Summary of Contents for Fujitsu MBA3073NC

  • Page 2 In addition, FUJITSU assumes no liability with respect to the application or use of any porduct or system in accordance with the descriptions or instructions contained herein; including any liability for incidental or consequential damages arising therefrom.
  • Page 3 REVISION RECORD Edition Date published Revised contents October, 2007 Specification No.: C141-E270-**EN C141-E270...
  • Page 4 Related Standards Product specifications and functions described in this manual comply with the following ANSI (*1) standards. Document number T10/1236D Rev.20 [NCITS.351:2001] T10/996D Rev.8c [NCITS.306:1998] T10/1157D Rev.24 T10/1365D Rev.10 *1 ANSI = American National Standard Institute In case of conflict between this manual and any referenced document, this manual takes precedence.
  • Page 5 This manual describes the MBA3300NC, MBA3300NP, MBA3147NC, MBA3147NP, MBA3073NC, and MBA3073NP 3.5-inch SCSI hard disk drives. This manual details the specifications and functions of the above disk drives, and gives the requirements and procedures for installing it into a host computer system.
  • Page 6 CONVENTIONS USED IN THIS MANUAL The MBA3300NC, MBA3300NP, MBA3147NC, MBA3147NP, MBA3073NC, and MBA3073NP disk drives are described as "the hard disk drive (HDD)," "the disk drive" or "the device" in this manual. Decimal number is represented normally. Hexadecimal number is represented as X'17B9', 17B9h or 17B9H.
  • Page 7: Important Alert Items

    Important Alert Messages The important alert messages in this manual are as follows: A hazardous situation could result in minor or moderate personal injury if the user does not perform the procedure correctly. This alert signal also indicates that damages to the product or other property may occur if the user does not perform the procedure correctly.
  • Page 8 Data loss Save data stored on the HDD to other media before requesting repair. Fujitsu does not assume responsibility if data is corrupted during servicing or repair. High temperature To prevent injury, never touch the HDD while it is hot.
  • Page 9 MANUAL ORGANIZATION PRODUCT 1. General Description MANUAL 2. Specifications 3. Data Format (This manual) 4. Installation Requirements 5. Installation 6. Diagnostics and Maintenance 7. Error Analysis SCSI PHYSICAL 1. SCSI Bus INTERFACE 2. SCSI Message SPECIFICATIONS 3. Error Recovery SCSI LOGICAL 1.
  • Page 10 This page is intentionally left blank.
  • Page 11: Table Of Contents

    CHAPTER 1 GENERAL DESCRIPTION... 13 Standard Features ... 14 Hardware Structure ... 18 System Configuration... 19 CHAPTER 2 SPECIFICATIONS ... 21 Hardware Specifications... 21 2.1.1 Model name and order number ... 21 2.1.2 Function specifications... 22 2.1.3 Environmental specifications ... 25 2.1.4 Error rate ...
  • Page 12 4.3.2 68-pin connector type 16-bit SCSI model (NP model) ... 60 4.3.3 Cable connector requirements ... 67 4.3.4 External operator panel (on NP model drives only) ... 68 CHAPTER 5 INSTALLATION... 71 Notes on Handling HDDs ... 71 Connections... 73 Setting Terminals ...
  • Page 13 6.4.1 Outline of troubleshooting procedures ... 105 6.4.2 Troubleshooting with HDD replacement in the field ... 105 6.4.3 Troubleshooting at the repair site ... 107 6.4.4 Troubleshooting with parts replacement in the factory ... 108 6.4.5 Finding possibly faulty parts ... 108 Packaging ...
  • Page 14 Figure 1.1 System configuration ...19 Figure 3.1 Cylinder configuration...32 Figure 3.2 Spare area in cell...34 Figure 3.3 Alternate cylinder ...34 Figure 3.4 Track format ...35 Figure 3.5 Track skew/head skew...36 Figure 3.6 Sector format ...36 Figure 3.7 Alternate block allocation by FORMAT UNIT command ...42 Figure 3.8 Alternate block allocation by REASSIGN BLOCKS command ...43 Figure 4.1...
  • Page 15 Figure 4.23 External operator panel circuit example ...68 Figure 5.1 SCSI bus connections ...74 Figure 5.2 Setting terminals location (on NP models only) ...75 Figure 5.3 CN2 setting terminal (on NP models only) ...76 Figure 5.4 Checking the SCSI connection (A) ...85 Figure 5.5 Checking the SCSI connection (B)...86 Figure 6.1...
  • Page 16 Table 2.1 Model names and order numbers...21 Table 2.2 Function specifications ...22 Table 2.2 Function specifications (continued)...23 Table 2.3 Environmental/power requirements...25 Table 2.3 Environmental/power requirements (continued) ...26 Table 2.4 SCSI function specifications ...29 Table 3.1 Format capacity ...38 Table 4.1 Surface temperature check point ...52 Table 4.2 Recommended components for connection...67...
  • Page 17: Chapter 1 General Description

    CHAPTER 1 GENERAL DESCRIPTION Standard Features Hardware Structure System Configuration This chapter describes the feature and configuration of the MBA3xxxxx. The HDDs are high performance large capacity 3.5-inch hard disk drives with an embedded SCSI controller. The HDDs support the Small Computer System Interface (SCSI) as described in the ANSI SCSI SPI-4 [T10/1365D Rev.10] to the extent described in this manual.
  • Page 18: Standard Features

