3 Defect Management Automatic alternate block allocation Automatic alternate block allocation at read operation If the ARRE flag in the MODE SELECT parameter permits the automatic alternate block allocation, the HDDs automatically execute the alternate block allocation and data duplication on the defective data block detected during the READ or READ EXTENDED command.
  • Page 44 Data Format Type 2 (Reassignment of write fail sector) 1) Commands to be applied WRITE WRITE EXTENDED FORMAT UNIT WRITE at executing WRITE AND VERIFY 2) Application requirements / processing When WRITE/WRITE EXTENDED command detects any Servo error (e.g. Write offtrack error) and cannot be recovered within pre-determined retry number (specified in Mode Parameter).

  • Page 45: Chapter 4 Installation Requirements

    CHAPTER 4 Installation Requirements Mounting Requirements Power Supply Requirements Connection Requirements This chapter describes the environmental, mounting, power supply, and connection requirements. Mounting Requirements 4.1.1 Dimensions Figures 4.1 show the dimensions of the HDDs and the location of the mounting screw holes. C141-E252...

  • Page 46: Figure 4.1 Dimensions

    Installation Requirements [Unit: mm] (*) is a dimention between the screw holes for the bottom mouting. Figure 4.1 Dimensions C141-E252...

  • Page 47: Mounting Orientations

    4.1 Mounting Requirements 4.1.2 Mounting orientations As shown in Figure 4.2, the HDD can be installed flat on any of its six sides. Inclination from a vertical or horizontal plane should not exceed 5°. (a) Horizontal –1 (b) Horizontal –2 (c) Vertical –1 (d) Vertical –2 (e) Upright mounting –1...

  • Page 48: Notes On Mounting

    Installation Requirements 4.1.3 Notes on mounting Damage Never remove any labels from the HDD or deface them in any way. Mounting screw Use No.6-32UNC Mounting frame structure Special attention must be given to mount the HDDs as follows. Use the frame with an embossed structure, or the like. Mount the HDDs with making a gap of 2.5 mm or more between the HDDs and the frame of the system.

  • Page 49: Figure 4.4 Limitation Of Side-Mounting

    4.1 Mounting Requirements Limitation of side-mounting Mount the HDDs using the 4 screw holes at the both ends on the both sides as shown in Figure 4.4. Do not use the center hole by itself. In case of using the center hole, it must be used in combination with 2 holes on both ends. (Total 6 screws for 6 holes enclosed) Figure 4.4 Limitation of side-mounting...

  • Page 50: Figure 4.5 Surface Temperature Measurement Points

    Installation Requirements Environmental temperature Temperature condition at installed in a cabinet is indicated with ambient temperature measured 30 mm from the HDD. At designing the system cabinet, consider following points. Make a suitable air flow so that the DE surface temperature never exceed 60°C. Cool the PCBA side especially with air circulation inside the cabinet.
  • Page 51 4.1 Mounting Requirements External magnetic field The HDD should not be installed near the ferromagnetic body like a speaker to avoid the influence of the external magnetic field. Leak magnetic flux The HDDs use a high performance magnet to achieve a high speed seek. Therefore, a leak magnetic flux at surface of the HDDs are large.

  • Page 52: Power Supply Requirements

    Installation Requirements Power Supply Requirements Allowable input voltage and current The power supply input voltage measured at the power supply connector pin of the HDDs (receiving end) must satisfy the requirement given in Subsection 2.1.3. (For other requirements, see Items (4) and (5) below.) Current waveform (reference) Figure 4.6 shows the spin-up current waveform of+5V DC and +12V DC.

  • Page 53: Figure 4.7 Current Waveform (Max Seek)

    4.2 Power Supply Requirements Figure 4.7 shows the Max Seek current waveform of+5V DC and +12V DC. Time (2 sec/div) Time (2 sec/div) Time (2 sec/div) Time (2 sec/div) Time (2 sec/div) Time (2 sec/div) Figure 4.7 Current waveform (Max seek) Power on/off sequence The order of the power on/off sequence of +5V DC and +12V DC, supplied to the HDDs, does not matter.

  • Page 54: Connection Requirements

    Installation Requirements Noise filter To eliminate AC line noise, a noise filter should be installed at the AC input terminal on the HDD power supply unit. The specification of this noise filter is as follows: Attenuation: 40 dB or more at 10 MHz Circuit construction: T-configuration as shown in Figure 4.8 is recommended.

  • Page 55: Interface Connector

    4.3 Connection Requirements 4.3.2 Interface connector Figure 4.10 shows the SAS type interface connector (SAS plug) overview. Table 4.2 lists the signal allocation of the SAS plug on the HDDs. Top view Bottom view Top view Bottom view Figure 4.10 SAS plug connector overview C141-E252...

