Upgrading The Computer
Figure 6 - 3
Memory Socket 2
6
6 - 6 Upgrading the System Memory

Upgrading the Memory in Socket 2

1. Turn off the computer.
2. Turn the computer over.
3. Remove screws &
1
4. Carefully lift the memory socket cover up and set it aside.
5. If there is a module currently installed which needs to be upgraded/replaced
then remove it.
2
1
from the memory socket cover
2
.
3
3