    Standard Features Compactness Since the SCSI controller circuit is embedded in the standard 3.5-inch hard disk drive form factor, the HDD is extremely compact. The HDD can be connected directly to the SCSI bus of the host system. Environmental Protection The HDDs comply with the Restriction of the use of certain Hazardous Substances in electrical and electronic equipment (RoHS) directive issued by European Union (EU).
  • Page 19 High speed data transfer Such a high data transfer rate on the SCSI bus can be useful with the large capacity buffer in the HDD. • 8-bit SCSI: The data transfer rate on the SCSI bus is 40 MB/s maximum at the synchronous mode.
  • Page 20 When Write cache is enabled, you should ensure that the cached data is surely flushed to the disk media before you turn off the HDD's power. To ensure it, you should issue either the SYNCHRONIZE CACHE command or the STOP UNIT command with specifying “0” to the Immediate bit and then confirm that the command is surely terminated with the GOOD STATUS.
  • Page 21 (14) Defective block slipping A logical data block can be reallocated in a physical sequence by slipping the defective data block at formatting. This results in high speed contiguous data block processing without a revolution delay due to defective data block. (15) High speed positioning A rotary voice coil motor achieves fast positioning with high performance access control.
  • Page 22: Hardware Structure

    Hardware Structure The HDDs have a disk enclosure (DE) and a printed circuit board assembly (PCBA). The DE includes the heads on an actuator and the disks on a spindle motor mounted on the DE. The PCBA includes a read/write circuit and a controller circuit. Disks The disks have an outer diameter of 70 mm (2.8 inch).
  • Page 23: System Configuration

    System Configuration Figure 1.1 shows the system configuration. The HDDs are connected to the SCSI bus of host systems and are always operated as target. The HDDs perform input/output operation as specified by SCSI devices which operate as initiator. C141-E270 SCSI bus (#14) (#15)
  • Page 24 SCSI bus configuration Up to eight SCSI devices operating as an initiator or a target can be connected to the SCSI bus for the 8-bit SCSI and up to 16 SCSI devices operating as an initiator or a target can be connected to the SCSI bus for the 16-bit SCSI in any combination.
  • Page 25: Chapter 2 Specifications

    CA06708-B400 MBA3300NP CA06708-B850 MBA3147NC CA06708-B200 MBA3147NP CA06708-B650 MBA3073NC CA06708-B100 MBA3073NP CA06708-B550 (*) One gigabyte (GB) = one billion bytes; accessible capacity will be less and actual capacity depends on the operating environment and formatting. C141-E270 Model names and order numbers...
  • Page 26: Function Specifications

    Cable length: 1.5 m max. (*7) Cable length: 25 m max. (*8) Cable length: 12 m max. (*9) 188 MB/s (standard format, most outer) 320 MB/s max. 512 to 528 byte (fixed length) (*11) MBA3073NC MBA3073NP 73.5 GB (*2) (rpm) C141-E270...
  • Page 27: Table 2.2 Function Specifications

    C141-E270 Function specifications (continued) Specification MBA3300NC MBA3147NC MBA3300NP MBA3147NP SPI-4 (T10/1365D Rev. 10), SAM-2 (T10/1157D Rev. 24), SPC-2 (T10/1236D Rev. 20), SBC (T10/996D Rev. 8c) 8 MB FIFO ring buffer (*12) 3.6 Bels typ. Seek difference [4096 Cyl/div] MBA3073NC MBA3073NP...
  • Page 28 The maximum data transfer rate may be restricted to the response speed of initiator and by (*10) transmission characteristics. 1MB/s=1,000,000 bytes/s. Refer to 1.1(13). (*11) 1MB=1,048,576 bytes (*12) C141-E270...
  • Page 29: Environmental Specifications

    –305 to +12,192 m (-1,000 to +40,000 feet) 0.88 A 2.5 A (peak) 3.5 A (less than 100 μs) 2.8 A 1.15 A MBA3073NC MBA3073NP 5 to 55°C 5 to 60°C (1 G) (20 to 300 Hz) or less (5 G) (20 to 300 Hz) or less...
  • Page 30: Error Rate

    Positioning errors which can be recovered by one retry should be 10 or less per 10 Environmental/power requirements (continued) MBA3300NC MBA3300NP 250 mVp-p or less (*7) Specification MBA3147NC MBA3073NC MBA3147NP MBA3073NP ± 5 % 0.5 A 1.5 A 0.79 A seeks.
  • Page 31: Reliability

    2.1.5 Reliability Mean Time Between Failures (MTBF) MTBF of the HDDs during its lifetime is 1,400,000 hours (operating: 24 hours/day, 7 days/week average DE surface temperature: 50°C or less). Continual or sustained operation at case DE surface temperature above 50°C may degrade product reliability.
  • Page 32 Note: The "average DE surface temperature" means the average temperature at the DE surface throughout the year when the HDD is operating. Data security at power failure Integrity of the data on the disk is guaranteed against all forms of DC power failure except on blocks where a write operation is being performed.
  • Page 33: Scsi Function Specifications

    SCSI Function Specifications Table 2.4 shows the SCSI functions provided with the HDD. Table 2.4 Item Single-ended type HVD type (High Voltage Differential) LVD type (Low Voltage Differential) Electrical requirements Single-ended type (*1) Differential type TERMPWR signal send function 68-pin P cable connector Connector 80-pin SCA2 connector Data bus parity (Data bus CRC)
  • Page 34 This page is intentionally left blank.
  • Page 35: Chapter 3 Data Format

    CHAPTER 3 DATA FORMAT Data Space Logical Data Block Addressing Defect Management This chapter explains data space definition, logical data block addressing, and defect management on the HDD. Data Space The HDD manages the entire data storage area divided into the following three data spaces. •...
  • Page 36: Figure 3.1 Cylinder Configuration