  • Page 56: Table 4.2 Interface Connector (Sas Plug) Signal Allocation:cn1

    Installation Requirements Table 4.2 Interface connector (SAS plug) signal allocation:CN1 Pin No. Signal Description GND for SAS Primary Port SAS Primary Port Receive (positive) signal SAS Primary Port Receive (negative) signal GND for SAS Primary Port SAS Primary Port Transmit (negative) signal SAS Primary Port Transmit (positive) signal GND for SAS Primary Port GND for SAS Secondary Port...

  • Page 57: Ready Led Output Signal

    4.3 Connection Requirements 4.3.3 Ready LED output signal Figure 4.11 shows a recommended circuit for external LED connection to Ready LED output signal. Figure 4.11 Recommended external circuit for Ready LED output Either +3.3 V or +5 V can be used for external power supply for LED (Vcc). Current limiting resister (R) value need to be adjusted depend on the Vcc voltage.
  • Page 58 This page is intentionally left blank.

  • Page 59: Chapter 5 Installation

    CHAPTER 5 Installation Notes on Handling HDDs Setting Mounting HDDs Checking Operation after Installation and Preparing the HDDs for Use Dismounting HDDs This chapter describes the notes on handling HDDs, setting, mounting HDDs, confirming HDD operations after installation and preparation for use, and dismounting HDDs. Notes on Handling HDDs The items listed in the specifications in Table 2.3 must be strictly observed.
  • Page 60 Installation Unpackaging a) Use a flat work area. Check that the "This Side Up" sign side is up. Handle the package on soft material such as a rubber mat, not on hard material such as a desk. b) Be careful not to give excess pressure to the internal unit when removing cushions. c) Be careful not to give excess pressure to the PCBA and interface connector when removing the HDD from the Fcell (Fig.

  • Page 61: Setting

    5.2 Setting Setting 5.2.1 Port Address Every device that uses the SAS interface has a unique SAS address, and commands use an SAS address to identify each device for I/O operations. Every HDD is assigned a unique SAS address before shipment from the factory, so setting of an address is not required before the HDDs are used. Mounting HDDs 5.3.1 Mounting procedures...

  • Page 62: Checking Operation After Installation And Preparing The Hdds For Use

    Installation Checking Operation after Installation and Preparing the HDDs for Use 5.4.1 Checking initial operation The procedure for verifying operation after power-on is explained below. Initial diagnosis at the time of power-on: a) When the HDDs are turned on, the LED blinks and the HDDs perform the initial self-diagnosis (controller hardware diagnosis).

  • Page 63: Formatting

    5.4 Checking Operation after Installation and Preparing the HDDs for Use c) Issue the REQUEST SENSE command to collect sense data. When sense data has been collected successfully, perform an analysis to check for recoverable errors, and retry operations for recovery from any such errors.
  • Page 64 Installation FORMAT UNIT command Initialize entire recording surface of the disk with the FORMAT UNIT command. The FORMAT UNIT command initializes entire surface of the disk using the P lists, verifies data blocks after initialization, and allocates an alternate block for a defect block detected with verification. With initialization, the pattern specified with the initialization data pattern field is written into all bytes of all logical data blocks.

  • Page 65: Setting Parameters

    5.4 Checking Operation after Installation and Preparing the HDDs for Use 5.4.3 Setting parameters The user can specify the optimal operation mode for the user system environments by setting the following parameters with the MODE SELECT or MODE SELECT EXTENDED command: Error recovery parameter Caching parameter Control mode parameter...
  • Page 66 Installation Error recovery parameters The following parameters are used to control operations such as HDD internal error recovery: a. Read/write error recovery parameters (page code = 1) Parameter Default value • AWRE: Automatic alternate block allocation at Write 1 (enabled) operation •...
  • Page 67 5.4 Checking Operation after Installation and Preparing the HDDs for Use Caching parameters (page code = 8) The following parameters are used to optimize HDD Read-Ahead caching operations under the system environments. Refer to Chapter 3 "Data Buffer Management" of the SAS INTERFACE MANUAL for further details.

  • Page 68: Dismounting Hdds

    Installation Port control parameters The following parameters are used to control the ready LED signal behavior. Parameter Default value • READY LED MEANING 0 (LED is on when HDD is ready) Dismounting HDDs Since the method and procedure for dismounting the HDD, etc. depends on the locker structure of the system, etc., the work procedure must be determined in consideration of the requirements specific to the system.

