Set auto
palette
Reset palette
View Selection
Choose color
from the image
Select colors
from the image
Choose color
from dialog
Merge colors
Delete colors
Load LUT
Save LUT
To calculate a palette automatically
Press the button
The palette will be recalculated automatically, and the image will be regenerated to
reflect the changes. The color samples will appear in the color Sample table, and
the number of colors will appear in the color Counter.
To create a new palette
Set a number of color in the color Counter
- or -
edit the palette in the color Sample table.
Press the button
Observe the changes in the Preview window. When the best result are achieved
press OK.
To select color(s)
Pick a color in the color Sample table; hold SHIFT for continuous selection;
Pressing this button forces the program to automatically
determine a set of colors that represents the image
most closely.
This button is used to recalculate the palette based on
the number of colors set in the color Counter.
When this checkbox is checked, the points of selected
colors are highlighted with a specified color in the
image.
This tool is used to choose a color by clicking on a pixel
in the document window. The color of a selected pixel
will be highlighted in the color samples table.
This tool is used to select colors by drawing a polygon
around an area in the document window. Press ENTER
or right-click to close the polygon.
Opens the color Selection dialog which allows the
replacement of the currently selected color with a new
one.
Merges colors selected from the color samples table to
the mean color.
Deletes colors selected in the color samples table from
the palette
Loads the current palette from a LUT-file (Look-Up
Table).
Saves the current palette in a LUT-file (Look-Up Table).
Use this button to save and load color palette
information to and from a template file.
.