    Note: Spare sectors on the last track in each cell are not necessarily placed at the end of the track because of a track skew or a cylinder skew. (Details are explained in Subsection 3.1.3.) Figure 3.1 Apart from the above logical configuration, the HDD intends to increase the storage capacity by dividing all cylinders into several zones and changing a recording density of each zone.
  • Page 37: Alternate Spare Area

    User space The user space is a storage area for user data. The data format on the user space (the length of data block and the number of data blocks) can be specified with the MODE SELECT or MODE SELECT EXTENDED command. The user can also specify the number of logical data blocks to be placed in the user space with the MODE SELECT or MODE SELECT EXTENDED command.
  • Page 38: Figure 3.2 Spare Area In Cell

    The number of spare sectors per cell is fixed at 300. This number cannot be changed by users. Track 0 Sector 0 Track 1 Cell Last track Note: This HDD manages alternate spare areas for each cell, which is a set of cylinders. One cell consists of 32 to 40 cylinders.
  • Page 39: Track Format

    3.1.3 Track format Physical sector allocation Figure 3.4 shows the allocation of the physical sectors in a track. The length in bytes of each physical sector and the number of sectors per track vary depending on the logical data block length.
  • Page 40: Sector Format

    Track skew Head Head Figure 3.5 The number of physical sectors (track skew factor and head skew factor) corresponding to the skew time varies depending on the logical data block length because the track skew and the head skew are managed for individual sectors. The HDD automatically determines appropriate values for the track skew factor and the head skew factor according to the specified logical data block length.
  • Page 41 Gaps (G1, G2, G3) No pattern is written on the gap field. PLO Sync In this field, pattern X'00' in the specified length in bytes is written. Sync Mark (SM1, SM2) In this field, special pattern in the specified length in bytes is written. This special pattern indicates the beginning of the data field.
  • Page 42: Format Capacity

    Data block length MBA3300NC, MBA3300NP MBA3147NC, MBA3147NP MBA3073NC, MBA3073NP (*) One gigabyte (GB) = one billion bytes; accessible capacity will be less and actual capacity depends on the operating environment and formatting. Note: Total number of spare sectors is calculated by adding the number of spare sectors in each primary cylinder and the number of sectors in the alternate cylinders.
  • Page 43 Block address of user space The logical data block address number is consecutively assigned to all of the data blocks in the user space starting with 0 to the first data block. The HDD treats sector 0, head 0, and cylinder 0 as the first logical data block. The data block is allocated in ascending order of addresses in the following sequence (refer to Figure 3.5): 1) Logical data blocks are assigned in ascending order of sector number in the same track.
  • Page 44: Defect Management

    Defect Management 3.3.1 Defect list Information of the defect location on the disk is managed by the defect list. The following are defect lists which the HDD manages. • P list (Primary defect list): This list consists of defect location information available at the disk drive shipment and is recorded in a system space.
  • Page 45 The alternate block allocation is executed by the FORMAT UNIT command, the REASSIGN BLOCKS command, or the automatic alternate block allocation. Refer to Subsection 5.3.2 “Auto alternate block allocation processing” of the SCSI Logical Interface Specifications for details of specifications on these commands. The logical data block is allocated to the next physically continued sectors after the above sector slip treatment is made.
  • Page 46: Figure 3.7 Alternate Block Allocation By Format Unit Command

    : n represents a logical data block number : Defective sector : Unused spare sector Figure 3.7 Alternate block allocation by FORMAT UNIT command During FORMAT UNIT command, alternate block allocation is conducted in following cases: 1) Unrecovered write offtrack condition during a media write 2) Uncorrectable Data Error during a media read (certification) *1 If above errors are detected during FORMAT UNIT command, the HDD allocates the alternate block(s) to the defective data blocks.
  • Page 47: Figure 3.8 Alternate Block Allocation By Reassign Blocks Command

    Alternate block allocation by REASSIGN BLOCKS command When the REASSIGN BLOCKS command is specified, the alternate block is allocated to the defective logical data block specified by the initiator by means of alternate sector treatment. The alternate block is allocated to unused spare sectors in the alternate cylinder. Figure 3.8 is examples of the alternate block allocation by the REASSIGN BLOCKS command.
  • Page 48 • Automatic alternate block allocation at write operation If AWRE flag in the MODE SELECT parameter permits the automatic alternate block allocation, the HDD executes two kinds of automatic alternate processing during WRITE command processing as described below: Type 1 (Reassignment of uncorrectable read error sector) 1) Commands to be applied WRITE WRITE EXTEND...
  • Page 49 2) Application requirements / processing When WRITE/WRITE EXTENDED command detects any Servo error (e.g. Write offtrack error) and cannot be recovered within pre-determined retry number (specified in Mode Parameter). For the sectors around defective Servo, alternate blocks are allocated and the data of this WRITE commands are re-written.
  • Page 50 This page is intentionally left blank.
  • Page 51: Chapter 4 Installation Requirements

    CHAPTER 4 INSTALLATION REQUIREMENTS Mounting Requirements Power Supply Requirements Connection Requirements This chapter describes the environmental, mounting, power supply, and connection requirements. Mounting Requirements 4.1.1 External dimensions Figures 4.1 and 4.2 show the external dimensions of the HDD and the locations of the holes for the HDD mounting screws.
  • Page 52: Figure 4.1 Nc Model Dimensions

    The value marked with (*) indicates the dimension between mounting holes on the bottom face. [Unit: mm] Figure 4.1 NC model dimensions C141-E270...
  • Page 53: Figure 4.2 Np Model Dimensions

    The value marked with (*) indicates the dimension between mounting holes on the bottom face. [Unit: mm] Figure 4.2 NP model dimensions C141-E270...
  • Page 54: Mounting Orientations