  • Page 69: Chapter 6 Diagnostics And Maintenance

    CHAPTER 6 Diagnostics and Maintenance Diagnostics Maintenance Operation Check Troubleshooting Packaging This chapter describes diagnostics and maintenance. Diagnostics 6.1.1 Self-diagnostics The HDDs have the following self-diagnostic function. This function checks the basic operations of the HDDs. Initial self-diagnostics Online self-diagnostics (SEND DIAGNOSTIC command) Table 6.1 lists the contents of the tests performed with the self-diagnostics.
  • Page 70 Diagnostics and Maintenance Brief test contents of self-diagnostics are as follows. a. Hardware function test This test checks the basic operation of the controller section, and contains following test. RAM (microcode is stored) Peripheral circuits of microprocessor (MPU) Data buffer b.
  • Page 71 6.1 Diagnostics Online self-diagnostics (SEND DIAGNOSTIC command) The initiator can make the HDDs execute self-diagnostics by issuing the SEND DIAGNOSTIC command. The initiator specifies the execution of self-diagnostics by setting 1 for the SelfTest bit on the CDB in the SEND DIAGNOSTIC command and specifies the test contents with the UnitOfl bit.

  • Page 72: Test Programs

    Diagnostics and Maintenance When an error is detected in the hardware function test, the HDDs post the CHECK CONDITION status for all I/O operation request except the REQUEST SENSE command. The error status is not cleared even if the error information (sense data) is read. Only when the power is turned off or re-turned on, the status can be cleared.

  • Page 73: Maintenance

    See Section 5.1 and 6.5 for notes on packaging and handling when returning the HDD. Data loss Save data stored on the HDD to other media before requesting repair. Fujitsu does not assume responsibility if data is corrupted during servicing or repair. 6.2.1...

  • Page 74: Maintenance Requirements

    The PCBA cannot be replaced in the field. The DE cannot be replaced in the field. Service system and repairs Fujitsu has the service system and repair facility for the HDD. Contact Fujitsu representative to submit information for replacing or repairing the HDD. Generally, the following information must be...

  • Page 75: Maintenance Levels

    Replacement is usually done by the user, retail dealer, distributor, or OEM engineer. Factory maintenance (parts replacement) This replacement can only be done by Fujitsu. Replacement includes maintenance training and OEM engineer support. OEM engineers usually support retail dealers and distributors.

  • Page 76: Tests

    Diagnostics and Maintenance 6.2.5 Tests This HDD can be tested in the following ways: Initial seek operation check (See Subsection 6.3.1) Operation test (See Subsection 6.3.2) Diagnostic test (See Subsection 6.3.3) Figure 6.1 shows the flow of these tests. Start Start self-test by turning the power on Check host system...

  • Page 77: Operation Check

    6.3 Operation Check Operation Check 6.3.1 Initial seek operation check If an error is detected during initialization by the initial seek operation check routine at power-on, the spindle motor of the HDD stops, and then the HDD becomes unusable. For an explanation of the operation check before the initial seek, refer to the Section 5.4. 6.3.2 Operation test While the host computer is processing data, the HDDs monitor HDD operation including data...

  • Page 78: Troubleshooting

    At this level of maintenance, we recommend replacing the HDD as a unit. If replacing the HDD rectifies the fault, return the removed HDD to Fujitsu, for test and repair. If the newly installed HDD does not rectify the fault another part of the system is faulty.

  • Page 79: Table 6.2 System-Level Field Troubleshooting

    6.4 Troubleshooting Table 6.2 System-level field troubleshooting Item Recommended work DC power level Check that the DC voltage is within the specified range (±5%). For +5V DC, measure the voltage between pin P8 (+5V) of the interface connector and the nearest PCBA mounting screw (GND) from the interface connector, and confirm the value is from 4.75 to 5.25 VDC.

  • Page 80: Troubleshooting At The Repair Site

    HDD to Fujitsu for repair. A media defect list must be included with the HDD returned to Fujitsu. If the possibly faulty part is the DE, return the whole HDD to Fujitsu for repair. Also if a clear error (erroneous servo track information or noisy HDD) is detected in the DE, return the whole HDD to Fujitsu.

  • Page 81: Troubleshooting With Parts Replacement In The Factory

    Finding possibly faulty parts in the field was explained in Subsection 6.4.2. This manual does not cover finding possibly faulty parts at the factory level. Packaging When the HDD is returned to Fujitsu, the following methods are recommended. 6.5.1 Unitary packaging Figure 6.2...