    4.1.2 Mounting orientations As shown in Figure 4.3, the HDD can be installed flat on any of its six sides. Inclination from a vertical or horizontal plane should not exceed 5°. (a) Horizontal –1 (d) Vertical –2 4.1.3 Notes on mounting Damage Never remove any labels from the HDD or deface them in any way.
  • Page 55: Figure 4.4 Mounting Frame Structure

    Mounting screw Use No.6-32UNC. Mounting frame structure Special attention must be given to mount the HDD as follows. Use the frame with an embossed structure, or the like. Mount the HDD with making a gap of 2.5 mm or more between the HDD and the frame of the system. As shown in Figure 4.4, the inward projection of the screw from the HDD frame wall at the corner must be 4.5 mm ±...
  • Page 56: Figure 4.5 Limitation Of Side-Mounting

    Holes for mounting screw Use four holes (No.1 to No.4) to mount. Figure 4.5 Limitation of bottom-mounting Use all four mounting holes on the bottom face. Environmental temperature Temperature condition at installed in a cabinet is indicated with ambient temperature measured 30 mm from the disk drive.
  • Page 57: Power Supply Requirements

    Figure 4.6 Surface temperature measurement points External magnetic field Do not install the HDDs in the vicinity of equipment giving off strong magnetic fields, such as monitors, televisions, or loudspeakers. Leak magnetic flux Do not mount the HDDs near the devices that the leakage magnetic flux influence easily. Power Supply Requirements Allowable input voltage and current The power supply input voltage measured at the power supply connector pin of the HDD...
  • Page 58: Figure 4.7 Current Waveform (Spin-Up)

    +5VDC MBA3300NC MBA3300NP Time (2 sec/div) +12VDC MBA3300NC MBA3300NP Time (2 sec/div) Figure 4.7 MBA3147NC MBA3147NP Time (2 sec/div) MBA3147NC MBA3147NP Time (2 sec/div) Current waveform (Spin-up) MBA3073NC MBA3073NP Time (2 sec/div) MBA3073NC MBA3073NP Time (2 sec/div) C141-E270...
  • Page 59: Figure 4.8 Current Waveform (Max Seek)

    HDD and at least one of the SCSI devices supplying power to that signal. Figure 4.9 C141-E270 MBA3147NC MBA3147NP Time (10 msec/div) MBA3147NC MBA3147NP Time (10 msec/div) Current waveform (Max seek) Power on/off sequence (1) MBA3073NC MBA3073NP Time (10 msec/div) MBA3073NC MBA3073NP Time (10 msec/div)
  • Page 60: Figure 4.10 Power On/Off Sequence (2)

    c) In a system which does not use the terminating resistor power supply signal (TERMPWR) on the SCSI bus, the requirements for +5 VDC given in Figure 4.10 must be satisfied between the HDD and the SCSI device with the terminating resistor circuit. SCSI devices with the terminating resistor...
  • Page 61 Sequential starting of spindle motors After power is turned on to the HDD, a large amount of current flows in the +12 VDC line when the spindle motor rotation starts. Therefore, if more than one HDD is used, the spindle motors should be started by the following procedures to prevent overload of the power supply unit.
  • Page 62: Connection Requirements

    Figure 4.12 AC noise filter (recommended) Connection Requirements 4.3.1 SCA2 connector type 16-bit SCSI model (NC model) Connectors Figure 4.13 shows the locations of connectors on the SCA2 connector type 16-bit SCSI model (NC model). SCSI connector (CN1) (including power supply) Figure 4.13 NC connectors location C141-E270...
  • Page 63: Figure 4.14 Sca2 Type 16-Bit Scsi Connector

    SCSI connector and power supply connector The connector for the SCSI bus is an unshielded SCA-2 connector conforming to SCSI-3 type which has two 40-pin rows spaced 1.27 mm (0.05 inch) apart. The power connector is included in the SCSI connector. Figure 4.14 shows the SCSI connector.
  • Page 64: 68-Pin Connector Type 16-Bit Scsi Model (Np Model)

    4.3.2 68-pin connector type 16-bit SCSI model (NP model) Connectors Figures 4.15 show the locations of connectors and terminals on the 68-pin connector type 16-bit SCSI model (NP model). • Power supply connector • SCSI connector • External operator panel connector Power supply connector (CN1) External operator panel connector (CN1)
  • Page 65: Figure 4.16 68-Pin Type 16-Bit Scsi Interface Connector

    Pin 34 2.54mm 1.27mm Pin 68 0.40mm 0.635mm Figure 4.16 68-pin type 16-bit SCSI interface connector Power supply connector Figure 4.17 shows the shape and the terminal arrangement of the output connector of DC power supply. Figure 4.17 Power supply connector (68-pin type 16-bit SCSI) SG terminal The HDD is not provided with an SG terminal (fasten tab) for DC grounding.
  • Page 66: Figure 4.18 External Operator Panel Connector (Cn1)

    Figure 4.18 External operator panel connector (CN1) 2.0mm Pin 2 Pin 1 Figure 4.19 External operator panel connector (CN2) Pin 24 2.0mm Pin 23 Signal –ID0 Fault LED –ID1 ESID –ID2 (Reserved) –ID3 –LED +5 V –WTP C141-E270...
  • Page 67: Figure 4.20 16-Bit Scsi Id External Input

    External operator panel connector Signals a. 16-bit SCSI –ID3, –ID2, –ID1, –ID0: Input signals (CN1-A1, A3, A5, A7 pin and CN2-02, 04, 06, 08 pin) These signals are used for providing switches to set the SCSI ID of the HDD externally. Figure 4.20 shows the electrical requirements.
  • Page 68 b. Fault LED: Output signal (CN1-A2 pin) The HDD indicates that the write-protect status is in effect (CN1-A12 is connected to the GND, or the CN2-9 and CN2-10 are short-circuited.) A signal for driving the LED is output. 74LS06 or equivalent This signal is temporarily driven at the GND level when the micro program reads the SCSI ID immediately after the power supply to the HDD has been switched on (it is possible to set up the SCSI ID...
  • Page 69: Figure 4.21 Output Signal For External Led

    Figure 4.21 Output signal for external LED e. –WTP: Input signal (CN1-A12 and CN2-9, 10 pin) By connecting the CN1-A12 and CN2-10 pins to the GND, writing operations into the HDD disk media are set to disable. C141-E270...
  • Page 70: Figure 4.22 Scsi Cables Connection

    Cable connection requirements The requirements for cable connection between the HDD, host system, and power supply unit are given in Figure 4.22. Recommended components for connection are listed in Table 4.2. Figure 4.22 SCSI cables connection External operator panel (example) C141-E270...
  • Page 71: Cable Connector Requirements

    Name (Size) 787311-4 71743-1085 DHJ-PAC68-2AN- 5786090-7 UL20528-FRX- 68-P0.635 170148-1 (AWG18 to 24) A3B-2630SCC (AWG26 to 36) FCN-723J-G/AM (AWG28) Reference Manufacturer (*1) Tyco Electronics Molex Fujikura Tyco Electronics Fujikura Tyco Electronics Tyco Electronics HIROSE ELECTRIC HIROSE ELECTRIC FUJITSU TAKAMIZAWA FUJITSU TAKAMIZAWA...
  • Page 72: External Operator Panel (On Np Model Drives Only)

    External operator panel (NP model only) The external operator panel is installed only when required for the system. When connection is not required, leave open the following pins in the external operator panel connector of the HDD: Pins 21, 22 and pins 01 through 08 in CN2 and pins A1 through A12 in CN1. 4.3.4 External operator panel (on NP model drives only) A recommended circuit of the external operator panel is shown in Figure 4.23.
  • Page 73 IMPORTANT Do not connect the external LED to both CN1 and CN2. Connect it to either of them. C141-E270...
  • Page 74 This page is intentionally left blank. C141-E270...
  • Page 75: Chapter 5 Installation

    CHAPTER 5 INSTALLATION Notes on Handling HDDs Connections Setting Terminals Mounting HDDs Connecting Cables Checking Operation after Installation and Preparing the HDDs for Use Dismounting HDDs This chapter describes the notes on handling HDDs, connections, setting switches and plugs, mounting HDDs, connecting cables, confirming drive operations after installation and preparation for use, and dismounting HDDs.
  • Page 76 Unpackaging a) Use a flat work area. Check that the "This Side Up" sign side is up. Handle the package on soft material such as a rubber mat, not on hard material such as a wooden desk. b) Be careful not to give excess pressure to the internal unit when removing cushions. c) Be careful not to give excess pressure to the PCBA and interface connector when removing the HDD from the Fcell (See Figure 6.2).
  • Page 77: Connections

    Connections Figure 5.1 shows examples of connection modes between the host system and the HDD. For the 16-bit SCSI, up to 16 devices including the host adapter, HDD, and other SCSI devices can be connected to the SCSI bus in arbitrary combinations. Install a terminating resistor on the SCSI device connected to both ends of the SCSI cable.
  • Page 78: Figure 5.1 Scsi Bus Connections

    Connecting more than one HDD (single host) Figure 5.1 Connecting more than one HDD (multi-host) : SCSI terminator Figure 5.1 SCSI bus connections (1 of 2) SCSI bus connections (2 of 2) C141-E270...
  • Page 79: Setting Terminals

    Setting Terminals A user sets up the following terminals and SCSI terminating resistor before installing the HDD in the system as required. • Setting terminal: CN1 (NC model), CN2 (NP model) Figure 5.2 shows the location of the setting terminal for NP model, and Figure 5.3 shows the allocation and the default settings for NP model.
  • Page 80: Scsi Id Setting

    Figure 5.3 5.3.1 SCSI ID setting Table 5.1 shows the SCSI ID setting. For the terminal location and allocation of NC model, see Figure 4.13 and Table B.1. For NP model, see Figure 5.2 and 5.3. When the SCSI ID is set using the external operator panel connector CN1 of NP model, all pins listed in Table 5.1 should be open.
  • Page 81: Table 5.1 Scsi Id Setting

    NC model (CN1) SCSI Pin 39 Pin 79 Open Open Short Open Open Short Short Short Open Open Short Open Open Short Short Short Open Open Short Open Open Short Short Short Open Open Short Open Open Short 15 (*1) Short Short *1 Set at factory shipment.
  • Page 82: Each Mode Setting

    5.3.2 Each mode setting Setting terminator power supply Refer to Table 5.2 for controlling the supply of power from the drive to the SCSI terminator power source (TERMPOW). For information on NP model, refer to Figures 5.2 and 5.3. Table 5.2 Setting SCSI terminator power supply (NP model) Supply on/off of SCSI terminator power from Supply off...
  • Page 83: Table 5.4 Write Protect Setting (Np Model)

    Write protect When the write protect function is enabled on NP model, writing to the disk medium is disabled. Table 5.4 Write protect Write operation is enabled. Write operation is disable. *1. Set at factory shipment. For NC model, the function of the write protect setting is not supported. Setting of the SCSI interface operation mode By establishing a short-circuit between CN2-15 amd CN2-16 on NP model, the SCSI interface operation mode is forcibly set to the single-ended mode.
  • Page 84: Mode Settings