  • Page 82: Multi Box Packaging

    Diagnostics and Maintenance Put the above unitary packaging (packed in FCELL) into the conductivity bag by securing the cushion. Put the drive with conductivity bag into the cardboard box. Put the desiccant (10g) into the conductivity bag. Seal the conductivity bag with the packaging tape, then close the cardboard box. 6.5.2 Multi-box packaging (upper)

  • Page 83: Figure 6.4 Fraction Packaging

    6.5 Packaging Put unitary packaging (FCELL) in the cushion (lower). At this time, FCELL is put in the cushion (lower) so that the FCELL opening may become downward. The I/F connector may become upward. For less than 20 HDDs, insert the HDDs starting from the slot with the smallest number in Figure 6.4.
  • Page 84 This page is intentionally left blank.

  • Page 85: Chapter 7 Error Analysis

    (Auto Sense function). This HDD is equipped with sense data with a byte length of 48. Accordingly, Fujitsu recommends collecting all 48-byte sense data when the host unit collects sense data.

  • Page 86: Figure 7.1 Sense Data Format

    Error Analysis Bit 7 Byte 0 Valid X'70' or X'71' (error code) X‘00' Sense key [MSB] Information [LSB] X'28' (additional sense data length) [MSB] Basic information Command-specific information [LSB] Additional sense code Additional sense code qualifier X'00' SKSV Sense key-specific information Port CDB operation code Additional...

  • Page 87: 7.2 Sense Data Analysis

    7.2 Sense Data Analysis Sense Data Analysis 7.2.1 Error information indicated with sense data Table 7.1 lists the definition of sense data. For details of the following sense data, refer to Chapter 6 "Sense Data Error Recovery Methods" of the SAS INTERFACE MANUAL. Subsection 7.2.2 onwards explain troubleshooting using sense data.

  • Page 88: Sense Data (3-0C-03), (4-32-01), (4-40-Xx), (4-C4-Xx), And (4-44-Xx)

    Error Analysis 7.2.2 Sense data (3-0C-03), (4-32-01), (4-40-xx), (4-C4-xx), and (4-44-xx) Sense data (3-0C-03), (4-32-01), (4-40-xx), (4-C4-xx), and (4-44-xx) indicate one of the following: A target sector could not be detected using the sector counter. A seek process overran the specified time. A write to a disk terminated abnormally.

  • Page 89: Glossary

    Glossary Additional Sense Code This is a 1-byte code displayed in the sense data and is information which specifies the type of error that was detected. Command Descriptor Block A series of data which describes commands related to input/output operations, sent from the initiator to the target.
  • Page 90 This page is intentionally left blank.

  • Page 91: Abbreviation

    Acronyms and Abbreviations Alternating Current Hard Disk Controller ARRE Automatic Read Reallocation Hard Disk Drive Enabled AWRE Automatic Write Reallocation Enabled IDentifier Input/Output Bits Per Inch Light Emitting Diode Large-Scale Integration circuit Command Descriptor Block CmpLst Complete List Cyclic Redundancy Check MEEPRML Modified Enhanced CYLinder...
  • Page 92 Acronyms and Abbreviations Serial/Number Serial Attached SCSI SCSI Small Computer System Interface SeCTor SelfTest Self Test Save Page SPindle Motor Transfer Block Tracks Per Inch UnitOfl Unit Offline Voice Coil Motor Write Cache Enable C141-E252...

  • Page 93: Index

    Index defect management .......... 36 defective block slipping ........16 delivery ............56 acoustic noise........... 20 diagnosis ............16 actuator ............17 diagnostic ............65 additional error recovery parameter....62 diagnostic test ..........73 additional sense code ........81 dimension............41 additional sense code qualifier......
  • Page 94 Index physical sector allocation ......... 31 PLO Sync ............33 port address ............57 initial diagnosis at time of power-on....58 port addressing ..........18 initial seek operation check......73 power on/off sequence ........49 initial self-diagnostic........66 power supply requirement........ 48 installation..........
  • Page 95 Index unpackaging ............. 56 test program ............. 68 user space............29 tool and test equipment........71 track format............31 track skew ............31 verify error recovery parameter ....... 62 troubleshooting ..........74 verifying HDD operation ......... 58 troubleshooting at repair site......76 verifying interface connection ......
  • Page 96 This page is intentionally left blank.
  • Page 97 List any errors or suggestions for improvement. Page Line Contents Please send this form to the address below. We will use your comments in planning future editions. Address: Fujitsu Learning Media Limited 37-10 Nishikamata 7-chome Oota-ku Tokyo 144-0051 JAPAN Fax: 81-3-3730-3702...
  • Page 98 This page is intentionally left blank.