    5.3.3 Mode settings In addition to the previously described settings using setting terminals, the HDD is provided with several mode settings. The mode settings are enabled by specifying the CHANGE DEFINITION command. Table 5.7 lists the mode settings and their settings at factory shipment. Refer to Subsection 3.1.4 “CHANGE DEFINITION (40)”...
  • Page 85: Mounting Hdds

    Mounting HDDs 5.4.1 Check before mounting Reconfirm if the CN2 setting terminal is set correctly according to Table 5.8 before mounting the NP model drives in the system cabinet. For the CN2 setting terminal location, see Section 5.3. The NC model drives do not require the following check. Table 5.8 Setting contents (Check item)
  • Page 86: Connecting Cables

    Connecting Cables Connect the HDD and system with the following cables. See Section 4.3 for further details of the requirements for HDD connector positions and connecting cables. • Power cable • SCSI cable • External operator panel cable (if required for NP model) The general procedures and notes on connecting cables are described below.
  • Page 87: Checking Operation After Installation And Preparing The Hdds For Use

    Checking Operation after Installation and Preparing the HDDs for Use 5.6.1 Confirming initial operations This section describes the operation check procedures after power is turned on. Since the initial operation of the HDD depends on the setting of the motor start mode, check the initial operation by either of the following procedures.
  • Page 88: Checking Scsi Connection

    d) If an error is detected in initial self-diagnosis the LED blinks. In this case, it is recommended to issue the REQUEST SENSE command from the initiator (host system) to obtain information (sense data) for error analysis. The LED lights during the HDD is executing a command. However, in same commands, the lighting time is only an instant.
  • Page 89: Figure 5.4 Checking The Scsi Connection (A)

    Motor starts when power is turned on Self test = 1 Unit Of =1 No parameter Figure 5.4 Checking the SCSI connection (A) C141-E270...
  • Page 90: Figure 5.5 Checking The Scsi Connection (B)

    Motor starts by START/STOP command * Executing time: about 60 seconds Figure 5.5 Checking the SCSI connection (B) C141-E270...
  • Page 91: Formatting

    Checking at abnormal end a) When sense data can be obtained with the REQUEST SENSE command, analyze the sense data and retry recovery for a recoverable error. Refer to Chapter 5 "Sense Data Error Recovery Methods" of the SCSI Logical Interface Specifications for further details. b) Check the following items for the SCSI cable connection: •...
  • Page 92 b. Format parameter (page code = 3) Specify the number of spare sectors for each cell in the "alternate sectors/zone" field (cannot be changed). FORMAT UNIT command Initialize entire recording surface of the disk with the FORMAT UNIT command. The FORMAT UNIT command initializes entire surface of the disk using the P lists, verifies data blocks after initialization, and allocates an alternate block for a defect block detected with verification.
  • Page 93: Setting Parameters

    5.6.4 Setting parameters The user can specify the optimal operation mode for the user system environments by setting the following parameters with the MODE SELECT or MODE SELECT EXTENDED command: • Error recovery parameter • Disconnection/reconnection parameter • Caching parameter •...
  • Page 94 The saved value of the MODE SELECT parameter is assumed as the initial value of each parameter after the power-on, the RESET condition, or the BUS DEVICE RESET message. The initiator can change the parameter value temporary (actively) at any timing by issuing the MODE SELECT or MODE SELECT EXTENDED command with specifying "0"...
  • Page 95 Notes: The user can arbitrarily specify the following parameters according to the system requirements: • ARRE • AWRE • • The user also can arbitrarily specify parameters other than the above. However, it is recommended to use the default setting in normal operations. Disconnection/reconnection parameters (page code = 2) The following parameters are used to optimize the start timing of reconnection processing to transfer data on the SCSI bus at a read (READ or READ EXTENDED command) or write...
  • Page 96 Caching parameters (page code = 8) The following parameters are used to optimize HDD Read-Ahead caching operations under the system environments. Refer to Chapter 2 "Data Buffer Management" of the SCSI Logical Interface Specifications for further details. • IC: Initiator control •...
  • Page 97: Dismounting Hdds

    a. Control mode parameters • QUEUE ALGORITHM MODIFIER • QErr: Resume or abort remaining suspended commands after sense pending state Dismounting HDDs Since the method and procedure for dismounting the HDD, etc. depends on the locker structure of the system, etc., the work procedures must be determined in consideration of the requirements specific to the system.
  • Page 98 This page is intentionally left blank.
  • Page 99: Chapter 6 Diagnostics And Maintenance

    CHAPTER 6 DIAGNOSTICS AND MAINTENANCE Diagnostics Maintenance Operation Check Troubleshooting Packaging This chapter describes diagnostics and maintenance. Diagnostics 6.1.1 Self-diagnostics The HDD has the following self-diagnostic function. This function checks the basic operations of the HDD. • Initial self-diagnostics • Online self-diagnostics (SEND DIAGNOSTIC command) Table 6.1 lists the contents of the tests performed with the self-diagnostics.
  • Page 100 Brief test contents of self-diagnostics are as follows. a. Hardware function test This test checks the basic operation of the controller section, and contains following test. • RAM (microcode is stored) • Peripheral circuits of microprocessor (MPU) • Memory (ROM) •...
  • Page 101 The HDD does not reply to the SCSI bus for up to 2 seconds after the initial self-diagnostics is started. After that, the HDD can accept the I/O operation request correctly, but the received command, except the executable commands under the not ready state (such as INQUIRY, START/STOP UNIT), is terminated with the CHECK CONDITION status (NOT READY [=2]/logical unit is in process of becoming ready [=04-01] or logical unit not ready, initializing command required [=04-02]) during the interval from the spindle motor becomes stable to the...
  • Page 102: Test Programs

    b. Reporting result of self-diagnostics and error indication When all specified self-diagnostics terminate normally, the HDD posts the GOOD status for the SEND DIAGNOSTIC command. When an error is detected in the self-diagnostics, the HDD terminates the SEND DIAGNOSTIC command with the CHECK CONDITION status. The initiator should issue the REQUEST SENSE command when the CHECK CONDITION status is posted.
  • Page 103: Maintenance

    See Section 5.1 and 6.5 for notes on packaging and handling when returning the HDD. Data loss Save data stored on the HDD to other media before requesting repair. Fujitsu does not assume responsibility if data is corrupted during servicing or repair. 6.2.1...
  • Page 104: Maintenance Requirements

    Electrical shock To avoid shocks, turn off the power before connecting or disconnecting a cable, connector, or plug. Never touch the HDDs while power-feeding. Take the following precautions to prevent disk drive damage during maintenance and troubleshooting: Damage Always ground yourself with a wrist strap connected to ground before handling.
  • Page 105: Maintenance Levels

    Service system and repairs Fujitsu has the service system and repair facility for the HDD. Contact Fujitsu representative to submit information for replacing or repairing the HDD. Generally, the following information must be included: a) HDD model, part number (P/N), revision number, serial number (S/N), and date of...
  • Page 106: Tools And Test Equipment

    6.2.4 Tools and test equipment HDD troubleshooting and repair in the field require only standard SCSI tools. No special tools or test equipment are required. This manual does not describe the factory-level tools and test equipment. 6.2.5 Tests This HDD can be tested in the following ways: •...
  • Page 107: Figure 6.1 Test Flowchart

    Start Start self-test by turning the power on Test results OK? Execute an operation test using a host computer or test equipment Test results OK? Continue operation C141-E270 Check host system (Table 6.2) Host system normal? Replaced or repair HDD normal? Execute diagnostic test using a host computer or test...
  • Page 108: Operation Check

    Operation Check 6.3.1 Initial seek operation check If an error is detected during initialization by the initial seek operation check routine at power-on, the spindle motor of the HDD stops, and then the HDD becomes unusable. For an explanation of the operation check before the initial seek, refer to the Section 5.6. 6.3.2 Operation test While the host computer is processing data, the HDD monitors HDD operation including data...
  • Page 109: Troubleshooting

    At this level of maintenance, we recommend replacing the HDD as a unit. If replacing the HDD rectifies the fault, return the removed HDD to Fujitsu, for test and repair. If the newly installed HDD does not rectify the fault another part of the system is faulty.
  • Page 110: Table 6.2 System-Level Field Troubleshooting

    Table 6.2 Item DC power cable Check that the power cable is correctly connected to the disk drive and power supply unit. DC power level Check that the DC voltage is within the specified range (±5%). Check that +5V DC supply is from 4.75 to 5.25V DC. For NC model, check the voltage between pin 36 and 76 of the SCSI connector.
  • Page 111: Troubleshooting At The Repair Site

    HDD to Fujitsu for repair. A media defect list must be included with the HDD returned to Fujitsu. If the possibly faulty part is the HDD, return the whole HDD to Fujitsu for repair. Also if a clear error (erroneous servo track information or noisy HDD) is detected in the DE, return the whole HDD to Fujitsu.
  • Page 112: Troubleshooting With Parts Replacement In The Factory

    Finding possibly faulty parts in the field was explained in Subsection 6.4.2. This manual does not cover finding possibly faulty parts at the factory level. Packaging When the HDD is returned to Fujitsu, the following methods are recommended. 6.5.1 Single HDD packaging Figure 6.2...
  • Page 113 Put the HDD into FCELL. • At this time, the connector of the HDD is directed to the hinge side of FCELL. • The PCBA is put in the side with the material mark of FCELL. Push from two corners of FCELL on the hinge side previously, push two corners of the opening next, and lock FCELL surely.
  • Page 114: Multi-Box Packaging

    6.5.2 Multi-box packaging (upper) Put the conductivity bag into the milti-box, in addition put the cushion (lower) into the bag. Put unitary packaging (FCELL) in the cushion (lower). • At this time, FCELL is put in the cushion (lower) so that the FCELL opening may become downward.
  • Page 115: Figure 6.4 Fraction Packaging

    Put the long desiccant between the cushion (upper) Seal the conductivity bag with the packaging tape Close the cardboard box with the packaging tape (Attach the tape in 'H' figure at the tape.) C141-E270 Figure 6.4 Fraction packaging...
  • Page 116 This page is intentionally left blank. C141-E270...
  • Page 117: Chapter 7 Error Analysis

    The initiator can read the sense data by issuing a REQUEST SENSE command. This HDD is equipped with sense data with a byte length of 48. Accordingly, Fujitsu recommends collecting all 48-byte sense data when the host unit collects sense data.
  • Page 118: Figure 7.1 Sense Data Format

    Bit 7 Byte 0 Valid [MSB] [MSB] Basic information SKSV Additional information Detail information MSB: Most significant byte LSB: Least significant byte LUN: Logical unit number SKSV: Sense key specific valid SCSI ID: SCSI identifier X‘70’ or X‘71’ (error code) X‘00’...
  • Page 119: Sense Data Analysis

    Sense Data Analysis 7.2.1 Error information indicated with sense data Table 7.1 lists the definition of sense data. For details of sense data, refer to Chapter 5 “Sense Data Error Recovery Methods” of the SCSI Logical Interface Specifications. Subsection 7.2.2 onwards explain troubleshooting using sense data. Table 7.1 Sense data Sense...
  • Page 120: Sense Data (3-0C-03), (4-32-00), (4-40-Xx), And (4-C4-Xx)

    7.2.2 Sense data (3-0C-03), (4-32-00), (4-40-xx), and (4-C4-xx) Sense data (3-0C-03), (4-32-00), (4-40-xx), and (4-C4-xx) indicate one of the following: • A target sector could not be detected using the sector counter. • A seek process overran the specified time. •...
  • Page 121: Appendix Asetting Terminals

    APPENDIX A SETTING TERMINALS Setting Terminals (on NP model only) This appendix describes setting terminals. C141-E270...
  • Page 122: Setting Terminals (On Np Model Only)

    Setting Terminals (on NP model only) Table A.1 Pin pair Setting item 1 - 2 3 - 4 5 - 6 SCSI ID Open Open Open (Open) Short Open Open (Open) Open Short Open (Open) Short Short Open (Open) Open Open Short (Open) Short...
  • Page 123: Appendix Bconnector Signal Allocation

    APPENDIX B CONNECTOR SIGNAL ALLOCATION SCSI Connector Signal Allocation: SCA2 type LVD 16-bit SCSI SCSI Connector Signal Allocation: 68-pin type LVD 16-bit SCSI This appendix describes the connector signal allocation. C141-E270...
  • Page 124: Scsi Connector Signal Allocation: Sca2 Type Lvd 16-Bit Scsi

    SCSI Connector Signal Allocation: SCA2 type LVD 16-bit SCSI Table B.1 SCSI connector (SCA2 type LVD 16-bit SCSI): CN1 Pin No. Signal +12V (Charge) +12V +12V +12V Reserved (N.C.) Reserved (N.C.) –DB11 –DB10 –DB09 –DB08 –I/O –REQ –C/D –SEL –MSG –RST –ACK –BSY...
  • Page 125: Scsi Connector Signal Allocation: 68-Pin Type Lvd 16-Bit Scsi

    SCSI Connector Signal Allocation: 68-pin type LVD 16-bit SCSI Table B.2 SCSI connector (68-pin type LVD 16-bit SCSI): CN1 Pin No. Signal DB12 DB13 DB14 DB15 DBP1 DB00 DB01 DB02 DB03 DB04 DB05 DB06 DB07 P_CRCA DIFFSNS TERMPWR* TERMPWR* (Reserved) DB08 DB09 DB10...
  • Page 126 This page is intentionally left blank.
  • Page 127: Glossary

    Additional Sense Code This is a 1-byte code displayed in the sense data and is information which specifies the type of error that was detected. Bus phase The name of SCSI bus state. The SCSI bus can be either in the BUS FREE, ARBITRATION, SELECTION, RESELECTION or INFORMATION TRANSFER phase.
  • Page 128 SCSI Small Computer System Interface The standardized input/output interface of the American National Standards Institute (ANSI). [Standard No.: ANSI X3. 131-1986] SCSI Device The general name given to a device which is connected to the SCSI bus (input/output device, I/O controller, host adapter, expander, etc.). SCSI ID A physical device address which identifies an SCSI device on the SCSI bus.
  • Page 129: Acronyms And Abbreviations

    Acronyms and Abbreviations Alternating Current ACKnowledge ARRE Automatic Read Reallocation Enabled ATteNtion American Wire Gauge AWRE Automatic Write Reallocation Enabled Bits Per Inch BuSY Control/Data Command Descriptor Block CmpLst Complete List Cyclic Redundancy Check CYLinder Direct Current Disable CoRrection DCRT Disable CeRtificaTion Disk Enclosure DevOfl...
  • Page 130 Parts/Number PCBA Printed Circuit Board Assembly Post ERror PLO Sync Phase Lock Oscillator Syncronous Partial Medium Indicator Read Cache Disable REQuest Relative Humidity ReSeT Serial/Number SCSI Small Computer System Interface SeCTor SELect SelfTest Self Test Signal Ground Save Page SPindle Motor Transfer Block Tracks Per Inch UnitOfl...
  • Page 131: Index

    INDEX 16-bit SCSI ID external input...63 16-bit SCSI interface connector ...61 68-pin type LVD 16-bit SCSI ...121 8-bit SCSI/16-bit SCSI...14 AC noise filter ...58 acoustic noise ...17, 23 actuator ...18 additional sense code...113 additional sense code qualifier ...113 addressing of peripheral device ...20 air circulation (recirculation filter, breather filter)...18 allowable input voltage ...53...
  • Page 132 factory maintenance...101 field maintenance...101 finding possibly faulty part...108 format capacity ...38 format parameter ...88 FORMAT UNIT command ...88 formatting ...87 gaps...37 general note ...71 hardware function test ...96 hardware structure ...18 HDD replacement...101 HDD troubleshooting ...107 head ...18 head skew ...35 high speed data transfer...15 high speed positioning...17 initial seek operation check ...104...
  • Page 133 SCA2 type LVD 16-bit SCSI ...120 SCA2 type SCSI connector ...59 SCSI bus configuration ...20 SCSI bus connection ...74 SCSI cable connection...66 SCSI connector...120, 121 SCSI connector signal allocation...120, 121 SCSI function specification...29 SCSI ID setting...76, 77 SCSI interface error...116 SCSI standard ...14 sector format...36 seek test ...96...
  • Page 134 This page is intentionally left blank. C141-E270...
  • Page 135 We would appreciate your comments and suggestions regarding this manual. Manual code C141-E270-01EN Manual name MBA3300NC, MBA3300NP, MBA3147NC, MBA3147NP, MBA3073NC, MBA3073NP HARD DISK DRIVES PRODUCT MANUAL Please mark each item: E(Excellent), G(Good), F(Fair), P(Poor). General appearance Technical level Organization Clarity Accuracy Comments &...
  • Page 136 This page is intentionally left blank.

This manual is also suitable for:


Table of Contents
